4.2.2 Configuration Registers

Register Address
(protocol address)
13
14
15
21
48
49
50
7
If the register is configured as "0:Non-blocked", all commands received from Modbus will be sent to the AC system. If "1: Blocked",
commands from Modbus will only be sent to the AC system if they differ from the previous value.
8
This register applies to firmware version 2.5 onwards
9
Once window contact is open, a count-down to switch off the AC Unit will start from this configured value.
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
IntesisBox
®
is a registered trademark of Intesis Software SLU
FJ-RC-MBS-1
Register Address
(PLC address)
32
35
65
66
82
98
99
Register Address
(PLC address)
14
15
16
22
49
50
51
R/W
Description
Status (feedback)
R
0: Not active (Default value)
1: Active (A window is open)
Left/Right Vane pulse
W
1: Pulse
Economy
R/W
0: Disabled
1: Enabled
Input reference temperature
0x8000: No temperature's value is being
R
provided from an external sensor. No virtual
temperature is being applied.
Any other: (ºC/x10ºC/ºF)
Error address
R
Provides the indoor unit number which is
providing error
Block Periodic Sendings
R/W
0: Non-blocked (Default value)
1: Blocked
Master/Slave (gateway's role)
R
0: Slave
1: Master
R/W
Description
"Open Window" switch-off timeout
R/W
0..30 (minutes)
Factory setting: 30 (minutes)
Modbus RTU baud-rate
2400bps
4800bps
9600bps (Default)
R
19200bps
38400bps
57600bps
76800bps
115200bps
Modbus Slave Address
R
1..63
R
Max number of fan speeds
R
Switch value
R
Device ID: 0x0D00
R
Software version
URL
Email
Phone
User's Manual r1.9 EN
1,2,3
4,7,8
9
http://www.intesisbox.com
info@intesisbox.com
+34 938047134
9/24
