About Webcam Go Plus - Creative Video Blaster Go Plus User Manual

About
WebCam Go Plus
1-2 Installing WebCam Go Plus
Figure 1-1 shows you the front and back views of the camera.
Snapshot button
After you have started
WebCam Go Control,
press this button to
capture a still image.
LED light
Lights up when the
camera is turned
on.
Camera busy LED indicator
When the camera is connected to the
system, this indicator blinks when
commands are sent from the system to
the camera.
When the camera is disconnected, this
indicator blinks briefly after you press and
release the Snapshot button. At this point,
do not shake the camera. The indicator
will remain lit for a while. When the
indicator is turned off, you can take
another snapshot.
Figure 1-1: Front and back views of WebCam Go Plus.
Focus-free Lens
Objects must be at least 2 feet
(61cm) from the lens for the
images to be sharp.
Viewfinder
Front view
Viewfinder (back view)
When taking snapshots with the camera
disconnected, use this to verify that the
object of your snapshot is in view.
Built-in Microphone for
annotation recording
Press the Audio Record
button near the LCD
display to record your
voice or sounds.
Back view
