DT Research SA1360 Basic Operation Manual

SA1360/ DT136

SPECIFICATIONS

*
Model
System
Processor
GPU
Memory (RAM)
Storage
Microsoft® Windows® Embedded
Operating Systems
Standard 7
Display Resolution
Video Resolution
Trusted Platform Module
Network Interface
10/100/1000MB BaseT LAN x 2; Wi-Fi 802.11 a/b/g/n (optional)
Expansion
1 HDMI port, 1 VGA port, 1 DVI port
Line-out jacks); 4 USB 2.0 ports; 2 Serial/ COM ports; 2 PS/2 ports;
Input/Output Ports
2 DC-in (include Phoenix connector for 12-24V DC in); 2 RJ45 connectors for
Ethernet; 1 Parallel port; Wi-Fi dipole antenna (optional)
Power
AC/DC Adapter
Input: 100 – 240V AC; Output: 18.5V DC/ Phoenix: 12-24V DC, 3.5A
AC/DC Adapter
Regulatory
Power Consumption
Mechanical
Enclosure
Dimensions
(H x W x D)
Weight
Environmental
Regulatory
Temperature
Humidity
* Specifications subject to change without notice.
** Support for up to two displays at one time (e.g. HDMI and VGA only, or VGA and DVI only)
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2013, DT Research, Inc. All Rights Reserved. DT Research is a registered trademark of DT Research, Inc.
signage dtri com
BOG012913DT136SA1360ENG
4
ENGLISH
SA1360 DT136
Intel® Core™ i-Series CPU
Intel® HM65
4GB to 8GB
32GB, 64GB or 128GB
Microsoft® Windows® Embedded
Standard 7 or Windows® 7 Pro
Up to 1920 x 1080
Dual Full-HD
TPM 1.2
PCI Express
** ; 2 Audio jacks (Microphone-in,
UL, CE, PSE
Max: 46.3W (48.4 VA); Idle: 6.09W (9.46 VA)
Aluminum + steel
2.75 x9.8 x 7.87 in/ 70 x 250 x 200 mm
6.97 lbs/3.16kg
FCC Class B, CE, C-Tick, UL, RoHS compliant
Operation: 0°C - 40°C; Storage: -20°C - 60°C
0% - 90% non-condensing
http://www.dtresearch.com
Digital Signage Appliance
Embedded Controller/ System
SA1360/ DT136
BASIC OPERATION GUIDE
ENGLISH

INTRODUCTION

Thank you for acquiring the latest addition to DT Research's line of Embedded Controller/ System devices
- the SA1360/ DT136, featuring compact, robust construction powered by the high-performance and
energy efficient Intel® Core™ i-Series processor. The SA1360/ DT136 supports major embedded operating
systems as well as Microsoft® Windows® Embedded Standard 7 or Windows® 7 Pro and provides complete
solutions for a variety of computing needs. The user is offered a choice of software solutions on a platform
characterized by the following:
• High-integration and energy-efficient processor technology
• Expanded graphics capabilities for multimedia applications
• Robust construction for reliable operation
• Cost-effective computing in compact and versatile packaging
1
Note: The actual package contents may vary depending on the configuration acquired.
Package Contents
2
1 One SA1360/ DT136
2 AC/DC Power Adapter
3
Basic Operation Guide
