Product introduction

Motherboard overview

Unplug the power cord from the wall socket before touching any component.
Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.
Unplug the power cord before installing or removing the motherboard. Failure to do so
can cause you physical injury and damage to motherboard components.
KBMS
USB34
Place this
side towards
USB3_12
the rear of the
chassis
USB56
LAN_USB910
AUDIO
Scan the QR code to get the detailed pin definitions.
ASUS EX-B85M-V
1
2
17.78cm(7.0in)
CPU_FAN
EX-B85M-V
EATX12V
CHA_FAN
RTL
8111GR
Super
I/O
PCIEX1_1
ALC
887-VD2
PCIEX1_2
AAFP
USB1112
TPM
14
13
12
11
3
4
LGA1150
PCIEX16_1
Intel
®
B85
USB3_1314
SATA6G_1
SATA6G_2
SATA6G_3
10
5
1
1
5
6
64Mb
BIOS
7
F_PANEL
9
8
1-1
