- Page 1 M433LC Radio Modem (ETSI 300-220) Technical Manual ISSUE : 4.0 UPDATE : 19/08/2002...
- Page 2 Adcon RF Technology. This publication is intended only to assist the reader in the use of the product. Adcon RF Technology. shall not be liable for any loss or damage arising from the use of any information in this publication, or any error or omission in such information, or any incorrect use of the product.
-
Page 3: Table Of Contents
4.2.1 General concept ------------------------------------------------------------------------------------------------- 20 4.2.2 Standard commands-------------------------------------------------------------------------------------------- 21 4.3 Register description ------------------------------------------------------------------------------------------------------ 22 Appendix : History -----------------------------------------------------------------------------------------------------23 A.1 Revision history------------------------------------------------------------------------------------------------------------- 23 A.2 Firmware version history ----------------------------------------------------------------------------------------------- 23 Copyright Adcon RF Technology 2002 Page: 3 M433LC-Ind Modem Technical Manual Rev: 4.0... -
Page 4: Introduction
1.3 MTC Software Installation 1. Put Adcon database CD into the PC. The CD is autolaunched and displays a browser on the Adcon database presentation page. 2. Go to the Adcon database page by clicking either on the “Adcon RF Database” link or on its button. -
Page 5: Description
• Input voltage (Min.): • Reverse voltage: -40V • Load dump : 120V 1ms/100ms • Fast transient: Standard IEC801-4, 2KV • Conduction disturbance: Standard IEC801-6, 10V (RMS) Copyright Adcon RF Technology 2002 Page: 5 M433LC-Ind Modem Technical Manual Rev: 4.0... - Page 6 Copyright Adcon RF Technology 2002 Page: 6 M433LC-Ind Modem Technical Manual Rev: 4.0...
-
Page 8: Basic Operation: Using Mtc
3. BASIC OPERATION: USING MTC 3.1 The desktop The Modem Test & Configuration (MTC) Workbench is an Adcon software framework to test and configure all modems supplied by Adcon RF Technology. Several and diversified modems, connected to the PC/workstation via various hardware interfaces (RS232, RS422, ...), can be tested and configured at the same time. - Page 9 COM1 node. The radio modem should appear as a child node in the Tree window: The radio modem is now ready to be tested and configured with the different options of the MTC software. Those options are described below. Copyright Adcon RF Technology 2002 Page: 9 LC-Ind Modems Technical Manual Rev: 1.0...
-
Page 10: The Menu Bar
The parameters concerned are the operating mode and the radio channel. • Dialog: Displays an advanced terminal dialog window between two given radio modules, the ports of which are chosen by the user. Copyright Adcon RF Technology 2002 Page: 10 LC-Ind Modems Technical Manual Rev: 1.0... - Page 11 (i.e. mode, network and clients’ IDs). The ports are chosen by the user. Note: It is not applicable to M433LC-Ind units. The ‘Windows’ Menu The ‘Windows’ menu lists the different windows already opened and allows the user to change the active window.
-
Page 12: The Tool Bar
Operates new auto configuration on all or selected ports Opens peer-to-peer dialog Opens peer-to-peer dialog window between two chosen ports Opens network dialog Opens network dialog window between two chosen ports Copyright Adcon RF Technology 2002 Page: 12 LC-Ind Modems Technical Manual Rev: 1.0... -
Page 13: The Application Tree
Note: The application tree, i.e. the Tree window especially, can not be exploited in basic user level configuration. In basic level configuration, the Tree is just used as information. Copyright Adcon RF Technology 2002 Page: 13 LC-Ind Modems Technical Manual... - Page 14 Modem connected to corresponding port. Port not in use NOT CONNECTED No modem connected to corresponding port Note: The legend (i.e. ports status) can be hidden by disabling the ‘Legend’ button. Copyright Adcon RF Technology 2002 Page: 14 LC-Ind Modems Technical Manual Rev: 1.0...
-
Page 15: Peer-To-Peer Dialog
If ‘DIALOG’ was pressed, pressing ‘Yes’ opens the peer-to-peer dialog window (See paragraph 7.2). Pressing ‘No’ cancels the configuration in both cases. Copyright Adcon RF Technology 2002 Page: 15 LC-Ind Modems Technical Manual... -
Page 16: Dialog
‘Send continuously’: Enabling this option allows the user to transmit data (from ‘Data to send’) permanently to the other modem. The time out (i.e. ‘Each […] ms’ field) is configurable but should be greater than 500 ms. Copyright Adcon RF Technology 2002 Page: 16 LC-Ind Modems Technical Manual... - Page 17 ‘Display’ button: Displays a summary of the dialog established between the two radio units: • ‘Clear All’ button: Clears all the window’s fields (described above). • ‘Exit’ button: Quits the peer-to-peer dialog window. Copyright Adcon RF Technology 2002 Page: 17 LC-Ind Modems Technical Manual Rev: 1.0...
-
Page 18: Advanced Operation
The LC RF-Modem takes priority over the reception of the characters coming from the serial link connected to it. Thus a permanent reception or jamming on its channel of a radio signal (valid or not) cannot involve locking to switch to Hayes command. Copyright Adcon RF Technology 2002 Page: 18 LC-Ind Modems Technical Manual... -
Page 20: Hayes Or 'At' Mode
Note: The Time between 2 characters of the same command must be under 10 seconds. Despite its similarity to standard telecommunication modem, ADCON LC-IND radio modems remains a radio link modem and is consequently fitted with some particular additional “AT”... -
Page 21: Standard Commands
Pure carrier transmission (for testing purposes) ATT1 F0 modulated carrier transmission (for testing purposes) ATT2 F1 modulated carrier transmission (for testing purposes) ATT3 Alternative F0-F1 modulated carrier transmission (for testing purposes) Copyright Adcon RF Technology 2002 Page: 21 LC-Ind Modems Technical Manual Rev: 1.0... -
Page 22: Register Description
Scanning stops after reception of any character on the serial line . (*) Scanning = status of the radio activity as noise or data, in the selected channel Copyright Adcon RF Technology 2002 Page: 22 LC-Ind Modems Technical Manual... -
Page 23: Appendix : History
Updates and re-design 08/02 Updates and MTC integration A.2 Firmware version history Serial rate up to 38400 bauds v 1.51 Radio rate up to 10 Kbits/s Transparent mode Scanning Copyright Adcon RF Technology 2002 Page: 23 LC-Ind Modems Technical Manual Rev: 1.0...
