Sharp UP-600 Programming Manual

Pos terminal
Hide thumbs Also See for UP-600:

Advertisement

Quick Links

See also: Service Manual , Instruction Manual
UP-600
CHAPTER 1. SRV. RESET AND MASTER RESET ........................................ 2
CHAPTER 2. READING OF SRV MODE PROGRAM ..................................... 3
For setting in PGM1 or PGM2 mode, refer to the Operation Manual.
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
UP-700
CONTENTS
SHARP CORPORATION
POS TERMINAL
UP-600
UP-700
MODEL
(For "U" & "A" version)
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.

Advertisement

loading

Related Manuals for Sharp UP-600

Summary of Contents for Sharp UP-600

  • Page 1: Table Of Contents

    POS TERMINAL UP-600 UP-700 UP-600 MODEL (For "U" & "A" version) UP-700 CONTENTS CHAPTER 1. SRV. RESET AND MASTER RESET ........2 CHAPTER 2. READING OF SRV MODE PROGRAM ........3 CHAPTER 3. SRV MODE PROGRAMMING ("2 SETTING")......10 CHAPTER 4. SRV MODE PROGRAMMING ("3 IRC SETTING")....45 CHAPTER 5.
  • Page 2 Symbol/PartsCod) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Major keys used in the SRV mode The following major keys are used in the SRV mode.

  • Page 3: Chapter 1. Srv. Reset And Master Reset

    CHAPTER 1. SRV. RESET AND MASTER RESET The SRV key is used for operating in the SRV mode. MRS-2 (Master resetting 2) Used to clear all memory and keyboard contents. This reset returns all programming back to defaults. The keyboard 1.
  • Page 4 3) Turn on the AC switch. 4) While holding down the JOURNAL FEED key and MRS-3 key, turn to (SRV) position from (SRV’) position. MRS-3 key : UP-600=[CANCEL] key UP-700=[PLU70] key 5) The product serial No. input window is displayed as shown below.

  • Page 5: Chapter 2. Reading Of Srv Mode Program

    Sample of program reports printer DISPLAY: SRV mode screen 1. [1 SYSTEM PRESET] • UP-600 Select "1 READING " and press the Enter key. DISPLAY: READING item selection screen Select the desired item, press the Enter key. The setting content is printed.
  • Page 6 • UP-700 2. [2 DEVICE CONFIG] • UP-600 Report title Device name / Not assigned • UP-700 Report title Device name / Not assigned...
  • Page 7 3. [3 FREE KEY] • UP-600 Report title Key No. / Key text / Key position code Key No. / Key text / Not assigned...
  • Page 8 • UP-700 Report title Key No. / Key text / Key position code Key No. / Key text / Not assigned...
  • Page 9 4. [4 FILE] • UP-600 Report title File table No. / No. of records/ No. of used records File table No. / No. of records / No. of blocks / No. of used records File memory start address Empty memory start address...
  • Page 10 • UP-700 Report title File table No. / No. of records/ No. of used records File table No. / No. of records / No. of blocks / No. of used records File memory start address Empty memory start address Memory end address...
  • Page 11 5. [5 SSP] • UP-600 • UP-700...

  • Page 12: Chapter 3. Srv Mode Programming ("2 Setting")

    CHAPTER 3. SRV MODE PROGRAMMING ( "2 SETTING") DISPLAY: SRV mode screen 1. [01 DEVICE CONFIG] DISPLAY: DEVICE CONFIG select screen Select " 2 SETTING " and press the Enter key. DISPLAY: SETTING item selection screen Select the item to be changed and press the ENTER key. Select the desired item, press the Enter key.
  • Page 13 Symbol/PartsCod) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - [01 DEVICE CONFIG] - [01 R/J PRINTER] DISPLAY: Setting screen [R/J PRINTER] (Built-in printer programming)
  • Page 14 0 : No RS232 channel is assigned. 1-7 : RS232 channel is assigned. PRINTER Connected printer name BUILT-IN BUILT-IN The UP-700 can not be selected "BUILT-IN". (UP-600) (Fixed at "TM-295) TM-295 TM-295 (UP-700) VP TIMES No. of times of VP...
  • Page 15 [01 DEVICE CONFIG] - [05 KP#1] / [06 KP#2] / [07 KP#3] DISPLAY: Setting screen [08 KP#4] / [09 KP#5] / [10 KP#6] [11 KP#7] / [12 KP#8] / [13 KP#9] [KITCHEN PRINTER] KP#1-KP#9 DISPLAY CONTENTS SELECT ITEM NOTE TERMINAL# Terminal No.
  • Page 16 [01 DEVICE CONFIG] - [14 CAT#1]/[15 CAT#2] DISPLAY: Setting screen [CAT#1,CAT#2] DISPLAY CONTENTS SELECT ITEM NOTE TERMINAL# Terminal No. 000-254 000 :Self terminal No. This means local device. 1-254 : Except self terminal No. CHANNEL# Channel No. 0 : No RS232 channel is assigned. 1-7 : RS232 channel is assigned.
  • Page 17 [01 DEVICE CONFIG] - [17 BCR(SCANNER)] DISPLAY: Setting screen [BCR (SCANNER)] DISPLAY CONTENTS SELECT ITEM NOTE CHANNEL# Channel No. 0: No RS232 channel is assigned. 1-7: RS232 channel is assigned. BAUD RATE Transmission speed 4800 bps 4800 bps 9600 bps 19200 bps DATA BITS Data bit...
  • Page 18 [01 DEVICE CONFIG] - [19 COIN DISP.] DISPLAY: Setting screen [COIN DISPENSER] DISPLAY CONTENTS SELECT ITEM NOTE CHANNEL# Channel No. 0 : No RS232 channel is assigned. 1-7 : RS232 channel is assigned. [01 DEVICE CONFIG] - [20 ONLINE] DISPLAY: Setting screen [ONLINE] DISPLAY CONTENTS...
  • Page 19 2. [02 SYSTEM PRESET] DISPLAY: Setting item select screen Select "02 SYSTEM PRESET" and press the ENTER key. DISPLAY: SYSTEM PRESET screen Select the JOB# to be changed and enter the value. The content of each JOB# is described below.
  • Page 20 904-B: 1. Printing of the consecutive No. 2. Decimal point position of gasoline (OIL) q’ty 1. Printing of the 2. Decimal point position of 904-B consecutive No. gasoline (OIL) q’ty 0.00 0.000 0.00 0.000 ... MRS for UP-600 / ... MRS for UP-700 Note :...
  • Page 21 Successive multiplication Quantity Split pricing 1. GST EXPT 905-C FFx (FF sequence + Split pricing) Print Multiplication Skip Successive multiplication Enable Split pricing FFx (FF sequence + Split pricing) ... MRS for UP-600 / ... MRS for UP-700 Note :...
  • Page 22 2. Z1 resetting that resets GT 907-D: Not used (Fixed at "0") 1. Printing of X/Z report 2. Z1 resetting that 908-D resets GT Disable Receipt & Journal Enable Disable Journal only Enable ... MRS for UP-600 / ... MRS for UP-700 Note :...
  • Page 23 910-B: Not used (Fixed at "0") 910-C: 1. Server # entry system 2. Server # entry system 910-C Stay down PENDING Auto sign off 910-D: Not used (Fixed at "4") ... MRS for UP-600 / ... MRS for UP-700 Note :...
  • Page 24 3. Key touch sound 1. Drawer closing 2. Error system 3. Key touch 913-D compulsory sound All lock error Non-compulsory Misoperation (One shot error) All lock error Compulsory Misoperation (One shot error) ... MRS for UP-600 / ... MRS for UP-700 Note :...
  • Page 25 3. Non-add code entry Compulsory 1.Manual TAX 2.Check/Cashing 3.Non-add Non compulsory 914-D Always code entry Compulsory Enable Disable Disable Enable Enable Enable Disable Enable Disable Disable Disable Enable Enable Disable ... MRS for UP-600 / ... MRS for UP-700 Note :...
  • Page 26 Tax 1 totals Print Skip Print Print Print Print Skip Skip Print Skip Print Skip Print Skip Print Skip Print Skip Print Print Skip Skip Skip Skip Print Skip Skip ... MRS for UP-600 / ... MRS for UP-700 Note :...
  • Page 27 2. Foreign currency format 919-D SBTL Decimal digits are printed Omit digits lower than tab position Decimal digits are printed Omit digits lower than tab position ... MRS for UP-600 / ... MRS for UP-700 Note :...
  • Page 28 [JOB#920] : UP-600/700 MRS=2040 : INLINE [JOB#922] : UP-600/700 MRS=0000 : INLINE PROGRAMMING AREA PROGRAMMING AREA 920-A: 1. Back-up master function. 922-A : Not used (Fixed at "0") 922-B : 1. Using new Coin Dispenser which can issue $1 Coin.
  • Page 29 926-C: 1. Open store / Close store : stand alone POS with on-line [JOB#925] : UP-600/700 MRS=0303 : INLINE PROGRAMMING AREA 2. Send AT command string with OPEN STORE 925-A: Not used (Fixed at "0") 3. Send AT command string with CLOSE STORE 925-B: 1.
  • Page 30 Daily net Z2 report counter 0000 DEPARTMENT Z1 Department Z1 report counter 0000 980-C,D: Not used (Fixed at "00") DEPARTMENT Z2 Department Z2 report counter 0000 [JOB#981] : UP-600/700 NOT USED MRS=4000 ... MRS for UP-600 / ... MRS for UP-700 Note :...
  • Page 31 4. [04 GT] 5. [05 MODE SECRET# ] DISPLAY: Setting item select screen DISPLAY: Setting item select screen Select "04 GT" and press the ENTER key. Select "05 MODE SECRET#" and press the ENTER key. DISPLAY: GT COUNTER screen DISPLAY: MODE SECRET# screen Select the GT counter to be changed and enter the value.
  • Page 32 6. [06 FREE KEY] Position code (MRS) DISPLAY: Setting item select screen Key No. Function name Key text UP-600 UP-700 INHIBIT 0 KEY 0 KEY 1 KEY 1 KEY 2 KEY 2 KEY 3 KEY 3 KEY 4 KEY 4 KEY...
  • Page 33 Position code Position code (MRS) (MRS) Key No. Function name Key text Key No. Function name Key text UP-600 UP-700 UP-600 UP-700 Group discount 2 shift key GD2SFT Cash3 key Group discount 3 shift key GD3SFT Cash4 key Validation print key...
  • Page 34 Position code Position code (MRS) (MRS) Key No. Function name Key text Key No. Function name Key text UP-600 UP-700 UP-600 UP-700 Charge menu key CHG.MN PLU menu 37 key PMEN37 Conversion menu key CNV.MN PLU menu 38 key PMEN38 Void menu key VD.MN...
  • Page 35 7. [07 KEY INITIAL] 08. [08 FILE] DISPLAY: Setting item select screen DISPLAY: Setting item select screen Select "09 KEY INITIAL" and press the ENTER key. Select "10 FILE" and press the ENTER key. The keyboard layout is reset to the standard keylayout.
  • Page 37 DISPLAY: File group Type 2 input screen Select the file name to be changed and enter the number of records. Enter the bumber of blocks. The content of displayed are as listed in the file table. DISPLAY: File group Type 3 input screen DISPLAY: File group Type 0 input screen Enter the bumber of index records and data records.
  • Page 38 FILE TABLE GROUP File table No. (Create, Erase) FILE NAME TYPE [(Fixed files)/(Related files)] DEPT. 01, 02, 03, 05, 06 DEPT. TEXT (8) DEPT. TEXT (16) DEPT. Mark Down 11/12, 13, 14, 15 PLU/UPC 16, 17, 18, 20, 26, 28, 30, 32, 34, 36 PLU/UPC PRICE 1 18, 28, 30, 32, 34, 36/29, 31, 33, 35, 37 PLU/UPC PRICE 1-6...
  • Page 39 GROUP File table No. (Create, Erase) FILE NAME TYPE [(Fixed files)/(Related files)] Message text (KP) 152, 153 Repeat round buffer Positive# Charge Positing (Positive# Sales) Negative# Capture job 169, 190 Capture job (sales) RJE Command buffer 172, 173, 174, 175, 176, 177, 178, 179, 180 RJE Scheduler buffer 181, 182, 183, 184, 185, 186, 187 ONLINE PRINT buffer...
  • Page 40 FILE CONTENTS RECORD BLOCK Label Data File name size size DEPT PRESET PRICE TEXT (8 chara) TEXT (16 chara) CVM CHARACTOR DAILY TERM SAVE DAILY CONSOLI. RECEIVE DAILY (Markdown) TERM (Markdown) SAVE DAILY (Markdown) CONSOL. (Markdown) RECEIVE (Markdown) PLU PRESET 1000 1000 ****...
  • Page 41 RECORD BLOCK Label Data File name size size KP TEXT1 **** (48) TEXT1-6 (8 chara) **** (48) TEXT1-6 (16 chara) **** (48) KP TEXT1-6 **** (48) CVM CHARACTOR **** (48) DAILY (Price1) **** (48) TERM (Price1) **** (48) WASTE DAILY (Price1) **** (48)
  • Page 42 RECORD BLOCK Label Data File name size size SAVE DAILY (106) CONSOL. (106) RECEIVE (106) 111 DAILY NET LABEL TOTAL (111) 113 DAILY NET CONSOL. LABEL (111) CONSOL. (111) 115 DAILY NET RCV. LABEL (111) RECEIVE (111) 117 Reg buffer **** 118 Reg Edit buffer ****...
  • Page 43 RECORD BLOCK Label Data File name size size 163 POSITIVE# **** 164 CHARGE POSTING (POSITIVE# SALES) **** 165 CHARGE POSTING FOR IRC RCV **** (164) 166 NEGATIVE# **** 167 CAPTURE KEY PRESET CAPTURE KEY TEXT (167) 169 CAPTURE JOB PRESET CAPTURE JOB TEXT (169) 171 CAPTURE SALES...
  • Page 44 10. [10 MEMORY INITIAL] 11. [11 SSP] DISPLAY: Setting item select screen DISPLAY: Setting item select screen Select "10 MEMORY INITIAL" and press the ENTER key. Select "11 SSP " and press the ENTER key. DISPLAY: The following display is shown. DISPLAY: SSP screen Select the item and press the ENTER key.
  • Page 45 12. [12 BACKUP SEND] 13. [13 BACKUP RECEIVE] DISPLAY: Setting item select screen DISPLAY: Setting item select screen Select "12 BACKUP SEND" and press the ENTER key. Select "13 BACKUP RECEIVE" and press the ENTER key. DISPLAY: BACKUP SEND screen DISPLAY: BACKUP RECEIVE screen Select the item and press the ENTER key.

  • Page 46: Chapter 4. Srv Mode Programming ("3 Irc Setting")

    CHAPTER 4. SRV MODE PROGRAMMING ("3 IRC SETTING") Before trying to perform inline setup, make sure to create (or delete) [1 SATELLITE] the files required by the inline system using the following procedure: DISPLAY: Setting screen [SRV MODE] - [2 SETTING] - [08 FILE]. And then perform inline setup.
  • Page 47 Symbol/PartsCod) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - [2 MASTER] DISPLAY: Setting screen When all the machine are set, press the [CA/AT] key.
  • Page 48 [3 BACKUP MASTER] [4 STD. WITH IRC] DISPLAY: Setting screen DISPLAY: Setting screen Select the item to be changed and press the ENTER key. The setting content is described below. DISPLAY TEXT CONTENTS SELECT ITEM IP ADDRESS 1 IP ADDRESS 2 IP ADDRESS 3 IP ADDRESS 4 Terminal No.

  • Page 49: Chapter 5. Srv Mode Programming ("4 Down Load")

    CHAPTER 5. SRV MODE PROGRAMMING ("4 DOWN LOAD") After IRC SETUP, using this setting procedure, download the setting [1 ALL] data from the master. Download data from all the machines included in the master list. DISPLAY: SRV mode screen [2 MACHINE SELECT] Select the machine among the master list from which you want to download data.

  • Page 50: Chapter 6. Srv Mode Programming ("5 Diagnostics")

    CHAPTER 6. SRV MODE PROGRAMMING ("5 DIAGNOSTICS") Execute the test program. Fore more information, see the Service Manual. DISPLAY: SRV mode screen...
