STEP 9
Push the SWITCH ASSEMBLY (15) into the
BARREL (13) until it stops at the SNAP RING
(14).
STEP 11
Replace the LAMP (10).
421-000-391
STEP 10
Using the HEX WRENCH (22) center the
SWITCH (15) and Tighten the SET SCREW
(21).
STEP 12
Replace the HEAD ASSEMBLY (1).
C & D F l a s h l i g h t
9
ML Rev.1 8/03
