Marantz CD6005 Service Manual

Hide thumbs Also See for CD6005:
Table of Contents

Advertisement

Quick Links

Service
Manual
• For purposes of improvement, specifications and design are subject to change without notice.
• Please use this service manual with referring to the operating instructions without fail.
• Some illustrations using in this service manual are slightly different from the actual set.
S1356V04DM/DG1610
CD6005
Copyright 2016 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.
CD6005 /
U1B/K1B
N1B/N1SG
CD Player
Ver. 4
Please refer to the
MODIFICATION NOTICE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD6005 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marantz CD6005

Summary of Contents for Marantz CD6005

  • Page 1 Service CD6005 / U1B/K1B N1B/N1SG Manual CD Player • For purposes of improvement, specifications and design are subject to change without notice. • Please use this service manual with referring to the operating instructions without fail. • Some illustrations using in this service manual are slightly different from the actual set.

  • Page 2: Table Of Contents

    CONTENTS ABOUT THIS MANUAL .............3 What you can do with this manual ..........3 Using Adobe Reader (Windows version) ........4 SAFETY PRECAUTIONS ............6 NOTE FOR SCHEMATIC DIAGRAM .........7 NOTE FOR PARTS LIST ............7 TECHNICAL SPECIFICATIONS ..........9 DIMENSION ................9 CAUTION IN SERVICING ............10 Initializing CD Player ...............10 Note Handling and Replacement of the Laser pick-up ..11 1.

  • Page 3: About This Manual

    ABOUT THIS MANUAL Read the following information before using the service manual. What you can do with this manual Search for a Ref. No. (phrase) Jump to the target of a schematic diagram connector (Ctrl+Shift+F) You can use the search function in Acrobat Reader to search for a Ref.

  • Page 4: Using Adobe Reader (Windows Version)

    Using Adobe Reader (Windows version) Add notes to this data (Sign) Magnify schematic / printed wiring board diagrams - 1 TheSignfunctionletsyouaddnotestothedatain (Ctrl+Space, mouse operation) this manual. Savethefileonceyouhavefinishedaddingnotes. Press Ctrl+Spaceonthekeyboardanddragthe [Example using Adobe Reader X] mousetoselecttheareayouwanttoview. On the "View" menu, click "Sign". • Theselectedareaismagnified.
  • Page 5 Magnify schematic / printed wiring Magnify schematic / printed wiring board diagrams - 2 board diagrams - 3 (Pan & Zoom function) (Loupe Tool function) ThePan&Zoomfunctionletsyouseewhichpartof TheLoupeToolfunctionletsyoumagnifyaspecific amagnifieddiagramisbeingshowninaseparate part of a diagram in a separate window. window. [Example using Adobe Reader X] On the "View"...

  • Page 6: Safety Precautions

    SAFETY PRECAUTIONS The following items should be checked for continued protection of the customer and the service technician. leakage current check Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassis resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the set is defective.

  • Page 7: Note For Schematic Diagram

    NOTE FOR SCHEMATIC DIAGRAM WARNING: Partsindicatedbythe z markhavecriticalcharacteristics.UseONLYreplacementpartsrecommendedbythemanufacturer. CAUTION: Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassisresistancecheck.If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the set is defective. WARNING: DONOTreturnthesettothecustomerunlesstheproblemisidentifiedandremedied. NOTICE: ALLRESISTANCEVALUESINOHM.k=1,000OHM/M=1,000,000OHM NOTE FOR PARTS LIST...
  • Page 8 WARNING AND LASER SAFETY INSTRUCTIONS WARNING WAARSCHUWING Alle IC’s en vele andere halfgeleiders zijn gevoelig All ICs and many other semi-conductors are voor elektrostatische ontladingen (ESD). susceptible to electrostatic discharges (ESD). Onzorgvuldig behandelen tijdens reparatie kan de Careless handling during repair can reduce life levensduur drastisch doen verminderen.

  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS n Audio performance • Analog output Channels: 2 channels Playable frequency range: 2 Hz – 20 kHz Playable frequency response: 2 Hz – 20 kHz (±0.5dB) S/N: 110 dB Dynamic range: 100 dB Harmonic distortion: 0.002 % (1 kHz) Wow &...

  • Page 10: Caution In Servicing

    CAUTION IN SERVICING Initializing CD Player CD Player initialization should be performed when the μcom, peripheral parts of μcom, and CD PCB were replaced. Turn off the power pressing Power operation button. Turn on the AC plug while simultaneously while pressing " 3 " and "DISC/INPUT" buttons. "INITIALIZING"...

  • Page 11: Note Handling And Replacement Of The Laser Pick-Up

    NOTE HANDLING AND REPLACEMENT OF THE LASER PICK-UP 1. Protection of the LD Short a part of the LD circuit by soldering. After connection to a circuit, remove the short solder. 2. Precautions when handling the laser CD mechanism • Handle the laser pick-up so that it is not exposed to dust.

  • Page 12: Disassembly

    DISASSEMBLY • Disassemble in order of the arrow in the following figure. • In the case of the re-assembling, assemble it in order of the reverse of the following flow. • In the case of the re-assembling, observe "attention of assembling". •...

  • Page 13: Front Panel Assy

    1. FRONT PANEL ASSY Proceeding : TOP COVER → FRONT PANEL ASSY (1) Tray is opened and CD DOOR is removed. View from the bottom View from the CD MECHA bottom (2) Remove the screws. Shooting direction: D View from the bottom Shooting direction: C (3) Cut the wire clamp band, then remove the style pin and screws.

  • Page 14: Cd Main P.w.b

    2. CD MAIN P.W.B Proceeding : TOP COVER → CD MAIN P.W.B (1) Remove the style pin and screws. Disconnect the connector wires and FFC cable. CWC101 CWC100 STYLE PIN CN2101 CN2801 CN1101...

  • Page 15: Power Pwb

    3. POWER PWB Proceeding : TOP COVER → POWER PWB (1) Remove the style pin and screws. Disconnect the connector wires. CN3903 STYLE PIN CN3504 CN3902 CN3901 CN1101 4. AUDIO OUTPUT PWB Proceeding : TOP COVER → AUDIO OUTPUT PWB (1) Remove the style pin and screws.

  • Page 16: Mecha Assy

    5. MECHA ASSY Proceeding : TOP COVER → FRONT PANEL ASSY → MECHA ASSY (1) Remove the screws. (2) Laser short-circuit in Pick-up of CD MECHANISM ASS'Y, then disconnect the connector wires and FFC cable. Be sure to wear a grounding band. Disconnect the connector wire.

  • Page 17: Special Mode

    SPECIAL MODE Special mode setting button Turn on the AC plug while pressing the button of b No.1 - 8 : A and B at the same time. Mode Button A Button B Contents Version display mode DISC/INPUT PLAY Firmware versions such as Main or USB are displayed in the FL. VFD check mode DISC/INPUT STOP...

  • Page 18: Version Display Mode

    1. Version display mode Turn on the AC plug while pressing the button of " " and " ". DISC/INPUT Now, press the " " or " " button, following information is displayed on the FL tube. 8 / 6 7 / 9 Display Order Version of System μ-com →...

  • Page 19: Cd Test Mode

    4. CD test mode Turn on the AC plug while pressing the button of " " and " ". 8 / 6 To exit, turn off. : Blink Detail of the CD test mode Mode Button / Operation Disc loading Servo check LD ON FOCUS ON...
  • Page 20 4.2. Servo check • Press the " 1 " button. Execute the following steps. (1) LD ON (with servo still stopped) (2) FOCUS ON (disc rotation, tracking off) If no disc loaded, retry then stop. (3) CLV ON (4) TRACKING ON (5) SUB CODE readout (playback sound output) : Blink z @@ : T.No...
  • Page 21 4.6. Adjustment value display • When the " 2 " button is pressed, the adjustment values are displayed. (After All Servo on) • Press the " " button is pressed, the adjustment value are displayed int the following order. 7 / 9 (1) FOCUS BALANCE X X X X (2) FOCUS GAIN...

  • Page 22: Cd Heart Run Mode

    5. CD heart run mode • Set the disc in the tray. Turn on the AC plug while pressing the button of " " and " 2 ". 8 / 6 • If an error occurs, display the error and stop operation at that point. Number of operations held. See "Error display". Heat run count cleared when "...
  • Page 23 5.3. Error display E1-00 : Disc cannot be detected E1-01 : Tracking offset adjustment not possible E1-02 : Focus offset adjustment not possible E2-00 : Focus servo dropped during playback E2-01 : Focus servo dropped during searching E2-03 : Focus servo dropped during TOC reading E2-06 : Focus servo dropped during manualsearch E2-10 : Subcode can no longer be read during playback E2-11 : Subcode can no longer be read during searching...

  • Page 24: Laser On Time

    6. Laser on time Turn on the AC plag while pressing the " " and " 3 " button on this unit. 8 / 6 • One count corresponds to 10 minutes. (Values under 10 minutes are discarded.) • When the time exceeds 10922 hours, the stored data is not updated and the value is fixed 10922. Initialization of a count value •...

  • Page 25: About Replace The Microprocessor With A New One

    ABOUT REPLACE THE MICROPROCESSOR WITH A NEW ONE When replaced of the U-PRO (Microprocessor) or the Flash ROM, confirm contents of the following. After PWB Name Ref. No. Description Remark replaced IC302 TMPM330FWFG SOFTWARE:Main After replaced A : Mask ROM (With software). No need write-in of software to the microprocessor. B : Flash ROM (With software).

  • Page 26: Update For Ic302(Tmpm330Fwfg)

    1. Update for IC302(TMPM330FWFG) (1) Connection of SPK-581, PC and the unit. See "Connect SPK-581 Page)" (2) Turn on the unit. (3) Double click BootTool_M330, and launch the Boot Tool_M330. (4) Choose the Serial port number in the COM z Port. Turn on the unit.
  • Page 27 (5) If successful communication between PC from the unit, "Connected" will be displayed. Connecting target... Connected (6) Click Ram File [...] button. Then choose the "OnBoard_M330.s32". Click Open button. Connecting target... Connected...
  • Page 28 (7) Click "Flash File [...]". Choose the "Hex File ( z .S32)". Choose the "CD6005_20130528-01.s32". Click Open button. Connecting target... Connected OnBoard_M330_RamFile.s32 (8) Click Start button. Connecting target... Connected OnBoard_M330_RamFile.s32 CD6005_130528-01.s32 Start...
  • Page 29 (9) If the software is updated successfully, "OK." appears. Click OK. Disconnect mains cord from the unit, and then disconnect FFC of connection JIG from the unit. (10) Initializing the unit. Remove the AC plug. Turn on the AC plug while pressing the button of " "...

  • Page 30: Trouble Shooting

    TROUBLE SHOOTING 1. POWER 1.1. Power not turn on When the power turned on, Power not turn on. does the ON/STANDBY indicator on the front panel flashing red? Is the CUP12552Z_A-3 POWER B'D connector disconnected? Insert any disconnected connectors. • N3901,N3902,N3903 Is the CUP12551 MAIN B'D connector disconnected? Insert any disconnected connectors.

  • Page 31: Fld

    2. FLD 2.1. FL TUBE dosen't light Is the CUP12551 MAIN B'D Is the input voltage (+49.3V) of FL TUBE Check the circuit and soldering of VP output voltage (+25V) the CUP12552Z_A-3 POWER dosen't light. the transistor (Q3901) and output normal? B'D transistor collector normal? load, and replace any faulty parts.
  • Page 32 2.2. FLD Control Waveform DIS_CD DIS_SCL(CP) DIS_SO(DA) 2.3. Remote control is not accepted Remote control is not accepted. Check the U3904 input voltage of the Is the power voltage (FST+3.3V) CUP12552Z_A-3 POWER B'D, and the other of the CUP12552Z_A-4 FRONT circuits and soldering that handle the output B'D remote control sensor (U4001) load.

  • Page 33: Sound

    3. NO SOUND 3.1. No sound is output when a CD is played back No sound is output when a CD is played back. Is the CUP12551 MAIN B'D connector Insert any disconnected disconnected? connectors. • CWC100, CWC101, PFCK10, N2101, N2801 Is the CUP12552Z_A-3 AUDIO B'D connector Insert any disconnected disconnected?
  • Page 34 3.2. DAC Input Signal Waveform MCLK DATA LRCK...
  • Page 35 3.3. No sound is output when a USB, iPod is played back No sound is output when a USB, iPod is played back. Is the CUP12551 MAIN B'D connector disconnected? Insert any disconnected connectors. • CWC100, CWC101, CN1101, N2101, N2801 Check the regulator (U3901) +3.3V_D of the Is the CUP12551 MAIN B'D USB DSP IC power supply normal? CUP12552Z_A-3 POWER B'D and the circuits and...
  • Page 36 Is the CUP12551 MAIN B'D DAC IC digital input Check the following IC of the CUP12551 MAIN B'D and the signal normal? circuit and soldering that handle the output load, and replace • IC304 3pin (DATA) any faulty parts. • R160 (BCK) •...

  • Page 37: Measuring Method And Waveforms

    MEASURING METHOD AND WAVEFORMS Measuring Disc: 4822 397 30184 TCD-784 (It is better to use wires for extending between the probe and test points.) CUP12551 MAIN B'D ASSY: TEST POINT Dipping BK201 C300 Q308 Q307 K100 R300 K300 R314 C301 D304 C323 C322...
  • Page 38 WAVEFORMS 1. DISC PLAY RF WAVEFORM（EYE-PATTERN） 2. DISC DETECTION 1.1 CD（TCD-784）Play 2.1 CD（TCD-784）DISC DETECTION ②RFO 200mV ③FSMONIT ④FOO ①RFEQO 500Mv ⑤TEI ⑥ TRO ⑦FMO ⑧DMO 2.2 CD-R（TCD-R000RM）DISC DETECT 1.2 CD-R（TCD-R000RM）Play ②RFO 200mV ③FSMONIT ④FOO ①RFEQO 500Mv ⑤TEI ⑥ TRO ⑦FMO ⑧DMO 2.3 CD-RW（TCD-W000RM）DISC DETECTION 1.3 CD-RW（TCD-W000RM）Play...
  • Page 39 3. TOC READ 4. FOCUS ADJUSTMENT 3.1 CD（TCD-784）TOC READ 4.1 CD（TCD-784）FOCUS ADJUSTMENT ②RFO ③FSMONIT 200mV ④FOO ⑤TEI 500Mv ⑥ TRO ⑦FMO ⑧DMO 3.2 CD-R（TCD-R000RM）TOC READ 4.2 CD-R（TCD-R000RM）FOCUS ADJUSTMENT   ②RFO ③FSMONIT 200mV ④FOO ⑤TEI 500Mv ⑥ TRO ⑦FMO ⑧DMO 3.3 CD-RW（TCD-W000RM）TOC READ 4.3 CD-R（TCD-R000RM）FOCUS ADJUSTMENT ②RFO  1V...
  • Page 40 Personal notes:...

  • Page 41: Block Diagram

    BLOCK DIAGRAM CD MECHA UNIT +3.3V_D KT-690 +3.3V_D1 +3.3V_D2 +1.5V_D1 +1.5V_D2 VREF DSP_MCK TC74VHCU04FT +3.3V_D HDAM LPF HDAM-SA2 +5V_D ANALOG Lch 16.9344MHz CD DSP TC94A92FG-301 D/A_MCK CD_LRCK CD_LRCK MUTE +7V_DRV CD_SCLK CD_SCLK CS4398 LOAD+ +3.3V_D1 LOAD- VREF ANALOG Rch U1002 MOTOR VREF DRIVER...

  • Page 42: Power Diagram

    電源ダイヤグラム POWER DIAGRAM CD6005 CURRENT BLOCK DIAGRAM 2012.10.17 : HEATSINK 2SD2081 +12V 0.12 W A+14V A-14V A+12V A-12V +14V OP AMP 30 mA 30 mA 2SD2081 HEADPHONE 2SB1259 OP AMP OP AMP HP OP AMP 0.15A 0.15A 30 mA 30 mA...

  • Page 43: Wiring Diagram

    配線ダイヤグラム WIRING DIAGRAM...

  • Page 44: Printed Wiring Boards

    基板図 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 PRINTED WIRING BOARDS Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu). MAIN (A SIDE) MAIN (B SIDE) Dipping BK201 C 1 3 Q308 C300 Q307 R300 K100 C 1 4 K300 R314 C301 D304 C323 C322 S300...
  • Page 45 POWER (A SIDE) AUDIO (A SIDE) FLASHER (A SIDE) TRANS (A SIDE) CUP12552Z_A-3 CUP12552Z_A-1 CUP12552Z_A-2 B3502 Z3503 Z4001 Z3501 D3110 Z3911 C3921 BN2101 D3933 R3915 ADJ-1 ADJ-2 BN3902 D3931 C3926 R3133 BAR CODE LABEL CN3903 CN3301 BN3903 R3912 D3930 Pri. Sec.
  • Page 46 TRANS (A SIDE) FLASHER (A SIDE) AUDIO (A SIDE) POWER (A SIDE) C3507 L3304 Q3116 Q3118 R3601 Q3117 C3602 Q3101 C3925 Q3201 C3920 C3501 R3921 R3920 R3922 Fuse C3502 C3503 R3903 C3912 Sec. Pri. C3903 C3909 U3901 C3904 EARPHON (A SIDE) C3907 C4306 C4307...

  • Page 47: Schematic Diagrams (1/4)

    TO A1 TO MAIN FCC300 FCB300 U4003 16-ST-103GINK B4001 FST+3.3V C4002 0.1uF FDGND OPEN C4015 100P C4016 100P FCHGND C4017 100P 0.1uF C4007 FCHGND +42V LDGND2 FDGND DIS+3.3V FST+3.3V Q4102 KRA102S FDGND CHG_LED Q4101 CHG_LED KRA102S FST+3.3V STBY-LED FST+3.3V FST+3.3V STBY-LED R94EV1A U4001...

  • Page 48: Sch02_Power_Audio_Output_Unit

    +12V 1SS133MT 1SS133MT ST+10V D3111 D3112 C3120 1000uF/25V (ELNA RA3) AUDIO OUTPUT UNIT Q3303 Q3117 CN3101 Q3112 KSC1845FTA Q3111 KSC1845FTA KRA104S Q3118 Q3106 KSA992FTA KRC104S KSA992FTA Q3104 Q3116 KRC104S KSA992FTA Z3504 R3121 Q3101 STYLE_PIN Q3301 Q3109 R3106 OPEN KSA992FTA Z3503 KSA992FTA D3110 1SS133MT...

  • Page 49: Sch03_Dig_Main_Cpu

    [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] ST+5V S300 D304 Q300 1SS355T GND_D HVTKRC102S Q301 ST+3.3V GND_D REMOTE_IN Q302...

  • Page 50: Sch04_Main_Cd_Dsp_Usb

    [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] [1,2] R111 +3.3V_D1 +1.5V_D1 R170 GND_DA GND_D R142 VREF C149 1000P C129 R143...

  • Page 51: Exploded View

    EXPLODED VIEW Please refer to the last chapter for the part list. WARNING: Parts marked with this symbol z have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.
  • Page 52 Personal notes: Personal notes:...

  • Page 53: Packing View

    PACKING VIEW Please refer to the last chapter for the part list. UK plug (UK Only)

  • Page 54: Semiconductors

    SEMICONDUCTORS Only major semiconductors are shown, general semiconductors etc. are omitted to list. The semiconductor which described a detailed drawing in a schematic diagram are omitted to list. 1. IC's TMP92FD23AFG (IC302) MAIN MCU PORT MAP Symbol Pin Name I/O Pu/Pd STBY Description 1 AN10/PD6 unused...
  • Page 55 Symbol Pin Name I/O Pu/Pd STBY Description 36 TBINT1/PH3 USB_CTS usb cts control 37 PB4 IPOD_SCL ipod chip clk pin 38 TB0OUT/TP1 IPOD_RESET ipod chip reset pin 39 INT6/PJ6 unused 40 TB1OUT/PI1 unused 41 PB5 IPOD_SDA control ipod chip date pin 42 TB2OUT/PI2 DIT_PDN ak4104 power...
  • Page 56 TC94A92FG (IC17) TC94A92FG (IC100) DCD-710AE...
  • Page 57 TC94A92FG Terminal Function TC94A92FG Terminal Function Symbol Description Default Remarks DSP VCO - EFM and PLCK Phase difference VCoi signal output pin. 3 state output 3AI/F (DSP VCO control voltage inputr pin.) CD-DSP-Power supply for 3.3V RF RVDD3 amplifier core and PLL circuit Connect capacitor according with se SLCo EFM slice level output pin...
  • Page 58 Symbol Description Default Remarks Focus Error signal / Sub beam add signal FSMoNiT 3AI/F output pin(monitor pin/GND) RFZi 3AI/F RFRP 3AI/F Bulit-in serises R=500 Connect to VRo by 3AI/F capacitor. AVDD3 Power supply pin for 3.3 V CD analog circuits. Bulit-in serises R=3.3 k 3AI/F Bulit-in output R=3.3 k...
  • Page 59 Symbol Description Default Remarks DVSS3R Grounding pin for 3.3V Muiti-Bit DAC circuit R channel audio output pin of Audio DAC. 3AI/F DVDD3R Power supply pin for 3.3V Audio DAC circuit. DVDD3L Power supply pin for 3.3V Audio DAC circuit. L channel audio output pin of Audio DAC 3AI/F DVSS3L Grounding pin for 3.3V Muiti-Bit DAC Circuit...
  • Page 60 Default Symbol Description Remarks VDD3 Power Supply pin for 3.3V Digital circuit CMOS Port Schmitt input BUS0 Microprocessor I/F data input/output pin 0 3I/F Refer to [1.2 Pin Assinment Table] CMOS Port Schmitt input BUS1 Microprocessor I/F data input/output pin 1 3I/F Refer to [1.2 Pin Assinment Table] CMOS Port...
  • Page 61 IP4001 (IC14) IP4001 (IC101) (FIN) PGND2 DO4- DO4+ IN4A VCC2 VCC1 DO3+ DO3- DO5- DO5+ IP4001 IP4001 (IC14) (FIN) PGND2 DO4- DO4+ IN4A VCC2 VCC1 DO3+ DO3- DO5- DO5+ (FIN) DO1- DO1+ IN1A MUTE SGND DO2+ DO2- PGND1 REV IP4001 Pin Discriptions SYMBOL DESCRIPTION...
  • Page 62 AK4104 (IC104) MCLK BICK CDTO/ SDTI2 SDTI1 AK4104 LRCK TEST4 View TEST3 CCLK TEST2 TEST1 CDTI AK4104 Terminal Function MCLK µP CCLK Prescaler Interface CDTI CDTO SDTI1 Audio Biphase LRCK Data Encoder Interface BICK Block Diagram MCLK µP CCLK Prescaler Interface CDTI SDTI2...
  • Page 63 UPD63530 (IC105) UPD63530 Terminal Function...
  • Page 65 *For adjustable version only. *For adjustable version only. Figure 1. Typical Application Circuit Figure 1. Typical Application Circuit NCP380 (IC106) ILIM* PAD1 ILIM* FLAG FLAG FLAG ILIM* PAD1 TSOP−5 UDFN6 TSOP−6 (Top view) FLAG FLAG Figure 2. Pin Connections TSOP−5 UDFN6 *For adjustable version only, otherwise not connected.
  • Page 66 CS4398 1. PINOUT DRAWING CS4398 (IC304) DSD_B DSD_A DSD_SCLK SDIN SCLK AMUTEC LRCK AOUTA- MCLK AOUTA+ DGND AGND M3 (AD1/CDIN) AOUTB+ M2 (SCL/CCLK) AOUTB- M1 (SDA/CDOUT) BMUTEC M0 (AD0/CS) VREF REF_GND CS4398 FILT+ CS4398 Terminal Function Pin Name Pin # Figure 1.

  • Page 67: Fl Display

    2. FL DISPLAY V.F.D (FUTABA, 16ST103GINK) (U4003) PIN CONNECTION...
  • Page 68 FRONT_PWR FRONT_PWR PCB ASS'Y NOTE:The symbols in the column Remarks indicate the following destinations. U : North America model N : Europe model K : China model F : Japan model B : Black model SG : Silver gold model REF No.
  • Page 69 FRONT_PWR REF No. Part No. Part Name Remarks Q'ty New Ver U4001 943262010290S SENSOR , REMOTE/U CRVKSM603TH5B U4003 943172100160S V.F.D (FUTABA, 16ST103GINK) CFL16ST103GINK RESISTOR GROUP R3101,3102 RES, CARBON(1/5W,1Kohm,J) CRD20TJ102T R3104,3105 RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T R3107,3108 RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T R3109,3110 RES, CARBON(1/5W,4.7Kohm,J) CRD20TJ472T R3111 00MGD05121160 RES, CARBON(1/5W,120ohm,J)
  • Page 70 FRONT_PWR REF No. Part No. Part Name Remarks Q'ty New Ver R4301 RES, CARBON(1/5W,470ohm,J) CRD20TJ471T R4302 00MGD05104160 RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T R4303 RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T R4304,4305 RES, CARBON(1/5W,56ohm,J) CRD20TJ560T R4306 RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T R4307,4308 00MGD05220160 RES, CARBON(1/5W,22ohm,J) CRD20TJ220T R4309 RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T R4310 RES, CARBON(1/5W,10ohm,J)
  • Page 71 FRONT_PWR REF No. Part No. Part Name Remarks Q'ty New Ver BN2101 WIRE ASS'Y (11PIN,160MM,61205033100AS) CWZCD6004B2101 BN2201 WIRE ASS'Y (3PIN,140MM,61205032800AS) CWZCD6004B2201 BN2801 WIRE ASS'Y (13PIN,80MM,61205032400AS) CWZCD6004B2801 BN3301 WIRE ASS'Y (7PIN,160MM,61205033200AS) CWZCD6004B3301 BN3504 WIRE ASS'Y (5PIN,300MM,61205032600AS) CWZCD6004B3504 BN3902 WIRE ASS'Y (2PIN,200MM,61205032200AS) CWZCD6004B3902 BN3903 WIRE ASS'Y (10PIN,120MM,61205032300AS)
  • Page 72 DSP_MCU DSP_MCU PCB ASS'Y NOTE:The symbols in the column Remarks indicate the following destinations. U : North America model N : Europe model K : China model F : Japan model B : Black model SG : Silver gold model REF No.
  • Page 73 DSP_MCU REF No. Part No. Part Name Remarks Q'ty New Ver R214,215 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R216,217 RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T R218 RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T R300 RES, CHIP(1608/5%/47ohm) CRJ10DJ470T R301 RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T R302-308 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R310 RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T R311 RES, CHIP(1608/5%/47ohm) CRJ10DJ470T R312,313...
  • Page 74 DSP_MCU REF No. Part No. Part Name Remarks Q'ty New Ver C182 CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC C183 CAP, CHIP(1608, 50V/100pF) CCUS1H101JA C184 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C185 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T C186 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C191 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C192 13405012840AS...
  • Page 75 CUP12552Z-3 CD MAIN PCB ASS'Y CUP12551Z POWER PCB ASS'Y CUP12552Z-2 ！ C9 00MYJ04002640 AC INLET ASSY CJJ8A006ZW FLASHER 421410006004M BADGE , MARANTZ CGB1A206 943415100410M ORNAMENT, DOOR BLACK CGR1A552ZB37 943415100400M ORNAMENT, DOOR CGR1A552RMZD10 943416101150M WINDOW , FIP CGU1A423A12Y PANEL , SUB CD5003/N1B...
  • Page 76 PACKING PACKING NOTE:The symbols in the column Remarks indicate the following destinations. U : North America model N : Europe model K : China model F : Japan model B : Black model SG : Silver gold model REF No. Part No.
