INSTRUCTIONS FOR
18V Cordless

Hedge Trimmer

Stock No.75291
Part No.HTC18LI
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND
EFFECTIVE USE OF THIS PRODUCT.

GENERAL INFORMATION

These instructions accompanying the product are the original instructions. This document is part of the product, keep it
for the life of the product passing it on to any subsequent holder of the product. Read all these instructions before
assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been designed, and
contains all the necessary information to ensure its correct and safe use. By following all the general safety instructions
contained in this manual, it will ensure both product and operator safety, together with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper Tools policy
of continuous improvement determines the right to make modifications without prior warning.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTC18LI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Draper HTC18LI

Summary of Contents for Draper HTC18LI

  • Page 1: Hedge Trimmer

    AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.

  • Page 2: Title Page

    Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Draper Tools Limited. In all cases this copyright notice must remain intact.

  • Page 3: Table Of Contents

    CONTENTS 2.1 CONTENTS PAGE CONTENT PAGE TITLE PAGE INTRODUCTION ....................2 REVISION HISTORY................... 2 UNDERSTANDING THIS MANUAL ..............2 COPYRIGHT NOTICE ..................2 CONTENTS CONTENTS ......................3 GUARANTEE GUARANTEE ..................... 4 INTRODUCTION SCOPE ....................... 5 SPECIFICATION ....................5 HANDLING & STORAGE ................... 5 HEALTH &...

  • Page 4: Guarantee

    This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the guarantee period.

  • Page 5: Introduction

    This hand held cordless hedge trimmer is lightweight yet powerful and perfectly suited for hedge trimming away from mains power. 4.2 SPECIFICATION Stock no..........................75291 Part no..........................HTC18LI Battery: Type ..........................Li-ion Rated Voltage ........................ 18V Rating .......................... 2.0Ah Charger: Rated Voltage ......................

  • Page 6: Health & Safety Information

    HEALTH & SAFETY INFORMATION 5.1 GENERAL SAFETY INSTRUCTIONS Do not overreach. Keep proper footing and balance at all times. This enables better control of General Power Tools Safety Warnings the power tool in unexpected situations. Dress properly. Do not wear loose clothing or WARNING: Read all instructions.

  • Page 7: General Instructions For Battery Powered Tools & Chargers

    HEALTH & SAFETY INFORMATION 5.2 GENERAL INSTRUCTIONS FOR they eventually leak, they will become a pollutant hazard. Check that cutting tools are undamaged and are kept BATTERY POWERED TOOLS & clean and sharp, this will maintain their operating CHARGERS performance and lessen the loading on the tool. 5.3 SAFETY INSTRUCTIONS FOR Good Working Practices/Safety MAINS POWERED BATTERY...

  • Page 8: Instructions For Chargers And Batteries

    The battery is to be disposed of safely. medical attention. Inform the medical staff that the liquid is a 25-25% solution of Only use the correct Draper battery. potassium hydroxide. Do not crush, open or burn the battery. Exposure Do not splash or immerse in water or other to potentially harmful materials may occur.

  • Page 9: Hedge Trimmer Safety Warnings

    HEALTH & SAFETY INFORMATION 5.6 HEDGE TRIMMER SAFETY glasses is recommended. WARNINGS i) While operating the machine always be sure of a safe and secure operating position especially when using steps or ladder. Keep all parts of the body away from the j) Do not attempt to repair the machine unless you cutter blade.

  • Page 10: Technical Description

    TECHNICAL DESCRIPTION 6.1 IDENTIFICATION Cutting blade Main housing Safety guard Rear handle (with soft grip) Front handle On/off switch Rear switch lockout button Front handle (with soft grip) Rear handle On/off switch...

  • Page 11: Unpacking & Checking

    Lay the contents out and check them against the parts shown below. If any part is damaged or missing; please contact the Draper Helpline (the telephone number appears on the Title page) and do not attempt to use the hedge trimmer.

  • Page 12: Basic Hedge Trimmer Operations

    BASIC HEDGE TRIMMER OPERATIONS 8.1 BATTERY CHARGING - FIGS. 1 - 4 To charge the battery pack, it must first be removed from the hedge trimmer. To release the battery pack, press the battery release button and gently pull the battery pack from the hedge trimmer.

  • Page 13: Switching On Tool

    BASIC HEDGE TRIMMER OPERATIONS Caution: This units battery pack has low voltage FIG.5 protection, this means when fully discharged the unit will suddenly stop and will require charging. You will not experience the normal tapering off or slowing down of power as seen with other battery types. 8.2 SWITCHING ON TOOL - FIGS.

  • Page 14: Working Position

    BASIC HEDGE TRIMMER OPERATIONS 8.5 WORKING POSITION Maintain proper footing and balance and do not overreach. Please wear safety goggles, nonslip footwear and rubber gloves when trimming. Hold the tool firmly in both hands and turn the tool on by squeezing both switches. Always hold the trimmer with one hand on the front handle and one hand on the rear handle...

  • Page 15: Maintenance

    - NOTE: This hedge trimmer is intended for trimming hedges and bushes only and any other use constitutes inappropriate use. Note: Draper tools will not be responsible for any damage or injuries caused by repair of the tool by an unauthorised person or by mishandling of the tool.

  • Page 16: Optional Accessories

    10. OPTIONAL ACCESSORIES 10.1 BATTERIES Stock No. Part No. Voltage 80628 AGP21LI 18V 2.0Ah 10.2 CHARGER Stock No. Part No. Voltage 80629 AGP20LI 230V IN, 24V OUT.

  • Page 17: Explanation Of Symbols

    11. EXPLANATION OF SYMBOLS 11.1 EXPLANATION OF SYMBOLS Class II construction (Double insulated). WEEE Do not dispose of Waste Electrical & Electronic Equipment in with domestic rubbish For indoor use only. Do not expose to rain. Battery must be recycled or disposed of properly. Contains heavy metal - separate collection.

  • Page 18: Disposal

    12. DISPOSAL 12.1 DISPOSAL At the end of the machine’s working life, or when it can no longer be repaired, ensure that it is disposed of according to national regulations. Contact your local authority for details of collection schemes in your area. In all circumstances: •...
  • Page 19 NOTES...
  • Page 20 NOTES...
  • Page 21 NOTES...
  • Page 22 NOTES...
  • Page 23 NOTES...
  • Page 24 - Sales Fax: (023) 8049 4209 - General Enquiries: (023) 8026 6355 - Service/Warranty Repair Agent For aftersales servicing or warranty repairs, please contact the Draper Tools Helpline for details of an agent in your local area. YOUR DRAPER STOCKIST RDCH 010415...
