DT160
SPECIFICATIONS
System
Processor
GPU
Memory (RAM)
Storage
Operating Systems
Display Resolution
Network Interface
Expansion
Input/Output Ports
Power
AC/DC Adapter
Mechanical
Enclosure
Dimensions
(H x W x D)
Weight
Environmental
Regulatory
Temperature
Humidity
* Specifications subject to change without notice.
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2012, DT Research, Inc. All Rights Reserved. DT Research is a registered trademark of DT Research, Inc.
BOG030512DT160ENG
4
ENGLISH
signage dtri com
1.5GHz x86
VIA CX700M
512MB or 1GB
64MB to 16GB Flash; 160GB HDD
Microsoft® Windows® CE, Windows® XP Embedded, or
Windows® XP Pro for Embedded Systems
Up to 1920 x 1080
10/ 100Mb BaseT LAN; Wi-Fi 802.11a/b/g (optional)
Mini-PCI (internal); USB
DVI-I; 12V DC-in jack; 3 Audio jacks (Microphone-in, Line-in,
Headphone-out jacks); 4 USB 2.0 ports; RJ45 connector for
Ethernet; Wi-Fi dipole antenna (optional)
Input: 100 – 240V AC; Output: 12V DC
Aluminum chassis; Magnesiumaluminum end-caps
1.7 x 5.5 x 5.1 in/ 43 x 140 x 130 mm
1.2 lbs/ 544 g
FCC Class B, CE, C-Tick, UL, RoHS compliant
Operation: 0°C - 40°C; Storage: -20°C - 60°C
0% - 90% non-condensing
http://www.dtresearch.com
Embedded Controller/
System
DT160
BASIC OPERATION GUIDE
ENGLISH
INTRODUCTION
Thank you for acquiring the latest
addition to DT Research's line of
Embedded Controller/ System
devices—the DT160, featuring a slim yet robust construction
powered by the 1.5GHz x86 processor and providing complete solutions
for a variety of computing needs.
The DT160 supports major embedded operating systems as well as Microsoft® Windows® CE,
Windows® XP Embedded or Windows® XP Pro. The user is offered a choice of software solutions
on a platform characterized by the following:
igh-integration and energy-efficient processor technology
H
• obust and fan-less construction for quiet and reliable operation
R
• ow-cost computing in compact and versatile packaging
L
1
Note: The actual package content may vary depending on the configuration acquired.
Package Contents
1
2
DT160
2
AC/DC Power Adapter
3
DVI-VGA Adapter
4
Basic Operation Guide
3
