4.4 Implemented Functions

FJ-RC-MBS-1 implements the following standard Modbus functions:
3: Read Holding Registers
▪
4: Read Input Registers
▪
6: Write Single Register
▪
16: Write Multiple Registers (Despite this function is allowed, the interface does not
▪
allow to write operations on more than 1 register with the same request, this means that
length field should be always be 1 when this function is being used in case of writing)

4.5 Device LED indicator

The device includes two LED indicators to show all the possible operational states. In the
following table there are written the indicators which can be performed and their meaning.
L1 (green LED)
Device status LED indication
During not normal
LED blinking
operation
During normal
LED flashing
operation
L2 (red LED)
Device status LED indication
During not normal
LED Pulse
operation
L1 (green LED) & L2 (red LED)
Device status LED indication
During normal
LED Pulse
operation
LED alternatively
During not normal
operation
blinking
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
IntesisBox ® is a registered trademark of Intesis Software SLU
FJ-RC-MBS-1
ON / OFF Period
500ms ON / 500ms OFF
100ms ON / 1900ms OFF
ON / OFF Period
3sec ON / --- OFF
ON / OFF Period
5sec ON / --- OFF
500ms ON / 500ms OFF
User's Manual r1.9 EN
Description
Communication error
Normal operation (configured and
working properly)
Description
Under voltage
Description
Device Start-up
Flash checksum not OK
