  • Page 1 T800 Series II Conventional Equipment Reference Guide M800RACK-00-100...
  • Page 2 M800RACK-00-100 Index Section 1: Introduction Guide to the Conventional T800 Equipment Questionnaire Conventional T800 Equipment Questionnaire Order Number System Rack and Function Cross-Reference Chart Rack Components Weights Section 2: Rack Configurations Section 3: Rack Power Supply Options Section 4: Guide Assemblies Section 5: Rack Backplanes Section 6:...
  • Page 3 T800 Series II Conventional Equipment Reference Guide Introduction...
  • Page 4 M800RACK-00-100 Section 1 T800 Conventional Equipment This publication contains relevant reference information for Tait’s T800 Conventional product range. It will be updated as equipment is modified or new features are introduced. It is intended to show only standard options. There is provision to ‘mix & match’ up to seven modules in a rack to produce combinations for customised solutions.
  • Page 5 Tait Electronics Limited reserve the right to update the equipment or this document or both without prior notice. The Master copy will be available on the Tait Electronics Ltd Customer Service web site. Changes will be notified to all document holders who will be responsible for updating these changes from the web site.
  • Page 6 Guide and Purpose of Filling out Conventional T800 Equipment Questionnaire The purpose of this questionnaire is to assist the staff of RSD to get as much information as possible from you at the start of your enquires or order request for equipment that is to be SET-UP BY RSD.
  • Page 7 For the rest of the requirements you may tick the appropriate YES box for the module that you would like to be fitted into the Rackframe, remembering there is only sufficient room to fit 7 x 60mm modules. Doing this will help RSD ensure that if a Rackframe has been mentioned it can support your requirements.
  • Page 8 PART 10 This is to inform RSD of your required delivery DATE . PART 11 (TRANSMITTER/EXCITER PARAMETERS) This section is to allow you to inform RSD of operational parameters for the equipment. By ticking the STANDARD box you are indicating that all parameters required are as stated in the Set-up procedure in the appropriate equipment manual, and the frequency/frequencies required are as stated in PART 05.
  • Page 9 CONVENTIONAL T800 EQUIPMENT Customer Information: Date: Customer / C.S.O From: Purchase Order Number: RSD Quote Reference: RSD Staff Responsible: This form has been devised to assist in clearly identifying the Product required, and its operational parameters if being BUILT and TESTED by RSD. DO YOU REQUIRE RACKS and MODULES? DO YOU REQUIRE MODULES ONLY? (Please continue on this page)
  • Page 10 Purchase Order Number: PART 04. EQUIPMENT TYPE REQUIRED :- SERIES I SERIES II PART 05. DO YOU KNOW THE FREQUENCIES AT THIS TIME? To be advised Attached CTCSS CTCSS Channel Panel Eprom Info To be advised Attached PART 06. AUXILLIARY EQUIPMENT :- Description OPTION REQUIRED Part Number...
  • Page 11 Purchase Order Number: PART 11. TRANSMITTER/EXCITER PARAMETERS :- STANDARD CUSTOMISED (As Manual) (Identify Requirements) Channel Spacing : C.T.C.S.S. : 12.5 kHz 20.0 kHz 25.0 kHz Single Other (Freq Frequency Stability : (VHF) 2.5 ppm Multiple 1.5 ppm (Pattern Required) (UHF) 1.0 ppm Tx Time Out : External Reference...
  • Page 12 SYSTEM BLOCK DIAGRAM (OPTIONAL) T800temp.V11.doc : Issued 09 Sept 1999 Page of 4...
  • Page 13 M800RACK-00-100 Section 1 T800S II Numbering System Conventional Rack Systems ordered from RSD using the adjacent Numbering System will be configured as follows: Rack Configuration The Racks used in these configurations are as per Section 2 of this guide, which illustrates the factory default specifications.
  • Page 14 Order Number System 14/12/1999 System Frequency RF Output Channel Power Ancillary Duplexer Type Band Power Spacing Supply Options B A 1 W D 0 0 Base Station (T800-22-XXXX) 12.5 kHz Repeater (T800-22-XXXX) 20 kHz Slimline (T800-23-0000) 25 kHz (T800-25-XXXX) Portable 50 kHz Tone Remote (T800-27-XXXX)
  • Page 15 Rack and Function Cross-Reference Chart Cross- Relevant Module Module Function Reference T number Section Single system Dual system Receive only 25W Transmit T8n6 - 50W Transmit T8n7 - T8n7 - 100W Transmit T8n7 - T8n7 - X800-9x-000y Default Power Options External 13.8V DC X800-9x-000y shown.
  • Page 16 Rack and Function Cross-Reference Chart Module Function Single system Dual system Receive only 25W Transmit 50W Transmit 100W Transmit External 13.8V DC Battery back-up Converter Circuit breaker Optional Duplexer Optional fan Optional relay Optional CH/PNL Portable T803 Remote/Alarm Link Quasi Sync Alarms (TA136) Speaker Monitor (T818)
  • Page 17 T800 Series II Rack and Module Weights 0.00 Weight (kg) Rackframe to house 2 modules 3.60 to house 3 modules 4.15 to house 4 modules 4.70 to house 5 modules 5.25 to house 6 modules 5.80 to house 7 modules 6.35 T8n5 Receiver 2.20...
  • Page 19 T800 Series II Conventional Equipment Reference Guide Rack Configuration...
  • Page 20 M800RACK-00-100 Section 2 T800-22-0x00 A standard single channel rack for repeater or base station use; up to 100 Watt output. Operational Characteristics • Single channel • Up to 100W with option of Transmitter or Exciter / PA combination • Speaker / Programming panel •...
  • Page 21 FRONT VIEW Excellence in Radio Excellence in Radio Receiver Exciter Power Amplifier Speaker Panel Power Supply Communications Communications T800// T800// T800// T800// T800// T800// T800// Overload Supply Standby Gating Gate Sensitivity Low forward power Carrier High reverse power Supply Line Power Line Supply...
  • Page 22 M800RACK-00-100 Section 2 T800-22-0x06 A 25 Watt single channel rack for repeater or link use. Operational Characteristics • Single channel • Up to 25W Transmitter Output • Speaker / Programming panel • DC line fuse • Earth stud • Backplane interface Power Supply Options •...
  • Page 23 FRONT VIEW Excellence in Radio Excellence in Radio Excellence in Radio Excellence in Radio Speaker Panel Receiver Transmitter Communications Communications Communications Communications T800// T800// T800// T800// T800// T800// T800// Gating Gate Sensitivity Carrier Supply Line Line Supply level Sensitivity Microphone Monitor Volume Monitor...
  • Page 24 M800RACK-00-100 Section 2 T800-22-0x10 A single channel repeater or base station rack based on the standard T800-22-0x00, with the option of fitting a Channel Panel. Operational Characteristics • Single channel • Up to 100W with option of Transmitter or Exciter / PA combination •...
  • Page 25 FRONT VIEW Excellence in Radio Excellence in Radio Receiver Exciter Power Amplifier Speaker Panel Power Supply Communications Communications T800// T800// T800// T800// T800// T800// T800// Overload Supply Standby Gating Gate Sensitivity Low forward power Carrier High reverse power Supply Line Power Line Supply...
  • Page 26 M800RACK-00-100 Section 2 T800-22-0x11 A Receiver only rack with alarm outputs, AC power supply and dual battery back-up connections. Operational Characteristics • Receive only - up to 4 receivers • Speaker / Programming panel - with Receiver Speaker Select Switch •...
  • Page 27 FRONT VIEW Speaker Panel Receiver Receiver Receiver Receiver Alarm Panel Power Supply T800// T800// T800// T800// T800// T800// T800// Overload Power Standby Gating Gate Gating Gate Gating Gate Gating Gate Receiver Sensitivity Sensitivity Sensitivity Sensitivity Speaker Select PSU Fail Batt Fail Supply Supply Supply...
  • Page 28 M800RACK-00-100 Section 2 T800-22-0x12 Receive only rack similar to T800-22-0x11; but with no alarm outputs. Operational Characteristics • Receive only - up to 4 receivers • Speaker / Programming panel - with Receiver Speaker Select Switch • DC line fuse •...
  • Page 29 FRONT VIEW Excellence in Radio Speaker Panel Receiver Receiver Receiver Receiver Power Supply Communications T800// T800// T800// T800// T800// T800// T800// Overload Standby Gating Gate Gating Gate Gating Gate Gating Gate Receiver Sensitivity Sensitivity Sensitivity Sensitivity Speaker Select Supply Supply Supply Supply Line...
  • Page 30 M800RACK-00-100 Section 2 T800-22-0x13 A dual 50 Watt channel rack, with AC power supply and DC battery back-up connections. Operational Characteristics • Dual channel • 50W output • Speaker / Programming panel • DC line fuse • Earth stud • Backplane interface Power Supply Options •...
  • Page 31 FRONT VIEW Power Amplifier Receiver Exciter Power Supply Receiver Exciter Power Amplifier T800// T800// T800// T800// T800// T800// T800// Overload Supply Supply Standby Gating Gate Gating Gate Sensitivity Sensitivity Low forward power Low forward power Carrier Carrier High reverse power High reverse power Supply Supply...
  • Page 32 M800RACK-00-100 Section 2 T800-22-0x14 A dual 25 Watt channel rack, with AC power supply and DC battery back-up connections. Operational Characteristics • Dual channel • 25W output • Dual Speaker / Programming panel (switchable) • DC line fuse • Earth stud •...
  • Page 33 FRONT VIEW Excellence in Radio Receiver Transmitter Speaker Panel Receiver Transmitter Power Supply Communications T800// T800// T800// T800// T800// T800// T800// Overload Standby Gating RX 1 RX 2 Gating Gate Gate Sensitivity Sensitivity Carrier Carrier Supply Supply Line Line Power Line Supply Line...
  • Page 34 M800RACK-00-100 Section 2 T800-22-0x15 A dual 25 Watt channel rack with a separate power supply for each channel. The speaker panel can be switched between receivers. Operational Characteristics • Dual channel • 25W output • Speaker / Programming panel, with Receiver Selectable Switch •...
  • Page 35 FRONT VIEW Power Supply Receiver Transmitter Speaker Panel Receiver Transmitter Power Supply T800// T800// T800// T800// T800// T800// T800// Overload Overload Standby Standby RX 1 RX 2 Gating Gate Gating Gate Sensitivity Sensitivity Carrier Carrier Supply Supply Power Line Line Power Line Supply...
  • Page 36 M800RACK-00-100 Section 2 T800-22-0x16 A dual 50 Watt channel rack for use in DC only situations. Operational Characteristics • Dual channel • 50W output per channel • Speaker / Programming panel, with Receiver Selectable Switch • DC line fuse • Earth stud •...
  • Page 37 FRONT VIEW Power Amplifier Receiver Exciter Speaker Panel Receiver Exciter Power Amplifier T800// T800// T800// T800// T800// T800// T800// Supply Supply Gating Gate RX 1 RX 2 Gating Gate Sensitivity Sensitivity Low forward power Low forward power Carrier Carrier High reverse power High reverse power Supply Supply...
  • Page 38 M800RACK-00-100 Section 2 T800-22-0x17 A dual 25 Watt channel rack for use in DC only situations. Operational Characteristics • Dual channel • 25W output per channel • Speaker / Programming panel, with Receiver Selectable Switch • DC line fuse • Earth stud •...
  • Page 39 FRONT VIEW Excellence in Radio Excellence in Radio Receiver Transmitter Speaker Panel Receiver Transmitter Communications Communications T800// T800// T800// T800// T800// T800// T800// RX 1 RX 2 Gating Gate Gating Gate Sensitivity Sensitivity Carrier Carrier Supply Supply Line Line Line Supply Line Supply...
  • Page 40 M800RACK-00-100 Section 2 T800-22-0x20 A single repeater or base station channel rack up to 100 Watt maximum output. The rack can accommodate an Rx/Tx Monitor panel and AC power input. Operational Characteristics • Single channel • Up to 100W with option of Transmitter or Exciter / PA combination •...
  • Page 41 FRONT VIEW Excellence in Radio Receiver Exciter Power Amplifier Speaker Panel Power Supply Rx/Tx Monitor Communications T800// T800// T800// T800// T800// T800// T800// Overload Supply Standby Gating Gate Sensitivity Low forward power Carrier High reverse power Supply Power Line Supply Line level Sensitivity...
  • Page 42 M800RACK-00-100 Section 2 T800-22-0x21 A single 25 Watt repeater or base station channel rack to accommodate an Rx/Tx Monitor and rack mounted circuit breaker for protection on the DC power input. Operational Characteristics • Single channel • 25W output only •...
  • Page 43 FRONT VIEW Excellence in Radio Excellence in Radio Rx/Tx Monitor Receiver Transmitter Speaker Panel Circuit Breaker Communications Communications T800// T800// T800// T800// T800// T800// T800// Supply Gating Gate Sensitivity Carrier Line Supply Supply Line level Sensitivity Volts Rx Signal Rx Line Tx Line Microphone Monitor...
  • Page 44 M800RACK-00-100 Section 2 T800-22-0x22 A single 50 Watt repeater or base station channel rack to accommodate an Rx/Tx Monitor and rack mounted circuit breaker for protection on the DC power input. Operational Characteristics • Single channel • 50W output only •...
  • Page 45 FRONT VIEW Excellence in Radio Receiver Exciter Power Amplifier Speaker Panel Circuit Breaker Rx/Tx Monitor Communications T800// T800// T800// T800// T800// T800// T800// Supply Supply Gating Gate Sensitivity Low forward power Carrier High reverse power Supply Line Line Supply level Sensitivity Volts Rx Signal...
  • Page 46 M800RACK-00-100 Section 2 T800-22-0x23 A single channel rack with 50 Watt maximum output, alarm outputs and AC power supply. Operational Characteristics • Single channel • Up to 50W output • Speaker / Programming panel • Alarm Panel • DC line fuse •...
  • Page 47 FRONT VIEW Excellence in Radio Alarm Panel Receiver Exciter Power Amplifier Speaker Panel Power Supply Communications T800// T800// T800// T800// T800// T800// T800// Overload Power Supply Standby Gating Gate Sensitivity Low forward power Carrier PSU Fail High reverse power Batt Fail Supply Line Power...
  • Page 48 M800RACK-00-100 Section 2 T800-22-0x24 A single channel rack with 50 Watt maximum output, alarm outputs (LO) and AC power supply. Operational Characteristics • Single channel • Up to 50W output • Speaker / Programming panel • Alarm Panel • DC line fuse •...
  • Page 49 FRONT VIEW Excellence in Radio Alarm Panel Receiver Exciter Power Amplifier Speaker Panel Power Supply Communications T800// T800// T800// T800// T800// T800// T800// Overload Power Supply Standby Gating Gate Sensitivity Low forward power PSU Fail Carrier High reverse power Batt Fail Line Supply Power...
  • Page 50 M800RACK-00-100 Section 2 T800-23-0x00 A single channel rack with 25 Watt maximum output mounted in a 2RU Slimline configuration for use in DC situations. Operational Characteristics • Single channel • Up to 25W output • Speaker / Programming Port Power Supply Options •...
  • Page 51 FRONT VIEW Receiver Transmitter T800// Gate Supply Supply Gating Line Monitor Sensitivity Level Line Monitor Carrier Microphone Exciter Out Sensitivity Volume T800 Slimline REAR VIEW Transmitter Receiver ITEMS SUPPLIED AS STANDARD PART NUMBER DESCRIPTION REFERENCE T800-23-0000 SLIMLINE ASSEMBLY KIT + CABLES SECTION 4 T8n5-nn-nnnn RECEIVER...
  • Page 52 M800RACK-00-100 Section 2 T800-23-0x01 A single channel rack with 25 Watt maximum output mounted in a 2RU Slimline configuration, with an AC power supply. Operational Characteristics • Single channel • Up to 25W output • Speaker / Programming Port Power Supply Options •...
  • Page 53 FRONT VIEW Receiver Transmitter T800// Gate Supply Supply Gating Line Monitor Sensitivity Level Line Monitor Carrier Microphone Exciter Out Sensitivity Volume T800 Slimline REAR VIEW Transmitter Receiver Power Supply ITEMS SUPPLIED AS STANDARD PART NUMBER DESCRIPTION REFERENCE T800-23-0001 SLIMLINE ASSEMBLY KIT + CABLES + POWER SUPPLY SECTION 4 T8n5-nn-nnnn RECEIVER...
  • Page 54 M800RACK-00-100 Section 2 T800-25-0000 A single 25W channel, housed in a portable case with sealed lead acid batteries. Operational Characteristics • Single channel • Up to 25W output • DC only operation - Batteries and external DC supply input • Speaker / Programming panel •...
  • Page 55 FRONT VIEW Receiver Transmitter Speaker Panel T800// T800// T800// T800// Gating Gate Sensitivity Carrier Supply Line Line Supply level Sensitivity Microphone Monitor Volume Monitor Mute TALK THROUGH EXTERNAL DC BASE STATION REPEATER BATTERY OPERATION T8n5 -nn-0200 T8n6 -nn-0200 T800-15-0000 SPKR/PROG PNL TA087-01-0000 100 CHANNEL CHANNEL PANEL...
  • Page 56 M800RACK-00-100 Section 2 T800-25-0001 A single 25W channel, housed in a portable case with sealed lead acid batteries. This unit can use an external AC power source. Operational Characteristics • Single channel • Up to 25W output • AC and DC operation - Batteries, external AC and DC supply input •...
  • Page 57 FRONT VIEW Receiver Transmitter Speaker Panel Power Supply T800// T800// T800// T800// Overload Standby Gating Gate Sensitivity Carrier Supply Line Power Line Supply level Sensitivity Microphone Monitor Volume Monitor Mute TALK THROUGH EXTERNAL DC BASE STATION REPEATER BATTERY OPERATION T8n5 -nn-0200 T8n6 -nn-0200 T800-15-0000 SPKR/PROG PNL TA087-01-0000...
  • Page 58 M800RACK-00-100 Section 2 T800-25-0002 A single channel with up to 50W output, housed in a portable case with no batteries. This unit can use external AC or DC power source. Operational Characteristics • Single channel • Up to 50W output •...
  • Page 59 FRONT VIEW Receiver Exciter Power Amplifier Power Supply T800// T800// T800// T800// Overload Supply Standby Gating Gate Sensitivity Low forward power Carrier High reverse power Supply Line Power Line Supply level Sensitivity Power Microphone Monitor Volume Monitor Mute TALK THROUGH EXTERNAL DC BASE STATION REPEATER...
  • Page 60 M800RACK-00-100 Section 2 T800-27-0x00 A dual channel rack with 25 Watt per channel maximum output and Tone Remote / Alarm outputs. Operational Characteristics • Dual channel • Up to 25W output • Speaker / Programming panel • Remote / Alarm Panel •...
  • Page 61 FRONT VIEW Remote / Alarm Receiver Transmitter Remote / Alarm Receiver Transmitter Power Supply T800// T800// T800// T800// T800// T800// T800// Overload Talk Through Talk Through Base Station Base Station Standby Gating Gate Gating Gate Sensitivity Sensitivity Carrier Carrier Rev Power Supply Rev Power Supply...
  • Page 62 M800RACK-00-100 Section 2 T800-27-0x01 A single channel rack with 100 Watt maximum output, Tone Remote / Alarm outputs and AC power supply. Operational Characteristics • Single channel • Up to 100W output • Speaker / Programming panel • Remote / Alarm Panel •...
  • Page 63 FRONT VIEW Excellence in Radio Excellence in Radio Remote / Alarm Receiver Exciter Power Amplifier Power Supply Communications Communications T800// T800// T800// T800// T800// T800// T800// Overload Talk Through Base Station Supply Standby Gating Gate Sensitivity Low forward power Carrier High reverse power Rev Power Supply...
  • Page 64 M800RACK-00-100 Section 2 T800-28-0x00 A single channel rack with 100 Watt maximum output, and provision for a High Stability Oscillator to enable the Paging function. Operational Characteristics • Single channel - Paging • Up to 100W output • Speaker / Programming panel •...
  • Page 65 FRONT VIEW Excellence in Radio Excellence in Radio Receiver Exciter Power Amplifier Power Supply Communications Communications T800// T800// T800// T800// T800// T800// T800// Overload Supply Supply Standby Gating Gate Sensitivity Low forward power Carrier High reverse power Line Supply Power Supply Line level...
  • Page 66 M800RACK-00-100 Section 2 T800-29-0x00 A dual channel rack with 25 Watt maximum output, to interface to Fylde Trunking Controller Operational Characteristics • Dual channel • Up to 25W output • Speaker / Programming panel • DC line fuse • Earth stud •...
  • Page 67 FRONT VIEW Excellence in Radio Receiver Transmitter Speaker Panel Receiver Transmitter Power Supply Communications T800// T800// T800// T800// T800// T800// T800// Overload Standby RX 1 RX 2 Gating Gate Gating Gate Sensitivity Sensitivity Carrier Carrier Supply Supply Line Line Power Line Supply Line...
  • Page 68 M800RACK-00-100 Section 2 T800-29-0x01 A single channel rack with 100 Watt maximum output, to interface to Fylde Trunking Controller Operational Characteristics • Single channel • Up to 100W output • Speaker / Programming panel • DC line fuse • Earth stud •...
  • Page 69 FRONT VIEW Excellence in Radio Excellence in Radio Receiver Exciter Power Amplifier Speaker Panel Power Supply Communications Communications T800// T800// T800// T800// T800// T800// T800// Overload Supply Standby Gating Gate Sensitivity Low forward power Carrier High reverse power Supply Line Power Line Supply...
  • Page 70 M800RACK-00-100 Section 2 T800-29-0x02 A dual channel rack with 50 Watt maximum output, to interface to Fylde Trunking Controller. Operational Characteristics • Dual channel • Up to 50W output • Speaker / Programming panel • DC line fuse • Earth stud •...
  • Page 71 FRONT VIEW Power Amplifier Receiver Exciter Speaker Panel Receiver Exciter Power Amplifier T800// T800// T800// T800// T800// T800// T800// Supply Supply Gating RX 1 RX 2 Gating Gate Gate Sensitivity Sensitivity Low forward power Low forward power Carrier Carrier High reverse power High reverse power Supply Supply...
  • Page 72 T800 Series II Conventional Equipment Reference Guide Rack Power Supply Options...
  • Page 73 M800RACK-00-100 Section 3 Power Supply Options This section details the Power Supply Options for T800 SeriesII Conventional rackframes. The power rails have been standardised to allow versatility in the rack applications. Not all options are available on every rack. Please contact RSD if you are unsure of the correct option.
  • Page 74 AC POWER SUPPLY ONLY OUTPUT E A R T H x = 0 ONLY 13.8V S T U D 2 AMPS F U S E EXTERNAL DC SUPPLY ONLY OUTPUT E A R T H x = 1 ONLY 13.8V S T U D 2 AMPS DC INPUT...
