Summary of Contents for Rangemaster Toledo 110 Induction Cooker U109948 - 04

  • Page 1: User Guide

    ArtNo.000-0021 Toledo logo 110 Induction User Guide & Installation & Service Instructions U109948 - 04...
  • Page 2: Table Of Contents

    Contents Before You Start... Cooker Overview Cooking Tips Cooking Table Cleaning Your Cooker Troubleshooting Installation Servicing Circuit Diagrams 10. Technical Data...
  • Page 3: Before You Start

    1. Before You Start... Thank you for buying a Falcon cooker. It should give you many years of trouble-free cooking if installed and operated correctly. It is important that you read this section before you start, particularly if you have not used an induction cooker before.
  • Page 4: Cooker Care

    Make sure to use adequately sized pans with flat  bottoms that are large enough to cover the surface of the hotplate heating area. Never leave the hotplate unattended at high heat settings. Pans boiling over can cause smoking, and greasy spills may catch on fire.
  • Page 5: Cooker Overview

    2. Cooker Overview � � � � The 110 induction cooker (Fig.2-1) has the following features: 5 induction cooking zones A control panel A grill A conventional oven A programmable fan oven A storage drawer The Hob Use only pans that are suitable for induction hobs. We recommend stainless steel, enamelled steel pans or cast iron pans with enamelled bases.
  • Page 6: Pan Detector

    Fig.2-4 ����� ����� ArtNo.313-0002 - 110 induction hob rating ����� Fig.2-5 � � ArtNo.313-0003 110 Induction hob display � �������������������� ������������ ���������� ��������� ������ ���������� ArtNo.051-0002 - Min pan diameter ����������� Table 2-1 Make sure that the base of the pan is clean and dry to prevent any residue burning onto the hob panel.
  • Page 7: The Grill

    heat up at 100% power for a specified time before the power is reduced to the level selected. When the Automatic Heat-up function is activated, the hob control display will alternately flash between the [A ] setting and the chosen power level. Once the automatic heat-up time has ended the hob control display will stop flashing and will display the chosen power level.
  • Page 8: Operating The Ovens

    Fig.2-10 ArtNo.322-0002 Conventional oven Fig.2-11 ArtNo.321-0002 Fan assisted oven Fig.2-12 ArtNo.240-0002 - Toledo oven control 1 Fig.2-13 ArtNo.240-0003 - Toledo oven control 2 For best results, you should leave the grill pan in the grill chamber and preheat the appropriate part(s) of the grill for two minutes.
  • Page 9: Setting The Time Of Day

    The Clock Setting the time of day The LCD clock is shown in (Fig 2-14). When the clock is first connected the display flashes ( 0.00) and ( Press and hold both the [] and [] buttons as shown in Fig.2-15.
  • Page 10: Key Lock

    Fig.2-21 ArtNo.302-0008 - Activating the key lock 1 Fig.2-22 ArtNo.302-0009 - Activating the key lock 2 Fig.2-23 ArtNo.302-0010 - Activating the key lock 3 Fig.2-24 ArtNo.302-0011 - 6BC Deactivating the key lock 1 Fig.2-25 ArtNo.302-0012 - Deactivating the key lock 2 Fig.2-26 �...
  • Page 11: The Handyrack

    Accessories Oven Shelves In addition to the flat shelves (Fig.2-26), some models are supplied with a drop shelf (Fig.2-27). The drop shelf increases the possibilities for oven shelf spacing. The oven shelves can be easily removed and refitted. Pull the shelf forward until the back of the shelf is stopped by the shelf stop bumps in the oven sides (Fig.2-28).
  • Page 12: The Browning Element

    Fig.2-34 ArtNo.320-0027 - Twin oven lights Fig.2-35 ArtNo.340-0001 110 drawer position Fig.2-36 ArtNo.340-0002 110 removing the drawer Main Oven Light Press the appropriate button to turn one of the lights on (Fig.2-34). If an oven light fails, turn off the power supply before changing the bulb.
  • Page 13: Cooking Tips

    3. Cooking Tips Tips on Cooking with the Timer If you want to cook more than one dish, choose dishes that require approximately the same cooking time. However, dishes can be ‘slowed down’ slightly by using small containers and covering them with aluminium foil, or ‘speeded up’ slightly by cooking smaller quantities or placing them in larger containers.
  • Page 14: Cooking Table

    4. Cooking Table The oven control settings and cooking times given in the table below are intended to be used AS A GUIDE ONLY. Individual tastes may require the temperature to be altered to provide a preferred result. Food is cooked at lower temperature in a fan oven than in a conventional oven. When using recipes, reduce the fan oven temperature by 10°C and the cooking time by 5-10 minutes.
  • Page 15: Cleaning Your Cooker

    DocNo.045-0011 - Cleaning - 110 Induction - tpl glzd & std grill 5. Cleaning Your Cooker Isolate the electricity supply before carrying out any major Fig.5-1 cleaning. Allow the cooker to cool. Never use paint solvents, washing soda, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt.
  • Page 16: Control Panel And Doors

    Fig.5-2 ArtNo.320-0002b - Oven door side screws (Toledo) Once you have removed as much as possible with the scraper, follow the ‘Daily Care’ procedure outlined above. To Remove Metal Rub-off Sliding pans on the hob – especially aluminium or copper pans –...
  • Page 17 ‘Cook & Clean’ Panels The main oven has side ‘Cook & Clean’ panels which have been coated with a special enamel that partly cleans itself. This does not stop all marks on the lining, but helps to reduce the amount of manual cleaning needed. These panels work better above 200°C.
  • Page 18: Troubleshooting

    6. Troubleshooting Interference with and repairs to the hob MUST NOT  be carried out by unqualified persons. Do not try to repair the hob as this may result in injury and damage to the hob. Please arrange for repair by a suitably competent person.
  • Page 19 Food is cooking too slowly, too quickly, or burning Cooking times may differ from your previous oven. Check that you are using the recommended temperatures and shelf positions – see the oven cooking guide. Then adjust the settings according to your own individual tastes.
  • Page 20: Installation

    7. Installation Dear Installer Before you start your installation, please complete the details below, so that, if your customer has a problem relating to your installation, they will be able to contact you easily. ���������������� ������������������� ArtNo.050-0011 - Installer information table ����������������������������...
  • Page 21: Unpacking The Cooker

    Positioning the Cooker Fig.7-1 shows the minimum recommended distance from the cooker to nearby surfaces. The cooker should not be placed on a base. The hotplate surround should be level with, or above, any adjacent work surface. A gap of 75mm should be left between each side of the cooker ABOVE the hotplate level and any adjacent vertical surface.
  • Page 22: Repositioning The Cooker Following Connection

    Fig.7-6 ArtNo.010-0008 Lowering the front rollers Fig.7-7 ArtNo.010-0002 Rear roller nut Fig.7-8 ArtNo.010-0003 Lowering the rear rollers Fig.7-9 ArtNo.010-0009 Pushing the cooker Fig.7-10 ArtNo.010-0004 Moving the cooker LOWER THE FRONT ROLLER by doing 14 complete (360°) turns clockwise (Fig.7-6). (This means turning and removing the �...
  • Page 23: Electrical Connection

    clockwise to raise the cooker and anticlockwise to lower. When you are satisfied with the height and level, raise the front of the cooker by one turn of the front roller adjuster. Screw down the front feet to meet the floor. Screw the front roller adjuster anticlockwise to raise the front roller so that the front of the cooker is supported on the feet, not the front roller, to prevent accidental movement of the cooker.
  • Page 24: Servicing

    WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 8. Servicing Fig.8-1 ArtNo.210-0008 - Classic Removing the end caps Disconnect the cooker from the electricity supply ...
  • Page 25 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. To Replace a Light Switch Disconnect from electricity supply. Remove the control panel (see 3). Note: The old switch may be destroyed during removal.
  • Page 26 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. Fig.8-4 ArtNo.320-0006 Oven door hinge adjustment 1 Effect of hinge adjustment - exagerrated for clarity Fig.8-5 Centreline of hinge pin ArtNo.320-0007 Oven door hinge adjustment 2...
  • Page 27 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 14. To Change the Oven Door Latch Remove the outer door panel (see 13). Remove screws ‘B’ that hold the latch assembly to the inner door panel (Fig.8-7).
  • Page 28 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. Fig.8-12 ArtNo.322-0002 Oven bottom element access � � Fig.8-13 ArtNo.324-0007 Unscrewing the bulb cover 20. To Replace an Oven Fan Disconnect from electricity supply.
  • Page 29: Circuit Diagram: Oven

    9. Circuit Diagram: Oven � � �� � � �� �� �� � � �� � �� �� � � �� � � ������� � � � ��� �� � � � � �� � � �� � �� � ���...
  • Page 30: Circuit Diagram: Hob

    Circuit Diagram: Hob 2.3kW Code Description Touchlite panel Distribution board Left-hand front control Left-hand rear control Central control Right-hand front control Right-hand rear control To T1 To T2 To T4 To T5 2.3kW 1.4kW To Earth 1.4kW ���������������������������������������������������� 2.3kW Colour Code Blue Brown Black...
  • Page 31: Technical Data

    10. Technical Data INSTALLER: Please leave these instructions with the User. DATA BADGE LOCATION : Cooker back, serial number repeater badge below oven door opening. Connections Electric Dimensions Overall height Overall width Overall depth Refer to 'Positioning the Cooker' . Ratings �����...
  • Page 32 DocNo.000-0001 - Back cover Rangemaster �������������� ����������� ������� ����� w w w.ra n g e m a s t e r.c o .u k ArtNo.000-0003 CE logo...

This manual is also suitable for:

Toledo 110 induction

Table of Contents
