Picture Message Draft
Priority
Unread MMS Notification
Read MMS Notification
Corrupt Message
Pending Message Sent
Unread MMS
DST (Daylight Saving Time)
16
Message Icons
Multiple Message Sent
IM Screen Name
Address
WL Messenger
AIM
Yahoo!
Other Icon

INSTALL BATTERY

1. Insert your finger tip into the slot (1), then push down on
top of the battery cover and slide it off to remove (2).
2. Slide the battery into the slot (3) by aligning the contacts
and press down (4) until you hear the "click".
Correct incorrect
3. Align the cover tabs with the slots on the back of the
device and slide the battery cover onto the unit until it
snaps into place.
• If the battery is not correctly placed in the compartment, the
handset will not turn on and/or the battery may detach during use.
• Important: To activate your device for data transfer, mount battery in your device
before connecting the USB data cable.
Correct

REMOVE BATTERY

1. To remove the battery cover, insert your finger tip into the
slot (1), then push down on top of the battery cover and
slide it off (2).
incorrect
01 01
02 02
03 03
04 04
05 05
06 06
07 07
