Part Types and specifications
tubing connections
No. of
1
Gas tube: 15.88
Liquid tube:
2
Suspension hook
3
Liquid tube: 9.52
4
Suction tube:
5
Discharge tube:
6
Earth (M5 with washer)
7
Service panel
8
Power outlet
(connected to a 5 m cabtyre
9
cable with connector)
147
9
7
239
• Specifications
Compatibility
Power source
9.52
Power input
Net weight
Accessories
15.88
12.7
1
2
98
52
5.6 ≤ Total capacity of indoor units (kW) < 16.0
Single-phase 200V 50/60Hz (supplied by indoor unit)
25 W
4.7 kg
Washer × 2
Insulating tape
PCB connector × 1
3
8
108 108 111
81
56
426
22
