ZUMEX MULTIFRUIT SPEED CONTROL Quick Manual page 19

Cleaning
1. Place the rear power switch in position « 0 » and unplug it pulling out
the plug.
Fig 5
2. Remove the handle by lifting from the front.
3. Remove cover lifting it upwards and separating it from the peel
bucket.
Fig 7
4. Disassemble the tap and coaster.
5. Dismantle grating-filter and tank assembly, by pulling the bucket
upwards, following which they should come apart easily.
Attention: Do not touch the sharp points of the grater.
All these components are dishwasher safe. Clean the outside of the
machine using a soft cloth soaked with water and soap suitable for
dishes, rinsing with a cloth dampened with clean water to remove
soap traces.
Remember: To prevent the pulp from drying between uses, slowly pour
a jug of water through the feeding tube with the machine in operation.
Fig 6
Fig 8
Fig 9
