Zte MF90 Getting Started Manual

MF90
Let's go
Getting started with your device.
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
1
Installing Your Device
1. Slide the back cover and remove it
2. Insert the (U)SIM card.
WARNING!
Your device does not support the micro-SIM and nano-SIM card or any
other non-standard SIM cards. To avoid damage to the device, do not
use those cards or any card holders.
3. Insert the microSDHC card if necessary.
6
LEGAL INFORMATION
Copyright © 2014 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or
utilized in any form or by any means, electronic or mechanical, includ-
ing photocopying and microfilm, without the prior written permission of
ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to
make modifications on print errors or update specifications without prior
notice.
Version No. : R1.0
Edition Time: December 2, 2014
NOTE:
Do not use the device in an enclosed environment or where heat dis-
sipation is poor. Prolonged work in such space may cause excessive
heat and raise ambient temperature, which may lead to automatic shut-
down of the device for your safety. In the case of such event, cool the
device in a well-ventilated place before turning on for normal use.
2
4. Insert the battery.
5. Close the back cover.
Connecting to Your Device
Via Wi-Fi
1. Power on your device directly.
2. Use your normal Wi-Fi application on the client to search for the
available wireless networks.
7
Getting to Know Your Device
Appearance
The following figure is only for your reference. The actual product may
be different.
1. LED Indicators
2. Power Button
3. WPS Button
4. Micro USB Port
5. (U)SIM Card Slot
6. RESET Button
7. microSDHC Card Slot
NOTE:
microSDHC™ logo is a trademark of SD-3C, LLC.
3
NOTE:
Please set the client to obtain an IP address automatically referring to
the chapter "Configuring your PC", and then the client will get an IP ad-
dress like "192.168.0.101".
3. Select the SSID of your device, and then click Connect.
8
Indicators
Indicator Status Description
Error status. Not registered to the mobile
Red solid network, no (U)SIM card inserted or no
network service available.
Green solid Registered to the 2G/3G network.
Network
Connected to the 2G/3G network and data
Green blinking
is being transferred.
Blue solid Registered to the 4G network.
Connected to the 4G network and data is
Blue blinking
being transferred.
Blue solid WPS is active.
Wi-Fi
Blue blinking Wi-Fi is active.
LED light off Wi-Fi is off or your device is in sleep mode.
The battery is empty. Please charge the
Red blinking
battery.
• The battery is low. Please charge the
battery.
Red solid
• The battery is in the over-voltage charg-
Battery
ing status.
Green blinking The battery is being charged.
Green solid The battery level is middle or high.
Your device is in sleep mode and not being
LED light off
charged, or the battery is not inserted.
4
NOTE:
Please check the label on your device to get the default SSID.
4. Input the password, and then click Connect.
NOTE:
You may need to input the password for Wi-Fi connection. Please
check the label on your device to get the default.
5. Wait a moment, and then the client will connect to your device suc-
cessfully.
Via USB Cable
1. Connect to the device.
2. Power on your device.
9
Connection Scenario
Your device supports two methods to connect to the Internet and sup-
ports multi-clients for surfing on the Internet at the same time. The fol-
lowing figure is only for your reference.
• 4G Mode: Use your (U)SIM card to access the Internet.
• Internet Wi-Fi Mode: Your device will connect to other WLAN de-
vice (hotspot device, wireless router, etc.) via Wi-Fi to access the
Internet. The WLAN device has already connected to the Internet.
NOTE:
The subnets of your device and other WLAN device must be different.
5
3. The OS detects and recognizes new hardware and finishes the in-
stallation automatically.
NOTE:
If the system does not automatically launch installation, you can click
the device installation icon in My Computer to install the software.
4. Wait a moment, and then the client will connect to your device suc-
cessfully.
Using the WPS(Optional)
If your client device supports WPS, you don't have to input the pass-
word manually after WPS has been available. Please do the following:
1. Power on your device, and enable the Wi-Fi function on your de-
vice.
2. Press and hold the WPS button on your device about three seconds
to start Wi-Fi Protected Setup authentication process.
3. Enable the WPS function on your client to respond this authentica-
tion process.
4. Follow the system prompts on your client to finish the connection.
NOTE:
For the detailed operations about the client, please refer to the client's
instruction.
10
