SmartNode 4130 User Manual

SmartNode 4130 Rear Panel

The SmartNode 4130 is a compact ISDN VoIP gateway that supports eight VoIP or Fax calls, by using either
G.711, G.722, T.38 or any other codec as indicated on the Datasheet. The SmartNode 4130 rear panel ports
are described in table 2.

Ports descriptions

The SmartNode 4130 Series rear panel ports are described in
Port
ETH 0/0
USB 2.0
BRI 0/0 - BRI 0/3
SmartNode 4130 Overview
Figure 2. SN4130 Rear Panel
Table 2. Rear panel ports
Auto-MDX Fast/Gigabit-Ethernet port, RJ45 (see
unit to an Ethernet WAN device (for example, a cable modem, DSL
modem, or fiber modem).
USB 2.0 host port (see
Modem. A list of supported USB Models can be found in the release
notes and in the Software Configuration Guide
ISDN BRI TE/NT port, RJ-45 socket S0/T0 interface (see
nects the SmartNode with an ISDN device over an S/T bus, e.g. a PBX or
an NT.
The port can be switched between TE and NT mode.
The interface is internally terminated with 100 Ohm.
Point-to-point or point-to-multipoint configurable. If the port is in NT
mode, a phantom power supply can be switched on to supply connected
phones with power.
table 2.
Description
figure 2) to connect a USB 3G/4G Cellular
1 • General information
figure 2), connects the
figure 2), con-
16
