- Page 1 Digital Force Gauge with RS232 Output 840060 Instruction Manual...
-
Page 2: Table Of Contents
CONTENTS FEATURES ................3 FRONT PANEL DESCRIPTIONS ........4 MEASUREMENT PROCEDURES ........5 Preparations for Measurements ........5 Average Reading Measurements ........6 Peak Load Measurements ..........7 MOUNTING HOLES & OPTIONAL TEST STAND ....7 APPLICATIONS ..............8 Electronics ................ 8 Business Equipment ............ -
Page 3: Features
FEATURES • 5000 gram wide capacity, high resolution, high accuracy, and high repeatability • 3 display units: grams, Newton, or ounces • Tension and compression capabilities • Peak hold (max. load) can be displayed while measuring tension or compression • The “Zero” button works during normal measuring and “peak hold”... -
Page 4: Front Panel Descriptions
FRONT PANEL DESCRIPTION 1 Universal Sensing Head 9 Mounting Holes/ 2 LCD Display Fixing Screws 3 Fast Indicator 10 Battery Cover/ 4 FAST/SLOW Button Compartment 5 LCD Reverse 11 Flat-Head Adapter Display Button 12 Cone Adapter 6 Zero Button 13 Chisel Adapter 7 g/oz/Newton Unit Switch 14 Hook Adapter 8 Power Off/On/Peak Hold... -
Page 5: Measurement Procedures
MEASURMENT PROCEDURES Measuring Consideration The Tension & Compression measuring function is executed automatically. When making the compression measurement, the display will show the ‘”-” mark automatically. When making the measurement, the SENSING HEAD along with the adapter has to be on a line with the measuring object. (ref. -
Page 6: Average Reading Measurements
Normal Measurement • Slide the “PowerOff/On/Peak Hold Switch” (3-8, Fig. 1) to the “On” position. • Determine display unit of g, oz or Newton by selecting “g/oz/ newton Unit Switch” (3-7, Fig. 1). • Connect “Sensing Head” (3-1, Fig. 1) with proper “Adapter”... -
Page 7: Peak Load Measurements
Peak Hold Measurement The meter can measure the peak value of force both of tension & compression operation. The operation procedures of Peak Hold Measurement are the same as above “Normal Measurement” but slide the “Power Off/On/Peak Hold Switch” (3-8, Fig. 1) to the “PEAK H” position. Sliding the “Power Off/On/Peak Hold Switch”... -
Page 8: Applications
APPLICATIONS Electronics • Test strength of solder points and spot welds on circuit boards. • Pull test external leads bonded to ceramic substances. • Test wire wraps on clip connections. • Test pull strength of modified wire wrap connection on posts. •... -
Page 9: Machinery & Manufacturing
• Test crush strength of pills (medicine). • Test peel strength of adhesives. • Measure compression of ceramic compounds. • Test vacuum take-down pressure on process machines. Machinery & Manufacturing • Test load on wire reel. • Test force to open cabinet doors. •... -
Page 10: Battery Replacement
• Test integrity of seals on blister packages and plastic bags. • Test pressure of surgical instruments (forceps, scissors) • Test fruit removal force and fruit firmness. • Measure force on spindles of photographic equipment. Battery Replacement • When it is necessary to replace the battery (battery voltage less than approx. - Page 11 Overload Max. 7 kg. Capacity Zero Control Max. full capacity Circuit Exclusive microprocessor LSI-circuit Full Scale Approx. 2.0 mm max. Deflection Power 6 x 1 .5 V AA (UM-3) size battery or DC 9V Supply adapter (not included) Power Approx. DC 24 mA Consumption Transducer Exclusive load cell...
-
Page 12: Warranty
WARRANTY Sper Scientific warrants this product against defects in materials and workmanship for a period of five (5) year from the date of purchase, and agrees to repair or replace any defective unit without charge. If your model has since been discontinued, an equivalent Sper Scientific product will be substituted if available.
