- Page 1 TGB 1620 TGB1620T B AT T E RY S C R U B B E R D RY E R Owner Instructions Warning! Read instructions before using the machine www.numatic.co.uk...
-
Page 2: Table Of Contents
TGB 1620 B AT T E RY S C R U B B E R D RY E R Index Machine Overview ........ Pages 2-3 PLEASE READ Control Panel Overview ........ Page 4 BEFORE COMMENCING Machine Set up Guide ........ Page 5 OPERATION Fitting the Brush / Pad ........ -
Page 3: Machine Overview
Machine Overview For Traction Drive Twintec see pages 15 & 16... -
Page 4: Control Panel Overview
Battery Charge Level Indicator Vacuum Pick Up On / Off Water Flow On / Off Brush On / Off / Control Handle In the event of a breakdown contact your Numatic dealer or the Numatic Technical help line +44 (0)1460 269268... -
Page 5: Machine Set Up Guide
Machine Set-up Guide PLEASE READ BEFORE COMMENCING ANY OPERATION AFTER THE REMOVAL OF ALL THE PACKAGING, CAREFULLY OPEN AND CHECK THE CONTENTS. TGB 1620 CONTENTS Use handle grip when raising or lowering the ● 2 x Ignition Keys ● 2 x 40 Amp Fuse top waste-tank. -
Page 6: Fitting The Brush / Pad
Machine Set-up Guide ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF BEFORE MAKING ANY ADJUSTMENTS Fitting the Brush / Pad / Turn on water 550mm Brush or a 500mm Pad on the TGB 1620. Featuring the Nulock brush system. The brush is simply pushed and twisted to lock, making fitting and removal a simple process. Slide the brush / pad under the brush deck. -
Page 7: Fitting The Hose Guide
Machine Set-up Guide Fitting the Hose Guide The vacuum hose has a U-bend clip which creates a U-bend in the hose preventing water spillage when the vacuum is switched off. If you need to remove the U-bend clip for any reason always ensure it is refitted correctly before you resume operation. NOTE: DO NOT push the vacuum hose onto the floor tool with the floor tool in the raised position. -
Page 8: Fill Level Indicator
Machine Set-up Guide Fill Level Indicator The water level in the clean-water tank can be measured using the scale on the left rear side of the machine. The clean water bottom tank holds 60 litres. NOTE: always ensure that the waste water tank is empty before lifting. -
Page 9: Lowering The Floor Tool
Machine Operation Raising/Lowering the Floor Tool After preparing the floor (see previous section), we are now ready to set the controls to suit the cleaning conditions. Before any settings can be applied, ensure the brush deck is lowered. Move the floor tool lever to its lower position. NOTE: Do not pull the machine backwards with the floor tool in the lowered position, this could possibly... -
Page 10: Brush Pressure
Machine Operation Brush Pressure / Load Adjustment The brush load lever is located to the right hand side of the machine. This option is for hard to clean patches, adding extra pressure to the brushes. NOTE: It is recommended this option is NOT used all the time and is for spot cleaning only. The run-time of the machine may decrease if the load on the brushes is increased. -
Page 11: Machine Cleaning
Regular Maintenance ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF PRIOR TO ANY MAINTENANCE USING THE MASTER CONTROL ON/OFF KEY. REMOVE THE KEY PRIOR TO ANY MAINTENANCE OPERATION. After use, empty waste water tank using emptying hose and flush out with clean water. -
Page 12: Changing Floor Tool Blades
Changing the Floor Tool Blades Always ensure that the machine is switched off prior to any maintenance. To clean the floor tool, remove securing-pin and pull-free from the holder. Rinse the floor tool assembly with clean water and refit. Periodically the floor tool blades should be examined and checked for wear and damage. The blade removal is easy. -
Page 13: Machine Charging
The machine charging point is located to the rear of the machine under the control panel. Remove Isolator Plug and connect your external charger. Refit Isolator Plug before operating the machine. Note: Only use the recommended charger and leads. Contact Numatic International Ltd for recommended charger and leads. T 01460 68600... -
Page 14: Battery Care
Battery Care To ensure your machine remains at its maximum efficiency and prolong your battery life, please follow the simple steps below: UNDER NORMAL DAILY USAGE: Re-charge the machine FULLY after each use regardless of machine operation time. Do not leave the machine in a discharged state. Charging Light Sequence Signal (LED) Meaning... -
Page 15: Tgb6055T Operation
Speed Control Dial Forward / Backwards Control Emergency Stop Button Traction Status Light In the event of a breakdown contact your Numatic dealer or the Numatic Technical help line +44 (0)1460 269268 Machine Operation. Ensure the Emergency Stop button is released (Fig.D). - Page 16 Machine Operation Setting the Cleaning Controls Insert the key, turn the main control on / off key to position ‘1’. (Fig.A) The battery charge-level indicator will illuminate for 5 seconds. Set desired traction speed as required, depending on floor type and level of soiling (Fig.B).
-
Page 17: Specifications
Replace fuse & reduce load (page 5) Handle safety fuse blown Replace fuse (or contact service engineer) Failure to rectify the problem or in the event of a breakdown contact your Numatic dealer or Numatic Technical helpline +44 (0)1460 269268 T 01460 68600... -
Page 18: Rating Label / Personal Protective Equipment /Recycling
NOTE: A risk assessment should be conducted to determine which PPE should be worn. Safety Critical Component: In the event of a breakdown contact your Numatic dealer or the Charging Leads: H05VV-F x 1.0 mm x 3 Core Battery Charger: 220V / 240V (50-60Hz) -
Page 19: Safety Precautions
Operators shall be adequately instructed as to the correct use of the machine. If this product does not have a factory installed Numatic battery charger, then it is the responsibility of the owner and user of the product to ensure that the charging system and battery combination are compatible, fit for purpose and safe to use. -
Page 20: Battery Care 14
Undo battery terminals and remove. Remove batteries. The batteries are to be disposed of safely, as according to local government guidelines. 10. Only use genuine Numatic replacement batteries. 11. Do not allow the batteries to become fully discharged; it may not be possible to re-charge them. -
Page 21: Recommended Spare Parts
Spare Parts Part No. BRUSHES Part No. HOSES 606028 550 mm Polyscrub Brush 903325 Hose Closure (Bottom Tank) 606550 550 mm Nyloscrub Brush 903341 Hose Closure ( Filling Hose) 606551 550 mm Long Life Brush 901548 Top Tank Hose (Adjustable Flow) Part No. -
Page 22: Eu Declaration Document
T 01460 68600... - Page 23 Notes T 01460 68600...
-
Page 24: Company Address
Tel: 0861 686 284 www.numatic.co.za Numatic International Schweiz AG. Sihlbruggstrasse 142, 6340 Baar. SCHWEIZ Tel: 0041 (0) 41 76 80 76 - 0 www.numatic.ch Numatic International ULDA. Centro de Negócios da Maia, Rua Albino José Domingues, 581, 4470 – 034 Maia PORTUGAL Tel: +351 220 047 700 www.numatic.pt...
