REPAIR AND MAINTENANCE
❑ Front Tire Replacement
Tools required: 10mm wrench, two (2) 17mm wrenches and a fl athead screwdriver.
1 (E100 Only)
Loosen
the brake pad bolt and remove
one brake pad.
E_Series_Manualv10.indd 10
2
Using two 17mm wrenches,
loosen the front axle bolts by
turning the wrenches counter
clockwise.
3
Remove wheel and replace
tire. To reinstall wheel, reverse
these steps. Helpful hint: You
may need to use a fl athead
screwdriver to center the axil
and the bolts.
9
