Summary of Contents for Razor E100

Page 1 OWNER’S MANUAL Read and understand this entire manual before riding! DO NOT RETURN TO STORE! NOTE: E100/125/150 must be traveling 3mph before motor will engage. Kick start to 3mph then twist the throttle to start motor. Item Numbers E100 13100E-BL...
Page 2: Table Of Contents
Do not attempt or do stunts or tricks on your E100, E200 or E300 scooter. The scooters are not made to withstand abuse from misuse such as jumping, curb grinding or any other type of stunts.
Page 3: Estimated Assembly/Set-Up Time
6mm hexagonal key wrench (included) Need Help? Visit our web site for updates and a list of authorized service centers at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM Paciﬁc Time. Brake Lever Adjuster...
Page 4: Assembly And Set-Up
ASSEMBLY AND SET-UP ❑ Charging the Battery Your electric scooter may not have a fully charged battery. Therefore it is a good idea to charge the battery prior to use. • Initial charge time: 12 hours • Recharge time: up to 8 hours, Battery should be recharged a minimum of 8 hours after each use.
Page 5: Riding Your Scooter
5. Note: The E100 must be going 3 mph before the motor will start. Kick to 3 mph then activate the speed control while simultaneously pressing the green“go” button to engage the motor.
Page 6: Inﬂating Tires
Inﬂate to of purchase. the PSI indicated on the tire sidewall. E150 / E200 / E300 Front Tire and E100 Tires Using a bicycle style tire pump equipped for a Schrader- type valve, inﬂate the front tire to the PSI indicated on the sidewall of the tire.
Page 7: Adjusting The Chain
BMX bicycles. If you are not familiar with it or do not feel comfortable performing the ad- justment, consult an authorized Razor service center or a quali- ﬁed BMX bike or motorcycle mechanic. The chain should be “just taut” – in other words snug, but not piano-wire tight.
Page 8 REPAIR AND MAINTENANCE ❑ Chain and Rear Tire Replacement Tools required: Phillips screwdriver, 10mm wrench, two (2) 8mm wrenches, and two (2) 17mm wrenches. With a Phillips screwdriver, loosen the two screws and loosen the brake cable anchor remove the chain guard. and disconnect the cable.
Page 9 REPAIR AND MAINTENANCE Install the axle adjusters and axle nuts. Tighten until they ers the same number of turns just barely hold the hardware to ﬁne-tune the tension on the in place. chain and to approximately maintain the centering of the wheel.
Page 10 REPAIR AND MAINTENANCE ❑ Front Tire Replacement Tools required: 10mm wrench, two (2) 17mm wrenches and a ﬂathead screwdriver. (E100 only, other loosen the front axle bolts by models go to Step 2) Loosen the brake pad bolt and turning the wrenches counter clockwise.
Page 11: Repair And Maintenance
CONTAINS SEALED LEAD BATTERY. BATTERY MUST BE RECYCLED. Disposal: Your Razor product uses sealed lead-acid batteries which must be recycled or disposed of in an environmentally sound manner. Do not dispose of a lead-acid battery in a ﬁre. The battery may explode or leak.
Page 12: Troubleshooting Guide
Make sure you do not overload the scooter by allowing more than one rider at a time, exceeding the E100 120 lb. or E200 and E300 220 lb. maximum weight limit, going up a hill or towing objects behind the scooter.
Page 13 Brake rotor is dragging on brake pads Need Help? Visit our web site for updates and a list of authorized service centers at www.razor.com Need Help? Visit our web site for updates and a list of authorized service centers at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM Paciﬁc Time.
Page 14: E100, E150, E200 And E300 Scooter Parts
E100 PARTS Keep your scooter running for years with genuine Razor parts. Visit our web site or e-mail us for more information on spare part availability. (Speciﬁcations subject to change without notice.) 1 Grip, right side no ﬂange 2 Anti-friction Spacer, throttle...
Page 15 E100 PARTS...
Page 16: E150 Parts
E150 PARTS Keep your scooter running for years with genuine Razor parts. Visit our web site or e-mail us for more information on spare part availability. (Speciﬁcations subject to change without notice.) 1 Front wheel assembly 1-1 Axle Nut 1-2 Washer...
Page 17 E150 PARTS �� ...
Page 18 E200 PARTS Keep your scooter running for years with genuine Razor parts. Visit our web site or e-mail us for more information on spare part availability. (Speciﬁcations subject to change without notice.) Grip, right side no ﬂange Anti-friction spacer, throttle...
Page 19 E200 PARTS...
Page 20 E300 PARTS Keep your scooter running for years with genuine Razor parts. Visit our web site or e-mail us for more information on spare part availability. (Speciﬁcations subject to change without notice.) Grip, right side no ﬂange Anti-friction spacer, throttle...
Page 21 E300 PARTS...
Page 22 SB 1918 (CALIFORNIA) DECLARATION YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING THE USE OF THIS SCOOTER/ELECTRIC VEHICLE. TO DETERMINE IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT.
Page 24: Safety Gear
Need Help? Visit our web site for updates and a list of authorized service centers at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM Paciﬁc Time.
