Sharp UP-700 Dealer Knowledge Book

Hide thumbs Also See for UP-700:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Programming Manual
Preliminary draft
Category
1.
Functions Overview ....................................................................................................
2.
- Recommended Sequence ..................................................................................
- Cable Specifications ...........................................................................................
- Program (SRV) Reset ........................................................................................
3.
- UP-700 Connection .............................................................................................
- SRV Mode Related Presets ...............................................................................
- Making SRV mode Settings ...............................................................................
4.
Installing the Logo Converter Utility on a PC ...........................................................
5.
Creating a Logo Image .............................................................................................
6.
Sending the Image to the UP-700 ............................................................................
7.
Converting Images for the ER-02FD.exe ................................................................
8.
Error Code Descriptions ...........................................................................................
9.
Quick Start Procedures .............................................................................................
Notice:
This software and/or documentation are furnished under license and may be used or copied in accordance with the terms
of such license.
Except as permitted by such license, no part of this software or documentation may be reproduced, stored in a retrieval
system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior
written permission of Sharp Corporation.
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/
or other countries.
Designs and specifications are subject to change without notice.
Dealer Knowledge Book
I'm also here
to assist you !
MODEL
LOGOCONV.exe Logo Converter Utility
Contents
UP-700
Pg.
10
11
13
15
16
1
2
3
4
5
6
7
8

Advertisement

Table of Contents
loading

Related Manuals for Sharp UP-700

Summary of Contents for Sharp UP-700

  • Page 1: Table Of Contents

    - Making SRV mode Settings ................Installing the Logo Converter Utility on a PC ............Creating a Logo Image ..................... Sending the Image to the UP-700 ................Converting Images for the ER-02FD.exe ..............Error Code Descriptions ................... Quick Start Procedures .....................

  • Page 2: Functions Overview

    Over view FUNCTIONS OVERVIEW The UP-700 model ECR provides support for loading image data that may be used as an graphics logo for the header or footer of a receipt. The data must meet the specifications defined within this document which will outline the attributes necessary for loading the image data.

  • Page 3: Introduction

    Introduction INTRODUCTION This document will help you utilize the graphics logo function of the UP-700 model ECR. This documentation assumes that you are familiar with general PC and the Microsoft® Windows operating system as it relates to the settings for the desk top, communications ports, etc. Please read this introductory section carefully as it will provide helpful hints and recommendations that will make your time more efficient and produce time saving results.

  • Page 4: Cable Specifications

    Introduction CABLE SPECIFICATIONS The SIO function is used to download the logo image to the UP-700 from the PC. Yjr SIO function is dedicated to COMM-2 with connection via an RJ45 modular jack. The below diagram represents the cable specifications required when connecting the UP-700 to a PC when the Logo Image Data function is used.

  • Page 5: Program (Srv) Reset

    Introduction RESET PROCEDURES 1. Program (SRV) Reset: To perform a Program Reset, the SRV key (p/n: LKGiM7113RCZZ) must be used. Please refer to (fig. 2) when performing the below key sequence. (1) Insert the SRV key and rotate it counterclockwise to the 6 o'clock position to the SRV' position. (Please note that the display goes out) (2) Count for 5 seconds.

  • Page 6: Up-700 Setup

    PREPARING THE UP-700 1. The UP-700 SIO Function Connection: In addition to setting the graphics logo print control, the image data may be sent to the UP-700 using the SIO Function. The Program Back up/Restore (SIO) function has been fixed to port-2 (CH #2) of the UP-700 as shown below in (Fig.

  • Page 7: Srv Mode Related Presets

    UP-700 Setup 2. SRV Mode Related Jobs: The SRV-mode presets related to the usage of the LogoConv.exe are described within this section. (1) SRV job #903: SIO Baud Rate is set in SRV-mode 903-A as outlined below; - - - .

  • Page 8: Making Srv Mode Settings

    UP-700 Setup (2) SRV job #912: Header and Footer print is set in SRV-mode 912-C&D as outlined below. - - - - - - - - - - - - ..- - - - - -...

  • Page 9: Installing The Logo Converter Utility On A Pc

    LOGOCONV.exe Setup PREPARING THE PC ENVIRONMENT The UP-700 Logo Utility has been provided in two separate files which are self extracting files that contain all the necessary files for installation of the program. 1. Using Explorer, create a temporary folder to copy the following files;...
  • Page 10 LOGOCONV.exe Setup 4. Select the Program Group where the utility will be referenced and then click [ Continue ]. (Fig. 9) 5. When the installation process has been successfully completed, click [OK] to exit to the installation program. (Fig. 10) 6.

  • Page 11: Creating A Logo Image

    Creating a Logo Image CREATING A LOGO IMAGE Prior to starting the Logo conversion application it is recommended that you create and format the image data to be used by setting the attributes to be within the previously mentioned specifications. Format Specifications: (1) File format: *.PCX or *.BMP...

  • Page 12: Sending The Image To The Up-700

    3. Click [ OK ] (Fig. 12) .12) 4. The LOGOCONV.exe will prompt you if you have an image file ready for transfer to the UP-700. Click [Continue] if you have a file that has been prepared. (Fig. 13) .13) 5.
  • Page 13 For the Protocol setting, only SIO (Manual) and SIO (Auto) are eligible selections. .16) (3) Click [ OK ] when you have selected the necessary settings and the application will begin downloading the image data to the UP-700. (Fig. 17) .17) 9. At the receiving UP-700;...

  • Page 14: Converting Images For The Er-02Fd.exe

    Converting Image Data CONVERTING IMAGES FOR USAGE WITH THE ER02FD.EXE The UP-700 Logo utility also supports the conversion of image data that meets the necessary specification previously outlined to be used with the ER02FD.exe PC utility as an alternative means of loading a graphics logo.
  • Page 15 Converting Image Data 5. Once selected, if the image data complies with the specifications, the image will be displayed. 6. If the image is the correct graphics, then click the [ Save ] button to save the image to the hard drive.

  • Page 16: Error Code Descriptions

    (2) During communications if the communications encounters problems for some reason. 1. Error Display when the image data does not meet specifications. (Fig. 23) .23) 2. The following Communications error could result which are related to the UP-700's SIO communications function. Code : Description —————————————————...

  • Page 17: Quick Start Procedures

    Quick Start Procedures QUICK START PROCEDURES For a quick reference procedure for using the LOGOCONV.exe with the UP-700, please use the below sequential steps outlined in the chart below. " : " 8 " : " 5 i l c...
