SmartNode 4130 User Manual
Introduction
This section provides information on the cables used to connect the SmartNode to the existing network infra-
structure and to third party products.
Serial Console
The SmartNode can be connected to a serial terminal over its serial console port, as depicted in
CAUTION
CAUTION
Console Connection settings:
•
19200 Bps
•
8bits, no parity
•
1stop bit
•
flow control off
Note
See section
Introduction
The interconnecting cables shall be acceptable for external use
and shall be rated for the proper application with respect to volt-
age, current, anticipated temperature, flammability, and
mechanical serviceabilty.
For the ISDN connection to a carrier network, it shall be con-
nected to a network termination device and not connected
directly to an outside POTS line.
I 0
B R
/ 3
I 0
B R
/ 0
H 0
E T
B
U S
s e
t
o le
R e
n s
C o
1 A
V ,
1 2
Note
A Patton Model 16F-561 RJ45 to DB-9 adapter is included with
each SmartNode Series device
Figure 9. Connecting a serial terminal
"Console port"
on page 47 for console port pin-outs.
/ 0
I 0
B R
/ 1
I 0
B R
/ 2
Serial Terminal
C • Cabling
figure
9.
43
