Marantz CD6002/F Service Manual
  1. Manuals
  2. Brands
  3. Marantz Manuals
  4. CD Player
  5. CD6002/F
  6. Service manual

Marantz CD6002/F Service Manual

Hide thumbs

Advertisement

Table of Contents

Service
Manual
SECTION
1. TECH NI CAL SPEC I FI CA TIONS ........................................................................................... 1
2. SERVICE HINTS AND TOOLS ............................................................................................. 4
3. WARNING AND LASER SAFETY INSTRUCTIONS ............................................................ 5
4. SERVICE MODE AND TAKING THE DISC OUT OF EMERGENCY ................................... 6
5. UPDATE MICROPROCESSOR SOFTWARE PROCEDURE .............................................. 7
6. WIRING DIAGRAM ..............................................................................................................17
7. BLOCK DIAGRAM ...............................................................................................................19
8. SCHEMATIC DIAGRAM ......................................................................................................21
9. PARTS LOCATION ..............................................................................................................27
10. EXPLODED VIEW AND PARTS LIST ................................................................................ 35
CD MECHANISM (LOADER ASS'Y) ............................................................................. 39
11. MI CRO PRO CES SOR AND IC DATA ...................................................................................41
12. ELECTRICAL PARTS LIST ..................................................................................................51
13. ABOUT REPLACE THE MICROPROCESSOR WITH A NEW ONE ............................... 62
Please use this service manual with referring to the user guide ( D.F.U. ) without fail.

TABLE OF CONTENTS

CD6002
CD6002 /
F B/N1B/N1S
F N/K1G
CD Player
PAGE
Part no. 90M30CW855010
First Issue 2007.07
MZ

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD6002/F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marantz CD6002/F

Summary of Contents for Marantz CD6002/F

  • Page 1: Table Of Contents

    Service CD6002 / F B/N1B/N1S F N/K1G Manual CD Player TABLE OF CONTENTS SECTION PAGE 1. TECH NI CAL SPEC I FI CA TIONS ................... 1 2. SERVICE HINTS AND TOOLS ..................... 4 3. WARNING AND LASER SAFETY INSTRUCTIONS ............5 4.
  • Page 2 Parts for your MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent. ORDERING PARTS : Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specifi ed.

  • Page 3: Technical Specifications

    1. TECHNICAL SPECIFICATIONS Audio characteristics Power supply Channels ............2 channels F version ..........AC 100 V 50 /60 Hz Frequency response ........2 Hz to 20 kHz K version ........... AC 220 V 50 Hz Dynamic range ............100 dB N version ..........
  • Page 4 ¡ CD-TEXT 表示対応 • Supports CD-Text display CD-Text is an extension to the existing audio CD CD-TEXT とは従来の音楽 CD にアルバム名、 standard that enables text information, such as the 曲名などの文字情報を記録した音楽ディスク name of the artist, album title and song titles to be です。以下のようなロゴが付いた...
  • Page 5 7 Playing MP3 or WMA fi les タイトル、アーティスト名、アルバムタイトル などを表示することができます。 This CD player can be used to play CD-R or CD-RW discs on which MP3 (MPEG Audio Layer-3) or WMA (Windows Media Audio) format audio files have been recorded. Support for MP3 ID3 tags enables display of ID3 information, such as artist names, album titles, •...

  • Page 6: Service Hints And Tools

    2. SERVICE HINTS AND TOOLS SERVICE HINTS SERVICE TOOLS Audio signals disc 4822 397 30184 or TCD-784 Disc without errors + Disc with DO errors, black spots and fingerprints 4822 397 30245 (SBC444A) or TCD-726 Disc (65 min 1kHz) without no pause 4822 397 30155 Max.

  • Page 7: Warning And Laser Safety Instructions

    3. WARNING AND LASER SAFETY INSTRUCTIONS WARNING WAARSCHUWING All ICs and many other semi-conductors are Alle IC’s en vele andere halfgeleiders zijn susceptible to electrostatic discharges (ESD). gevoelig voor elektrostatische ontladingen Careless handling during repair can reduce (ESD). life drastically. Onzorgvuldig behandelen tijdens reparatie When repairing, make sure that you are kan de levensduur drastisch doen...

  • Page 8: Service Mode And Taking The Disc Out Of Emergency

    4. SERVICE MODE AND TAKING THE DISC OUT OF EMERGENCY [A] SERVICE MODE 1. Insert mains cable plug in the outlet and press POWER button. 2. Press the OPEN/CLOSE button to open the tray. 3. Press the g/i button for about five seconds. 4.

  • Page 9: Update Microprocessor Software Procedure

    5. UPDATE MICROPROCESSOR SOFTWARE 5. UPDATE MICROPROCESSOR SOFTWARE PROCEDURE PROCEDURE When microprocessor software was updated, update the マイコンのソフトウェアが更新された場合、下記の手順に従っ software in the following procedure. てアップデートしてください。 Necessary Equipment 必要機器 • Windows PC (OS: Windows2000 または WindowsXP) で • Windows PC (OS: Windows2000 or WindowsXP) with Serial port.
  • Page 10 3. Double click FlashProg.exe, and launch the Flash 3. FlashProg.exe をダブルクリックし、 Flash Programmer を Programmer. 起動します。 NOTE : When a Flash Programmer does not launch even if 注意 : FlashProg.exe をダブルクリックしても Flash double-clicked FlashProg.exe, please refer to "[B] Programmer "[B] When a Flash が起動しない場合は、...
  • Page 11 5. Click the Setup in the menu bar and select the Object メニューバーから Setup をクリックし、 Object file を選択 file. します。 6. Click Browse. 6. Browse をクリックします。...
  • Page 12 7. Choose the Motorola S Format(*.s16,*.s24,*.s32) in 7. Files of type を Motorola S Format(*.s16,*.s24,*.s32) に Files of type. 変更します。 Choose the CD6002_yymmdd_x.s24 , and click Open . CD6002_yymmdd_x.s24 を選択し、 Open をクリックし NOTE : The yy is two digits of year. The mm is month. The ます。...
  • Page 13 9. Choose the TMP91FW60 in the Device, and choose the 9. Device から TMP91FW60 を選び、 Series から 900/L1 を選択 します。 900/L1 in the Series. And click Communication tab. そして、 Communication タブをクリックします。 10. Choose the Serial port number in the COM Port. 10.
  • Page 14 11. Disconnect the mains cord from the unit. 本機から電源ケーブルを外します。 接続冶具の RS-232C 端子と の Serial ポートを 12. Connect the RS-232C on the connection JIG and the Serial Port of windows PC with RS-232C cable. 232C ケーブルで接続します。 13. Connect FFC (upside contact) to the rear panel of the 本機のリアパネルに接続冶具の...
  • Page 15 17. Click P (Program) to start update. 17. P (Program) をクリックし、アップデートを開始します。 18. Software is written into the microprocessor. ソフトウェアがマイコンに書き込まれます。 The writing of software takes about 50 seconds. ソフトウェアの書き込みにかかる時間はおよそ 秒です。 19. If the software is updated successfully, a dialog box アップデートが完了すると "R006: Programming saying "R006: Programming completed successfully."...
  • Page 16 20. Click the File in the menu bar and select the Exit. メニューバーの File をクリックし、 Exit を選択します。 21. Disconnect mains cord from the unit, and then disconnect 電源ケーブルを本機からはずし、その後接続冶具の を FFC of connection JIG from the unit. 本機から外します。 [B] When a Flash Programmer did not launch [B] When a Flash Programmer did not launch 1.
  • Page 17 2. Delete the text "OpenFile=C:\...(your PC setting)...\???. テキスト文の” OpenFile=C:\...(PC 環境により異なりま s24". す。 )...\???.s24 ”を削除します。...
  • Page 18 3. Save the FlashProg.ini. 3. FlashProg.ini を上書き保存します。 4. Close the text editor. テキストエディタを閉じます。 5. Probably you can launch the Flash Programmer. Go to これで Flash Programmer を起動することが出来ますので the [A] Update Procedure step 3. [A] Update Procedure 手順 に戻ってください。...

  • Page 19: Wiring Diagram

    6. WIRING DIAGRAM POWER PWB MAINS MAIN PWB H/P(HEADPHONE) CD MECHANISM FRONT PWB TACT SW PWB...

  • Page 20: Block Diagram

    7. BLOCK DIAGRAM Servo Servo CD-RF Processor CD-RF Servo Audio 24-Bit Peripheral Analog (Audio Out) Post 1 Mbit PLL/VCO Filter SRAM 3.3V 1.5V MAIN TRANSF. SUB TRANSF.

  • Page 21: Schematic Diagram

    8. SCHEMATIC DIAGRAM MAIN PWB 1/2 DSP & PITCH PART TO/FROM CD MECHANISM TO/FORM UPDATE TO/FROM CD MECHANISM TO/FROM CD MECHANISM OPTICAL COAXIAL MAIN PWB 2/2 MAIN PWB 2/2 REMOTE CONTROL TO/FROM FRONT PWB...
  • Page 22 MAIN PWB 2/2 AUDIO PART FROM MAIN PWB 1/2 FROM MAIN PWB 1/2 HEADPHONE PWB POWER SUPLLY PART 4.7K 4.7K MAINS CORD POWER PWB HEADPHONE TO/FROM FRONT PWB...
  • Page 23 TO/FROM TO/FROM MAIN PWB 2/2 MAIN PWB 12 FRONT PWB TACT SW PWB...

  • Page 24: Parts Location

    9. PARTS LOCATION FRONT A Q202 Q203 Q204 POWER A PWB Q951 POWER B PWB 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 25 FRONT B IC21 HEADPHONE A PWB HEADPHONE B PWB TACT SW A Q801 - Q804 IC81 Q201 TACT SW B 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 26 MAIN A PWB Q718-Q720 Q618-Q620 IC45 IC46 IC53 Q502 IC33 Q717 Q617 Q910 IC31 IC51 Q374 Q503 Q716 Q715 Q616 Q615 IC48 IC47 Q714 - Q709 Q614 - Q609 Q909 Q708 Q707 Q608 Q607 IC49 IC50 Q301 IC96 IC95 IC52 Q606 Q706 Q705 Q704...
  • Page 27 MAIN B PWB 鉛フリー半田 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).

  • Page 28: Exploded View And Parts List

    10. EXPLODED VIEW AND PARTS LIST /F only /N only /K, /U only BK31 MECHA LOADER AND TRAVERSE MAIN PWB TACT SW PWB FRONT PWB POWER PWB HEADPHONE PWB BK81 S10 CTBD3+8JFB SCREW CTB3+10JFB SCREW CTB3+6JR SCREW CTW3+18JR SCREW CTW3+8JR SCREW CTB4+6FFZR SCREW...
  • Page 29 LEG GOLD/BLACK CKL2A042H11 22 F N 00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11 22 /K1G 00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11 22 /N1B 00M243W057010 00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 30 00M24AW257010 LID TOP COVER (BLACK) CKC1A140K117 19 /N1S 00M24AW257210 LID TOP COVER (SILVER) CKC1A140G14 90M-ZD000440R CONN. CORD CORD PIN CJS4M009X 90M-ZD000510R CONN. CORD CORD PIN CJS4N014Z NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.

  • Page 31: Cd Mechanism (Loader Ass'y)

    PC BOARD,LOADING 9A06966700 MOTOR MOTOR ASSY LOADING 9A06966800 GEAR MIDWAY GEAR (S) 9A07980800 PULLY LOADING PULLY 9A07268600 90M24AW264010 90M24AW264010 BELT LM BELT 9A07980900 SCREW SCREW+B2.6X2.5 9A06967200 NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 32 CD MECHANISM (LOADER ASS'Y)

  • Page 33: Microprocessor And Ic Data

    11. MICROPROCESSOR AND IC DATA IC51 : T5CD2 VREFH P30/TB3IN0/INT3/SDA0 AVSS PZ3/R/W AVCC PZ2/HWR P70/TA0IN PZ1/WR P71/TA1OUT PZ0/RD P72/TA3OUT P27/A7/A23 P26/A6/A22 P73/TA4IN P74/TA5OUT P25/A5/A21 P75/INT0 P24/A4/A20 P80/TB0IN0/INT5 P23/A3/A19 T5CD2 P81/TB0IN1/INT6 P22/A2/A18 P82/TB0OUT0 DVCC LQFP100 P83/TB0OUT1 P84/TB1IN0/INT7 DVSS TOPVIEW P21/A1/A17 P85/TB1IN1/INT8 P86/TB1OUT0 P20/A0/A16 P87/TB1OUT1...
  • Page 34 IC51 : T5CD2 Port Setting Power Port Name I/O Use Name Note Act. init 1 VREFH VREFH ADC power, connect with +5V 2 AVSS 3 AVCC AVCC MCU power, connect with +5V 4 P70/TA0IN /SRAM_WE sram write enable 5 P71/TA1OUT /SRAM_OE sram output enable 6 P72/TA3OUT...
  • Page 35 IC51 : T5CD2 Port Setting Power Port Name I/O Use Name Note Act. init 51 P07/AD7 SRAM_ADD07 sram_address_07 52 P10/AD8/A8 CD_BUS2 receive data from CD DSP 53 P11/AD9/A9 CD_BUS3 send command to CD DSP 54 P12/AD10/A10 CD_BUCK communication clock with CD DSP 55 P13/AD11/A11 CD_CCE communication chip enable with CD DSP...
  • Page 36 IC31 : TC94A70FG Symbol Description Default Remarks － － AVSS3 Grounding pin for 3.3V CD analog circuits. Servo Servo CD–RF Connect to RFRP by Processor CD–RF RFZi Input pin for RF ripple zero-cross signal. 3AI/F 0.033uF RFRP RF ripple signal output pin. 3AI/F Servo Sub beam addition signal or...
  • Page 37 IC31 : TC94A70FG Symbol Description Default Remarks Correction flag output CMOS PORT 3I/F SFSY Servo internal register read clock output pin CMOS PORT 3I/F Internal Audio DAC Zero data detection flag ZDET CMOS PORT output 3I/F CD General Input port(Pull down by 100K GPIN Schmitt input when not in use)
  • Page 38 IC32 : TA2125AF Driver RIN FIN STB IN3 IN4 REG OUT N.C. ´ 3 ´ 3 ´ 3 ´ 3 Control STBY STBY Logic Iref ´ 3 ´ 3 ´ 3 ´ 3 N.C. N.C. N.C. N.C. VCIN IN1 Symbol Function OUT5A Output terminal...
  • Page 39 IC41 : CS4398CZ 3.3 V to 5 V 1.8 V to 5 V Switched Interpolation Register/Hardware Multibit Left Capacitor Hardware or I C/SPI Filter with Configuration Differential ΔΣ Modulator DAC and Control Data Volume Control Output Filter 1.8 V to 5V Switched Interpolation Multibit...
  • Page 40 IC33 : TC74HCU04AFNG IC44 : TC7WH157FU IC45 : TC7WHU04FU...
  • Page 41 IC46 : TC7WH74FU IC47 : BU2630FV...
  • Page 42 IC48 : TC74LS628...

  • Page 43: Electrical Parts List

    12. ELECTRICAL PARTS LIST NOTE ON SAFETY FOR FUSIBLE RESISTOR : PARTS INFORMATION The suppliers and their type numbers of fusible resistors RESISTORS 1) 00MGD05 × × × 140, Carbon fi lm fi xed resistor, ±5% 1/4W are as follows; 2) 00MGD05 ×...
  • Page 44 00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T C805 CER. CAP. 1000PF 50V B HCBS1H102KBT C806 CER. CAP. 1000PF 50V B HCBS1H102KBT C807 00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 45 00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC MAIN C325 00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC MAIN C326 00MDD95680300 CER. CAP. 68PF 50V JA CCUS1H680JA NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 46 CCEA1CH101T MAIN C465 00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T MAIN C466 00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T MAIN C467 00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 47 CONN. 5P STRAIGHT CJP05GA19ZY MAIN CN32 CONN. 6P STRAIGHT CJP06GA19ZY MAIN CN33 CONN. 16P WAFER CARD CABLE CJP16GA117ZY MAIN CN51 CONN. 15P FFC WAFER CJP15GA117ZY NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 48 HOLDER FUSE KJCFC5S MAIN HF92 CONN. HOLDER FUSE KJCFC5S MAIN IC31 90M-HC110060R 90M-HC110060R IC TC94A70FG CD DSP CVITC94A70FG MAIN IC32 90M-HC109470R 90M-HC109470R IC TA2125AFG HVITA2125AFG NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 49 00MHF100741G0 00MHF100741G0 F.E.T. 2SJ74BLT HVT2SJ74BLT MAIN Q709 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT MAIN Q710 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT MAIN Q711 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 50 1M OHM 1/10W J CRJ10DJ105T MAIN R453 00MNN05470610 CHIP RES. 47 OHM 1/10W J CRJ10DJ470T MAIN R454 00MNN05470610 CHIP RES. 47 OHM 1/10W J CRJ10DJ470T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 51 CRD20TJ561T MAIN R710 RES. 10K OHM 1/5W J CRD20TJ103T MAIN R711 RES. 33K OHM 1/5W J CRD20TJ333T MAIN R712 RES. 100 OHM 1/5W J CRD20TJ101T NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 52 10K OHM 1/5W J CRD20TJ103T POWER RY95 00MLY10120400 00MLY10120400 RELAY ! POWER RELAY G5PA-1 5A OMRON CSL1E002ZE POWER T951 90M-TS003150R TRANSF. # TRANSF. POWER CD6002 100V/50HZCLT5N035ZJ NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
  • Page 53 R201 RES. 1.5K OHM 1/5W J CRD20TJ152T TACT R202 RES. 10K OHM 1/5W J CRD20TJ103T TACT S201 90M-SP001400R 90M-SP001400R PUSH SW TACT SW EVQ22505R CST1A023ZT NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.

  • Page 54: About Replace The Microprocessor With A New One

    13. ABOUT REPLACE THE MICROPROCESSOR WITH A NEW ONE When replaced of the U-PRO (Microprocessor) or the Flash ROM, confirm contents of the following. Pos. After Description Remark Name replaced MAIN IC51 T5CD2(F AAD JZ) CD6002 After replaced A : Mask ROM (With software). No need write-in of software to the microprocessor. B : Flash ROM (With software).
