Page 2
Your phone is designed to make it easy for you to access a wide variety of content. For your protection, we want you to be aware that some applications that you enable may involve the location of your phone being shared. For applications available through AT&T, we offer privacy controls that let you decide how an application may use the location of your phone and other phones on your account.
Page 3
Thank you for choosing the AT&T Smart Device Pantech Matrix Pro, which has adopted the Microsoft Windows Mobile™ 6.1 Standard in a dual slider design to give you the convenience of Windows and the comfort of a familiar shape. Using ActiveSync®, you can keep your PC and Pantech Matrix Pro synchronized at all times.
Using Shortcuts Numbered menu items, such as menus, sub-menus, and options can be quickly accessed by using their shortcut numbers. In Start window, Main Menus can be accessed by pressing the number keys (1 to 9) corresponding to their location on the screen.
MENU TREE 13.4 Tasks 13.5 Voice Note 13.6 World Time 14 Office Mobile 14.1 Excel Mobile 14.2 OneNote Mobile 14.3 PowerPoint Mobile 14.4 Word Mobile 15 Games 16 Internet Explorer 17 Applications 17.1 Camera 17.2 File Explorer 17.3 Java 17.4 JETCET PDF 17.5 Mobile banking 17.6 My-Cast Weather 17.7 Speed Dial...
CHAPTER 1 BEFORE USING YOUR PHONE ... 14 INSIDE THE PACKAGE ... 15 HANDSET DESCRIPTION ... 16 NUMBER PAD VIEW ...16 QWERTY KEYBOARD VIEW ...17 ACTIVATING YOUR PHONE ... 18 HOME SCREEN ... 19 HOME SCREEN CUSTOMIZATION ...19 HOME SCREEN ICONS ...19 QUICK &...
Page 7
EXPLORE FILES AND FOLDERS ...41 SILENCE THE RING TONE OF AN INCOMING CALL ...41 MAKING AN EMERGENCY CALL ... 42 ENTERING TEXT AND NUMBERS... 43 CHANGE BETWEEN UPPERCASE, LOWERCASE, AND CAPS LOCK...43 CHANGE THE MULTIPRESS TIMEOUT...43 DELETE CHARACTERS...44 ENTER A SPACE...44 ENTER A SYMBOL ...44 ENTER NUMBERS IN TEXT BOXES ...44 ENTER PUNCTUATION IN MULTIPRESS MODE ...45...
Page 8
ASSIGN A CATEGORY TO A CONTACT ...60 ASSIGN A RING TONE TO A CONTACT ...60 CREATE A SPEED DIAL...61 USING SPEED DIALS ...61 VIEW AND EDIT A SPEED DIAL ...62 DELETE A SPEED DIAL ...62 SEND AS VCARD...62 CALL HISTORY ... 63 VIEW CALL TIMERS ...63 RESET CALL TIMERS...63 VIEW DETAILS ABOUT A CALL...64...
Page 9
EDIT PREDEFINED TEXT...84 EMPTY THE DELETED ITEMS FOLDER ...84 FORWARD A MESSAGE...85 INSERT PREDEFINED TEXT INTO A MESSAGE...85 MARK A MESSAGE AS READ OR UNREAD ...85 MOVE A MESSAGE TO A DIFFERENT FOLDER...86 OPEN A MESSAGE...86 QUICKLY MOVE BETWEEN ACCOUNTS ...87 SEND A MESSAGE DRAFT ...87 REPLY TO A MESSAGE...87 SAVE A DRAFT OF A MESSAGE...88...
Page 10
PLAYING MEDIA FILES ...103 SETTING UP A PLAYLIST ...105 SHOP MUSIC ... 107 MUSIC ID... 108 USING ID SONG! ...108 USING MANAGE ID’S ...109 GETTING HELP WITH MUSICID ...109 EXITING FROM THE MUSICID APPLICATION...109 XM RADIO MOBILE... 110 MUSIC VIDEOS... 111 PANDORA ...
Page 11
MOBITV ... 131 MEDIA NET ... 132 OFFICE MOBILE ... 133 EXCEL MOBILE ...133 ONENOTE MOBILE ...133 POWERPOINT MOBILE ...133 WORD MOBILE...133 CHAPTER 10 CAMERA... 134 CAMERA / CAMCORDER MODE ... 135 SELECT VIDEO QUALITY...135 COPY AN IMAGE TO YOUR PHONE...135 TAKE VIDEOS USING A TIMER...136 ADJUST PICTURES AND VIDEO FOR LIGHTING CONDITIONS ...136 SELECT WHERE PICTURES ARE SAVED ...137...
Page 12
GO TO A LINK...153 GO TO A WEB PAGE...153 GO TO A WEB PAGE IN THE HISTORY LIST ...154 OPEN INTERNET EXPLORER ...154 RETURN TO A WEB PAGE YOU VISITED IN THE SAME SESSION...154 VIEW A FAVORITE ...155 VIEW A LIST OF RECENTLY VISITED WEB PAGES ...155 MOVE A FAVORITE TO A FOLDER...155 CHANGE THE ZOOM LEVEL ON WEB PAGES ...156 SHOW OR HIDE PICTURES ON WEB PAGES ...156...
Page 13
MY-CAST WEATHER... 181 SPEED DIAL... 182 SYSTEM INFO ... 183 TASK MANAGER... 184 VOICE COMMANDER... 185 GETTING STARTED ...185 FEATURES ...185 “VOICE COMMANDER SETTINGS” MAIN FUNCTIONS...188 CHAPTER 14 SETTINGS... 191 PHONE ... 192 AUTO ANSWER ...192 AUTO LOCK ...192 CALL FORWARDING...192 CALL OPTIONS ...192 CALL WAITING ...193 CALLER ID ...193...
Page 14
DISABLE THE DEVICE LOCK ...207 ACTIVATING THE SIM PIN ...208 CHANGING THE SIM PIN...208 CHANGING PIN2 ...208 VIEW A CERTIFICATE ...209 DELETE A CERTIFICATE...209 ENCRYPTION...210 CHANGING MASTER CLEAR PASSWORD...210 MASTER CLEAR...210 REMOVE PROGRAMS ... 211 POWER MANAGEMENT... 212 VIDEO SHARE ... 213 ACCESSIBILITY...
Page 15
TETRIS ... 235 START A GAME OF TETRIS ...235 CHAPTER 16 SAFETY AND WARRANTY ... 236 SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES ... 237 EXPOSURE TO RADIO FREQUENCY SIGNALS...237 ANTENNA CARE ...237 DRIVING SAFETY...238 ELECTRONIC DEVICES...239 PRECAUTIONS ... 241 SAFETY INFORMATION FORFCC RF EXPOSURE... 243 SAR INFORMATION...
INSIDE THE PACKAGE This package should include all items pictured below. If any are missing or different, you should immediately contact the retailer where you purchased the phone. Handset Battery AC Travel Charger User Manual Chapter 1. Before using your phone...
HANDSET DESCRIPTION The Pantech Matrix Pro weight is about 151.4 g / 5.34 oz. The dimensions are 106x51x21.6 mm / 4.17”x2 ”x 0.85 ” NUMBER PAD VIEW Left/Right Soft Keys Home Key Send Key Voicemail Chapter 1. Before using your phone...
HANDSET DESCRIPTION Camera Speaker microSD slot QWERTY KEYBOARD VIEW Left/Right Soft key Perform the functions shown at the bottom line of the display. Function key CAPS/Shift key To enter a number To type a single or a symbol, press uppercase letter, the function key, press this key then and press the...
ACTIVATING YOUR PHONE If you have purchased Pantech Matrix Pro from the AT&T Store, it has been activated already and is ready to use. If you have upgraded your phone or received a new phone by mail, it probably needs to be activated before you can use it.
The home screen plays an integral part in the navigational mode of your Smart Device. It is the first screen displayed every time the phone is turned on. You can easily return to the home screen by pressing the [H]. HOME SCREEN CUSTOMIZATION The home screen allows you to customize your start page.
Page 22
HOME SCREEN Indicator Description Missed call Line 1/Line 2 Battery level Low battery Battery charging No battery Signal strength No signal No wireless coverage ActiveSync/ Synchronization error Phone off Silent Multipress text input mode, lowercase Multipress text input mode, uppercase first character only Multipress text input mode, uppercase XT9 text input mode, lowercase XT9 text input mode, uppercase first character only...
Page 23
HOME SCREEN Indicator Description Missing SIM card Voice Command Enabled microSD card inserted Speaker phone on Yahoo Conversation Yahoo Online, Available, Busy Yahoo Invisible Yahoo Offline AOL Conversaton AOL Available AOL Away AOL Invisible AOL Offline Windows Live Messenger Conversation Windows Live Messenger Online Windows Live Messenger Busy Windows Live Messenger Appear Offline...
QUICK & EASY Keys Press to make or receive a call. Short press: View Recent Calls. Long press: Make a call to the last number called. Press to turn the phone on/off, to terminate a call or to return to the home screen. Press to access the main menu or the Menu functions <...
USING QWERTY KEYBOARD Your phone, with a specifically designed QWERTY keyboard, provides a superior typing experience on a small handheld for easy and comfortable text writing. You can use all of the phone functions with the keyboard either closed or open. When you open the keyboard you have the extra benefit of a full messaging keyboard.
BATTERY USAGE The battery is not charged when the phone is first purchased – fully charge the battery before first use. The battery will charge faster if the phone is powered off while charging. Battery operating time gradually decreases over time. If the battery fails to perform normally, you may need to replace it.
Correct Power-Off Charging • The Pantech Matrix Pro will enter ‘power-off charging mode’ automatically if you try to charge it with the device powered off. • Charging state will be displayed according to the current state.
BATTERY USAGE NOTE: • The battery may not be fully charged at the time of purchase. • Fully charge the battery before use. • The battery must be connected to the phone in order to charge it. • Battery operating time gradually decreases over time. •...
Page 29
BATTERY USAGE • Only use the battery and charger approved by the manufacturer. • Only use the battery for its original purpose. • Try to keep the battery in a temperature range of 41ºF (5ºC) to 95ºF (35ºC). Otherwise, it could significantly reduce the capacity and lifetime of the battery.
TURNING THE PHONE ON / OFF ABOUT YOUR SIM CARD When you subscribe to your network operator, you receive a SIM (Subscriber Identity Module) card containing your registration information, PIN code, etc. Like a credit card, it should be kept secure and handled carefully. Do not bend, scratch or expose it to moisture.
CALL FUNCTIONS Your Pantech Matrix Pro phone has many options. This section will show you how to use basic functions such as making and receiving calls, locking and unlocking your phone, and managing the appearance and settings on your phone.
CALL FUNCTIONS MAKE A CALL FROM THE CALL HISTORY LIST Call History displays calls you have made, received, and missed. On the home screen, press Start > All Programs > More > Call History. Select the name or phone number to call. Press [S].
CALL FUNCTIONS ANSWER OR IGNORE A CALL • To answer the call, press Answer or [S]. • To reject the call, press Ignore or [E]. NOTE Selecting Ignore will connect the caller to your voicemail if you subscribe to this service. ANSWER A SECOND CALL •...
CALL FUNCTIONS INSERT A THREE-SECOND PAUSE IN A DIALING SEQUENCE There may be occasions when you wish to pause dialing after you’ve selected a contact to call. You can insert a three-second pause between selecting a contact to call and when the phone actually dials. On the home screen, press Contacts.
The Video Share feature allows you to share live or recorded video during a voice call. NOTE Video Share is not available in all markets. Both devices must be in a 3G service area − a 3G icon must appear by the signal bars prior to a call being placed.
Page 37
After the session established, recording started with displaying pop up message about the memory available for the recording. If you want to disconnect video sharing, press the End key or Select the STOP menu item. NOTE 1. The Video Share Call will be terminated in the following cases: •...
Only for the receiver • Landscape: You can switch the video to full-landscape / normal size. • Fullscreen: You can change the video to full / normal size by following your screen mode of a device. NOTE • The speakerphone will be automatically turned on when a Video Share Call begins, and automatically back to the previous mode when a Video Share Call ends.
SETTING UP YOUR VOICEMAIL Set up Voicemail All unanswered calls to your AT&T Pantech Matrix Pro are sent to voicemail, even if your phone is turned off. You’ll want to set up your voicemail and personal greeting as soon as you activate your Pantech Matrix Pro.
BASIC FUNCTIONS AUTO-LOCK THE KEYPAD When deactivating the locked key, you have to enter [*] additionally. However, with Auto-Lock, you can deactivate the lock function automatically. Activate Auto-Lock as follows before using it. On the home screen press Start > All Programs > More > Settings >...
Press Done. CHANGE THE HOME SCREEN APPEARANCE The Pantech Matrix Pro allows you to choose from many color schemes and layouts and allows you to use a background image for the main screen.
BASIC FUNCTIONS VIEW OPERATING SYSTEM INFORMATION There may be instances when you wish to see the basic information about your phone’s operating system. This option allows you to see summaries of all the settings on your phone. On the home screen, press Start > All Programs > More > Settings or select Settings and press All Settings.
BASIC FUNCTIONS EXPLORE FILES AND FOLDERS File Explorer lets you browse the contents of folders on your phone. The root folder on the phone is named My Device. My Device is similar to My Computer on a PC and contains the My Documents, Program Files, Temp, Storage Card, and Windows folders among others.
MAKING AN EMERGENCY CALL Emergency calls do not depend on the availability of the 911 (or 112) network in your area. The emergency number will work independently of the network area you are in, with or without a SIM card inserted. •...
ENTERING TEXT AND NUMBERS You can enter text, numbers and symbols by using the keypad. The phone supports four input modes for entering text, numbers and symbols: Multipress, XT9, Numeric and symbols. Multipress and XT9 modes are used for entering text, Numeric mode is used for entering numbers, and Symbols mode is used for entering symbols like “@”, “/”, “$”...
ENTERING TEXT AND NUMBERS DELETE CHARACTERS You can only delete characters when you are in input mode, either for numbers, names, or text. The [C] operates similarly to a backspace key on a computer. To backspace and delete a single character in any input mode, press [C].
ENTERING TEXT AND NUMBERS ENTER PUNCTUATION IN MULTIPRESS MODE Press [1] until you see the punctuation mark. To see all of the available symbols, press and hold the [#]. ENTER PUNCTUATION IN XT9 MODE In a text box when in XT9 text entry mode, do the following: Press [1], and select from a list of common punctuation.
ENTERING TEXT AND NUMBERS TURN ON CAPS LOCK You can toggle back and forth between having the cap lock on and off, the status indicator will tell you which mode you are in. In Multipress or XT9 mode, press the [*] until the status indicator for the text input mode appears in all capitals.
SCHEDULE AN APPOINTMENT Your calendar allows you to schedule appointments and reminders by day, by time, or by event. On the home screen, press Start > All Programs. Select Calendar > [O]. Press Menu > New Appointment. Enter information about the appointment. To schedule an all-day event, select End time>...
Calendar items can be deleted only from Agenda view or from an open calendar appointment. To delete from other views, open the appointment, and press Menu > Delete. To cancel a deletion, press [C]. UPDATE AN APPOINTMENT When your schedule or appointment information changes, you can easily edit the appointment with new information.
VIEW TODAY’S AGENDA For a single day’s schedule, select that day from one of the views in the calendar and select agenda view. On the home screen, press Start > All Programs. Select Calendar > [O]. Press Menu > Go to Today > [O]. From Week or Month in Calendar, press Menu >...
MAKE AN APPOINTMENT RECURRING If you’ve already entered a single appointment in your calendar and would like to change it to a recurring appointment, use the Occurs selection after selecting the appointment. On the home screen, press Start > All Programs. Select Calendar >...
CHANGE THE WORK WEEK DISPLAY Depending on your schedule, you may want to change the default work week displayed. You can choose any day of the week to start and/or finish. On the home screen, press Start > All Programs. Select Calendar >...
Using the Contacts feature of your Pantech Matrix Pro, you can manage all the phone information you need. There are many options for adding contacts, retrieving contacts, and managing the information for each contact. CREATE A NEW CONTACT To enter a new contact manually, without having the caller on the phone, you will use the Contacts selection from the home screen.
CALL A CONTACT FROM CONTACT INFORMATION You can call a contact directly by selecting them from the Contacts page off the home screen. On the home screen, press Start > All Programs > contacts or directly press Contacts. Select the contact to call and press [O]. Scroll to the phone number to dial.
DUPLICATE A CONTACT This feature allows you to copy contacts in Device or SIM to the same area. (Device Device, SIM SIM) On the home screen, press Start > All Programs. Select Contacts > [O]. Scroll to the contact to duplicate Press Menu.
DELETE A CONTACT Deleting a contact is very simple, just use the Menu once you have selected the contact. On the home screen, press Start > All Programs. Select Contacts > [O]. Scroll to the contact to delete. Press Menu. Select Delete Contact from the popup menu and press [O].
FILTER THE CONTACT LIST Contacts that have categories assigned are displayed in a list when filtered by category. On the home screen, press Start > All Programs. Select Contacts > [O]. Press Menu. Select Filter from the popup menu and press [O]. Select a category to filter.
SEND AN E-MAIL TO A CONTACT If a contact’s e-mail address is entered into their information, you can send an e-mail from within the contact list after selecting the contact. On the home screen, press Start > All Programs. Select Contacts > [O]. Select a contact and press [O].
ADD A PICTURE TO A CONTACT You may wish to add a picture to a contact record. You can add an existing picture, or you can put the phone in camera mode to take the picture and add it to the contact. On the home screen, press Start >...
ASSIGN A CATEGORY TO A CONTACT It may be helpful to group your contacts in categories you define for easier reference. If you know the contact’s category you can easily retrieve the contact. You can use categories to help you organize and group your contacts.
CREATE A SPEED DIAL You can create a speed dial for a phone number, e-mail address, or Web page address that is stored in Contacts. On the home screen, press Start > All Programs. Select Contacts > [O]. Select the contact for whom to create a speed dial and press [O]. Select the phone number, e-mail address, or Web page address for which to create a speed dial.
VIEW AND EDIT A SPEED DIAL You can view or edit all the contacts you’ve assigned to speed dial by entering the Speed Dial menu from the Start. On the home screen, press Start > All Programs > More. Select Applications > Speed Dial > [O]. Select a contact you want to change and press [O].
Call history provides details of all calls received, missed and dialed. On the home screen, press Start > All Programs > More. Select Call History > [O]. To view only missed calls, incoming calls, or outgoing calls, press [Menu] select Filter, and then press the type of calls to view. NOTE Call History is viewed on the main screen.
VIEW DETAILS ABOUT A CALL To review all the stored information on a call you will access the Call History function. On the home screen, press Start > All Programs > More. Select Call History > [O]. Select the call you want to view details for and press [O]. CREATE A CONTACT FROM CALL HISTORY While you are in the Call History function, you can select any of the calls and automatically add that caller to your contact list.
DIAL THE LAST NUMBER CALLED If you need to quickly call the last number you have called, this shortcut allows you to do so without using menus. On the home screen, press [S]. Select Call. INSERT AN INTERNATIONAL COUNTRY CODE To make an international call you must include a country code at the beginning of the dialing sequence for the phone number.
MY STUFF The My Stuff displays My Pictures, My Ringtones, My Videos, Notes, and Templates. My Stuff’s menu is same as File Explorer. Chapter 3. Calendar, Contacts, Call history & My stuff...
Voicemail is available at all times. When you call your voicemail the messages will be played back in the order they were received. You will have options to save, delete, replay, or skip each message. CALL YOUR VOICEMAIL BOX Retrieving your voicemail is simple and can be accessed directly from the home screen.
CREATE A TEXT MESSAGE The Pantech Matrix Pro allows you to create text messages quickly. You create a text message by typing in a phone number or by selecting a contact first.
MULTIMEDIA MESSAGE Multimedia Messaging Service allows you to send multimedia messages to others, which can include text, graphics and ring tones in a message. CREATE A MULTIMEDIA MESSAGE Creating a multimedia message is simple and you can add images or attachments to the message.
MULTIMEDIA MESSAGE MULTIMEDIA MESSAGE MENU OPTIONS The Menu supports advanced MMS composer option. Menu option Preview Press Menu >Preview. Preview is displayed when multimedia message has content (image, sound, text or video). Preview is not displayed when message is empty. Add Recipient You can add recipients address from Contact list or upload pictures to HP’s Snapfish.
Page 74
MULTIMEDIA MESSAGE Menu option Create Item You can add a picture, video or sound from camera and Voice Note. Press Menu > Create Item > Picture: Take a picture with camera and add it to multimedia message. Press Menu > Create Item > Video: Record a video with Camcorder and add it to multimedia message.
MULTIMEDIA MESSAGE Menu option Options You can set the importance of multimedia message. Press Menu > Options > Insert Page: Insert a new page at current page. Press Menu > Options > Delete Page: Delete current page. Press Menu > Options > Move Page: Change the order of current page.
MULTIMEDIA MESSAGE SELECT MULTIMEDIA MESSAGE IN THE LIST OF MESSAGE TYPE After selecting multimedia message from the Messaging menu, you will use the Menu to step through each field that is available when composing a message. On the home screen, press Start > All Programs > Messaging > [O].
MULTIMEDIA MESSAGE CHANGE HOW THE MESSAGE LIST DISPLAYS You can change the order in which messages are displayed and show the date and time that messages were received. On the home screen, press Start > All Programs > Messaging > [O].
The Pantech Matrix Pro allows you to send e-mails with several options. You can copy, blind copy, set priority, and store e-mails just as you would from a computer. The Pantech Matrix Pro uses Outlook as the default mail program.
FOLDER BEHAVIOR WITH A DIRECT CONNECTION TO AN E-MAIL SERVER The behavior of the folders you create depends on whether you are using POP3 or IMAP4. • If you use POP3 and you move e-mail messages to a folder you created, the link is broken between the messages on the phone and their copies on the mail server.
Enter your user information, such as user name, password, and press the Next. Enter the Outgoing (SMTP) mail server names and press the Next. Select how often your phone automatically connects to the server and checks for incoming e-mails ➊ Press the Finish.
E-MAIL OVERVIEW OF E-MAIL SECURITY You can help prevent impersonation, tampering, and eavesdropping when sending e-mail messages from your Outlook e-mail account by using Secure Multipurpose Internet Mail Extensions (S/MIME) digital signatures and encryption. A signature helps prevent impersonation and tampering. Impersonation occurs when a hacker sends e-mail messages and pretends to be someone else.
DOWNLOAD A COMPLETE E-MAIL MESSAGE You can save e-mail messages and retrieve them at any time when you synchronize or connect to your mail server. On the home screen, press Start > All Programs > Messaging > [O]. Select an e-mail account and the message to download. Press Menu >...
SEND AND RECEIVE INTERNET E-MAIL MESSAGES Using the Pantech Matrix Pro you can connect to the Internet to send and receive e-mails. On the home screen, press Start > All Programs > Messaging.
NOTE To stop this process, press Menu > Stop Send/Receive. ADD A VOICE RECORDING TO AN E-MAIL MESSAGE Inserting a voice recording is useful when you want to verbally explain information that is contained in the message. In the message area of an e-mail message, press Menu > Insert > Voice Note.
Setting Outgoing mail server Outgoing server requires authentication Outgoing server settings Use different user name for outgoing server User name Password Domain Require SSL connection (Outgoing mail server only) DELETE A MESSAGE Messages from any account can be deleted. Select the Messaging function from the home screen.
DELETE AN ACCOUNT You can delete accounts you have previously set up in the Messaging function. On the home screen, press Start > All Programs > Messaging > [O]. Select an account to delete. Press Menu > Delete. EDIT PREDEFINED TEXT You can edit the predefined text included with the phone to create words or phrases that you frequently use in messages.
FORWARD A MESSAGE When you have received a message, it is possible to forward the message to another account or user. From the received message opened, press Menu > Reply > Forward. Enter a message in the message area. Press Send. NOTE If you are forwarding e-mail from the Outlook e-mail account, you will send less data if you do not edit the original message.
Press Mark as Read or Mark as Unread. The message display is changed to reflect its new status: normal text for read messages and bold text for unread messages. When you synchronize or send and receive e-mail, the message is displayed as read or unread in all locations.
QUICKLY MOVE BETWEEN ACCOUNTS Your messages are stored in accounts and it is convenient to be able to move from account to account quickly. Do one of the following: • If you have an account open, you can quickly switch to another account by pressing [L/R].
Drafts. A draft of the message is stored in the Drafts folder of the account you are in. SPECIFY THE LANGUAGE FOR READING A MESSAGE OR COMPOSING The Pantech Matrix Pro has many languages and character sets from which to choose. Each message can be composed in whatever language you require.
VIEW AN ATTACHMENT Many e-mail messages come with attachments. You can view attachments for file types that are supported by the phone. In an open message containing a downloaded attachment, select the attachment. NOTE You can view attachments only for file types that are supported by the phone.
To quickly view new messages, press the message notification area in the home screen. VIEW THE LIST OF ACCOUNTS If you have added accounts to your phone, you can see a list of all the accounts at one time. On the home screen, press Start > All Programs > Messaging > [O].
USING THE ALARM You can use the alarm clock to set a wake-up alarm or set an alarm to remind you of an appointment. On the home screen, press Start > All Programs > More > Organizer > Alarm > [O]. Select Alarm1 or Alarm2 >...
In addition to making and receiving calls, scheduling and keeping contacts, the Pantech Matrix Pro allows you to save your own reminders and messages in voice format. CREATE A VOICE NOTE When you wish to create a voice note, after making the selections described here, you will speak into the microphone just as you would speak on a call.
DELETE A VOICE NOTE After you have no further need for a voice note, you can delete the note completely from the phone. On the home screen, press Start > All Programs > More > Organizer > Voice Note > [O]. Select the voice note to delete.
Using Notepad, you can create memos for important things, and manage them. TO ACCESS NOTEPAD On the home screen, press the Start > All Programs > More > Organizer > Notepad. CREATING A MEMO Press the New. Enter the memo text and press the Done. VIEWING A MEMO To view memo details, select the memo you want from the list.
USING THE CALCULATOR Perform standard mathematical operations such as addition, subtraction, multiplication, and division. On the home screen, press Start > All Programs > More > Organizer > [O]. Select Calculator > [O]. Enter a number using the keypad. Press Menu and choose the type of calculation to perform and Equals to perform the operation, then press [O].
USING THE WORLD TIME You can set up the world clock with the time zones you want, and then check the current time of the city you need at any time. On the home screen, press Start > All Programs > More > Organizer >...
CREATE A TASK The Pantech Matrix Pro allows you to create a new task with reminders for your task list from your phone or from your PC. On the home screen, press Start > All Programs > More > Organizer > [O].
Select the task to assign and press Edit. Select Categories and check the category you want. Press Done. NOTE A category will remain in the list of shared categories as long as it is assigned to at least one appointment, contact, or task. DELETE A TASK To remove a task from your list you will delete it.
Page 102
Select Tasks > [O]. In the task list, do one of the following: • To sort the list, press Menu > Sort by. Choose a sort option and press [O]. • To filter the list by category, to sort the list, press Menu > Filter. Choose the category you want displayed.
WINDOWS MEDIA PLAYER This device comes with Microsoft® Windows Media Player® 10.3. You can play Windows® Media Audio, Windows Media Video, and MP3 audio files that are stored on your phone, on a memory card, or on the Web. You can open Windows Media Player like this: On the home screen, press Start >...
WINDOWS MEDIA PLAYER Press the Sync > Edit Playlist. Select the media files > [O]. Select the saving location. Select the quality level and press [O]. Press Start Sync. In order to access libraries, you should press Menu from the player screen and then select Library.
Page 106
WINDOWS MEDIA PLAYER When libraries have been updated, press the Done. Select a category. Scroll to the library you want to play and press the Play. If the file does not appear in a library, on the Library screen, press the Menu >...
WINDOWS MEDIA PLAYER SETTING UP A PLAYLIST You can add media files on the Library screen to a temporary playlist. It lists the currently playing file, as well as any files that have been queued up to play next. Creating a playlist On the library screen, select the category you want and scroll to the file you want to play.
Page 108
WINDOWS MEDIA PLAYER • Video: Select the viewing options for playing videos on a full screen. NOTE: If there is a problem while playing MP4 files, deselect the Scale to fit window option. The problem occurs because the file has been resized.
This menu connects to AT&T’s music download site. On the home screen, press Start > All Programs > AT&T Music > [O]. Select Shop Music > [O]. Chapter 6. AT&T Music SHOP MUSIC...
This menu allows you to find out title, artist and other information about the song by just sending the sound of the song. On the home screen, press Start > All Programs > AT&T Music > [O]. Select MusicID > [O]. •...
USING MANAGE ID’S Highlight manage ID’s > [O]. The screen displays a list of the most recent successful song ID’s which were made. Highlight a song and press the Options. Highlight one of the following options and press the [O]. •...
XM RADIO MOBILE Selecting XM Radio Mobile from the AT&T Music sub menu launches an application which allows the user to listen to streaming audio. On the home screen, press Start > All Programs > AT&T Music > [O]. Select XM Radio Mobile > [O]. Chapter 6.
Selecting Music Videos from the AT&T Music sub menu launches an application called MobiVJ which allows the user to listen to streaming music videos. On the home screen, press Start > All Programs > AT&T Music > [O]. Select Music Videos > [O]. Chapter 6.
Selecting Pandora from the AT&T Music sub menu launches an application which allows the user to listen to personal radio. On the home screen, press Start > All Programes > AT&T Music > [O]. Select Pandora > [O]. Chapter 6. AT&T Music PANDORA...
Selecting Community from the AT&T Music sub menu launches the browser to either one or more of the hot user communities. This menu allows you to interact with your friends and the community. On the home screen, press Start > All Programs > AT&T Music > [O].
Selecting this menu launches the Web browser to AT&T’s Tones menu. On the home screen, press Start > All Programs > MEdia Mall > [O]. Select Shop tones > [O]. Follow the on-screen options. The downloaded files can be stored into the Main Memory or Storage Card found within the My Stuff (Phone) location.
Selecting this menu launches the Web browser to AT&T’s Game menu. On the home screen, press Start > All Programs > MEdia Mall > [O]. Select Shop Games > [O]. Follow the on-screen options. Categories include: – New Releases – Retro & Arcade –...
SHOP GRAPHICS Selecting this menu launches the Web browser to AT&T’s Graphics. On the home screen, press Start > All Programs > MEdia Mall > [O]. Select Shop Graphics > [O]. Follow the on-screen options. The downloaded files can be stored in the My Pictures folder found within the My Stuff (Phone) location.
SHOP MULTIMEDIA Selecting this menu launches the Web browser to AT&T’s Multimedia menu. On the home screen, press Start > All Programs > MEdia Mall > [O]. Select Shop Multimedia > [O]. Follow the on-screen options. The downloaded files can be stored in the My Document folder found within the My Stuff (Phone) location.
SHOP APPLICATIONS Selecting this menu launches the Web browser to AT&T’s Applications menu. On the home screen, press Start > All Programs > MEdia Mall > [O]. Select Shop Applications > [O]. Follow the on-screen options. When you are ready to purchase the application, press the Buy Now to charge your e-wallet account and complete the transaction.
MEDIA NET HOME The MEdia Net Home menu option allows you to quickly access your AT&T MEdia Net homepage using the built-in browser. This page gives you quick access to information such as local weather, sports scores, horoscope information and quick links to the previously mentioned shopping sites.
CELLULAR VIDEO Your phone is equipped with a WAP (Wireless Application Protocol) browser which allows you to access Internet and then upload media files directly to your phone. These media files are displayed using the built-in Media Player. Cellular Video (CV) is a media service which allows you to not only navigate to your favorite web sites but stream media content (Weather, News/Sports highlights, etc.) directly to your phone.
MEDIA CLIP OPTIONS With the media currently active on the phone (either playing or paused), press the Menu to open a list of the following streaming media options. LIBRARY This feature launches the Windows Media Library showing My Music, My Videos, My TV, My Playlists, and Now Playing. PLAY/PAUSE This feature allows you to toggle the state of the current video between being Paused or Resuming playback.
MEDIA CLIP OPTIONS • Video – Play video in full screen: Choose from Never, Only when oversized, or Always. – Scale to fit window: Allows you to fit the picture to the screen. • Network – Internet connection speed: Choose the internet connection speed to download the videos.
USING THE VIDEO CATEGORIES This grouping of media categories provides access to an additional listing of streaming media. Where the previous Favorites list of media stream can be user edited and updated, this list of categories is defined by AT&T’s homepage and cannot be changed. VIEWING A VIDEO CLIP On the home screen, press the Start >...
CUSTOMIZING CELLULAR VIDEO UPDATING THE FAVORITES LIST The list of media providers which appears in the Favorites section of the Cellular Video homepage can be edited and changed by the user. On the home screen, press the Start > All Programs > Cellular Video >...
The Cellular Video homepage can be used to shop for streaming multimedia content. The My Purchases can help keep track of your purchase history and view any new resale products. On the home screen, press the Start > All Programs > Cellular Video >...
PARENTAL CONTROLS Your phone can be configured to block both purchased and streamed media content. Before filtering, you must first establish a PIN code and e-mail address. Once those have been established, you can choose one of the two available filter options: Content Filter and Purchase Blocker. •...
INSTANT MESSAGING Your handset comes with the ability to sign onto Instant Messaging. You must first create an active account using your PC, and then you can connect and chat using the following applications: AOL Instant Messenger Windows Live Messenger Y! Messenger On the home screen, press the Start >...
With MobiTV your phone becomes a portable TV. See channels you watch at home, made for mobile programming, and the latest primetime shows from NBC, like Friday Night Lights. The Emmy® Award winning service is available through your wireless carrier and offers over 100 TV channels worldwide, such as MSNBC, ABC News Now, CNN International, FOX News Channel, Fox Sports, ESPN 3GTV, NBC Mobile, Bravo To Go, Sci Fi Pulse Mobile, Telemundo Mobile, Discovery...
OFFICE MOBILE EXCEL MOBILE View spreadsheets, even when you’re out of the office. You can use the Chart Wizard to view Microsoft Office Excel Mobile charts on the go. ONENOTE MOBILE Microsoft OneNote Mobile is a tool for notetaking, information gathering, and multi-user collaboration by Microsoft.
CAMERA / CAMCORDER MODE Use the camera program to take, view, and edit pictures as well as record and launch video clips stored on your device or on a storage card. You can also send pictures and video clips to others, or set a picture as the background in the home screen.
CAMERA / CAMCORDER MODE NOTE For best results, use images with the same screen resolution as your phone’s screen resolution, either 240 x 320 pixels, or 176 x 200 pixels, depending on the phone. See also Change the home screen appearance TAKE VIDEOS USING A TIMER Using the timer, you can be in the picture you take.
Applications > File Explorer > My Pictures. Press Menu > Edit > New Folder. EDIT A PICTURE You can actually edit pictures and videos on the Pantech Matrix Pro using the Menu. On the home screen, press Start > All Programs > More >...
CAMERA / CAMCORDER MODE To undo an edit, press Menu > Undo. To cancel all unsaved edits made to the picture, press Menu > Cancel. VIEW PICTURES AS A SLIDE SHOW However you have stored the pictures and videos, you can review them consecutively in a slide show format.
CAMERA / CAMCORDER MODE SEND A PICTURE VIA MULTIMEDIA MESSAGE You can attach pictures to messages and send them to someone else. On the home screen, press Start > All Programs > More > Applications > File Explorer > My Pictures. Select the picture to send.
CAMERA / CAMCORDER OPERATIONS CAMERA • Supports JPEG File Format (jpg) VIDEO • Supports QCIF (176x144) size of video • Supports 3gp File Format (3gp) RECORD A VIDEO By using the camera function, you can take pictures or you can record video by selecting the Camcorder option.
CAMERA / CAMCORDER OPERATIONS TAKE A PICTURE • Supports 144x176, 240x320, 480x640, 600x800, 1024x1280, 1200x1600 size of picture. • Stored JPEG file format (jpg) • You can choose Low, Normal or High quality. TAKE A PICTURE (MULTISHOT) • Supports maximize resolution of 144x176, 240x320. •...
CAMERA / CAMCORDER OPERATIONS VIDEO SHARE You can do Video Share by selecting the camera menu. On the home screen, press Start > All Programs > More > Applications > Camera. Press Options > Video Share Select phone number in the list, and press Call. Chapter 10.
CAMERA / CAMCORDER CONTROLS Just as with an ordinary camera, your phone can be adjusted to control the brightness, color, resolution, etc. From the Menu you have access to all the image parameters you will want to adjust. CAMERA MENU The menu is reached after selecting camera from the home screen and gives you access to these parameters: white balance, Effect, Timer, Size, Quality, and Advanced Settings.
CAMERA / CAMCORDER CONTROLS Item Resolution Choose a Resolution in Options > Settings > Resolution. Default value is 1200x1600. 144x176: Resolution is in 144x176. 240x320: Resolution is in 240x320. 480x640: Resolution is in 480x640. 600x800: Resolution is in 600x800. 1024x1280: Resolution is in 1024x1280. 1200x1600: Resolution is in 1200x1600.
CAMERA / CAMCORDER CONTROLS Item White Balance Choose White Balance in Options > Settings > W/B. Default value is Auto. Daylight: Control of the white value. Cloudy: Setting of the white value. Fluorescent: Setting of the white value. Incandescent: Setting of the white value. Effect Choose color effect in Options >...
CAMERA / CAMCORDER CONTROLS Press Done to apply the chosen values. The camera screen is displayed. If you do not wish to apply new values, press [C]. Item Time Out Choose Time Out in list. Default value is 1 Min. 1 Min: Time Out is 1 Min.
CAMERA / CAMCORDER CONTROLS Item Take Mode Choose Take Mode in list. Default value is Normal. Change Multi Shot mode. Resolution must be 176x144 or 320x240 on Multi Shot mode. Multi-shot Count Choose Multishot in list. Default value is 4. 4: Make a photograph 4 times in a row.
Page 150
CAMERA / CAMCORDER CONTROLS Item Recording Sound Choose recording with audio or not. Default value is On. On: Sound Recording is on. Off: Sound Recording is off. Video Prefix Change video prefix. Default video prefix is video. Overview of the default hardware button assignments By default, these hardware buttons are assigned to camera functions.
USING INTERNET EXPLORER ADD A WEB PAGE TO THE FAVORITES LIST Internet Explorer functions on your phone much the same as it does on your PC. You can maintain a list of web sites in your favorites list. Add each site to the list through the Internet Explorer menus. On the home screen, press Start >...
USING INTERNET EXPLORER CHANGE WEB PAGE DISPLAY OPTIONS There are Web page display options to choose from: text size, one column, fix to screen, and desktop. On the home screen, press Start > All Programs > More > Internet Explorer. Select one of the web sites.
USING INTERNET EXPLORER CREATE A NEW FOLDER IN FAVORITES If you have more than a few web sites in your Favorites list, it may be convenient to arrange the sites in folders on your favorites list. On the home screen, press Start > All Programs > More > Internet Explorer.
USING INTERNET EXPLORER EDIT A FAVORITE You can change the name, URL, or description of a web site in your favorites list. On the home screen, press Start > All Programs > More > Internet Explorer. Press Favorites. Select the favorite to edit. Press Menu >...
USING INTERNET EXPLORER GO TO A WEB PAGE IN THE HISTORY LIST You also have access to web pages you’ve visited by using the History list in Internet Explorer. On the home screen, press Start > All Programs > More > Internet Explorer.
USING INTERNET EXPLORER VIEW A FAVORITE To view a favorite site at any time, just go into the Favorites list and select the site you wish to visit. On the home screen, press Start > All Programs > More > Internet Explorer.
USING INTERNET EXPLORER CHANGE THE ZOOM LEVEL ON WEB PAGES The text on the Web pages displayed on your phone can be made larger or smaller. On the home screen, press Start > All Programs > More > Internet Explorer. Press Menu >...
USING INTERNET EXPLORER SEND A LINK VIA E-MAIL One of the options your phone provides is sending a link through e-mail. You will use the Tools menu on the Internet Explorer menu bar. On the home screen, press Start > All Programs > More > Internet Explorer.
Microsoft ActiveSync synchronizes data between your phone and PC. ActiveSync is already installed on you phone, but you need to install it on your PC before you can synchronize data. INSTALL AND SET UP ACTIVESYNC Install ActiveSync on your PC as described on the Windows Mobile Getting Started Disc.
Before changing synchronization settings on the phone, disconnect it from your PC. In the phone home screen, press Start > All Programs > ActiveSync > [O]. Press Menu > Configure Server > [O]. If you have not yet set up sync with Exchange Server, this will say Add Server Source.
SCHEDULE SYNCHRONIZATION AS ITEMS ARRIVE You can schedule automatic synchronization between your phone and Exchange Server every time an item arrives or is changed in Exchange Server if your company is running Exchange Server with Exchange ActiveSync, and after your first full synchronization with Exchange Server. On the phone home screen, press Start >...
IMPORTANT NOTE The device power-down timer is reset each time you synchronize. If you schedule a synchronization interval that is shorter than the time interval set for the device to automatically power down, the device will never turn off to save battery power.
CHANGE SETTINGS FOR AN INFORMATION TYPE Before changing synchronization settings on the phone, disconnect it from your PC. On the home screen, press Start > All Programs > ActiveSync > [O]. Press Menu > Options > [O]. Select one of the information types. Do one of the following: •...
You must deactivate the USB modem if you want to use ActiveSync. CONNECT TO A PC USING CHARGEABLE USB CABLE The Pantech Matrix Pro provides a USB connector for transferring data to and from your computer via USB cable. Plug the USB Data Cable into a standard USB connector of your computer.
If this is the first time you have connected to this PC via Bluetooth, you must complete the Bluetooth wizard on the phone and set up a Bluetooth partnership with the PC before synchronizing. Press Sync. When finished, press Menu > Disconnect Bluetooth. To preserve battery power, turn off Bluetooth.
EXCLUDE AN E-MAIL ADDRESS FROM REPLY ALL ActiveSync can help you manage your e-mail by ignoring a specified e-mail address when you reply to all senders from the phone. If you specify your own primary e-mail address, this can reduce the number of e-mails you receive by ensuring that you do not receive your own e-mail.
INTERNET SHARING INTERNET SHARING WITH BLUETOOTH Make PC access Internet through Bluetooth wireless. You can access Internet with PC through Bluetooth Internet Sharing. Make Bluetooth wireless power on and visible. Launch Internet sharing, press Start > All Programs > More > More >...
REMOTE DESKTOP What this feature does Remote Desktop provides a way for you to establish a remote connection with a host computer that is running Windows Terminal Services. On the home screen, press Start >All Programs > More > More > Remote Desktop >...
Your phone supports Bluetooth wireless pairing (also called linking or bonding). You can pair your phone with a Bluetooth headset or car kit or pair your phone with a computer to exchange and synchronise files. NOTE The use of wireless devices and their accessories may be prohibited or restricted in certain areas.
Select Settings by pressing [U/D] on the home screen, and then select Wireless Manager by pressing [L/R]. PAIR WITH A BLUETOOTH DEVICE Ensure that the two devices are within close range and that both Bluetooth-enabled devices are discoverable. On the home screen, press Start >All Programs > More > More > Bluetooth >...
Select the name of the device to send the file. To cancel sending an item, press Cancel. USE YOUR PHONE AS A PC REMOTE You can use Bluetooth wireless and your phone as a remote control for your computer. For example, want to watch a video on your computer and use your phone as a remote control? Use PC Remote to control when the video plays, stops or pauses.
ADVANCED BLUETOOTH FEATURES Make phone visible to other device Allow a Bluetooth device to discover your phone: On the home screen, press Start > All Programs > More > More > Bluetooth > [O]. Select Bluetooth Manager > [O]. If necessary, press Yes to turn on Bluetooth power.
Page 175
Send object to device Send an object to another device: On the home screen, press Start > All Programs > More > More > Bluetooth > [O]. Select BT Send Object > [O]. Edit device properties / change device name Edit the properties of a recognized device: On the home screen, press Start >...
This phone has File Explorer, which opens an explorer window. This is very similar to the one that Microsoft Windows® has. File Explorer will allow you to navigate to folders and files, and it will allow you manage, delete, copy, or edit files and folders on your phone. On the home screen, press Start >All Programs >...
JAVA Pantech Matrix Pro is a Java MVM (Multi-VM) enabled phone, and it provides three Java demo applications by default; My-Cast Weather, BrainChallange2 Demo, and Midnight Pool Demo. For the multi-MIDlet management, this phone provides Application Manager. The Application Manager is accessible from the Menu or by pressing the camera key when a MIDlet is excuted.
JETCET PDF Open and view PDF files received via e-mail, downloaded from the Internet or transferred over the network on the Smartphone with Westtek’s JETCET PDF. With the integrity of the original files intact, the information can be accessed just as the author intended. JETCET PDF does not require any file conversion, desktop connection or ActiveSync®...
MOBILE BANKING Mobile Banking is a term used for performing balance checks, account transactions, payments etc. via a mobile device such as a Pantech Matrix Pro. On the home screen, press Start > All Programs > More > Applications > [O].
MY-CAST WEATHER Now you can get weather on your cell phone! Anytime and anywhere you are. For more information, check the website http://www.my-cast.com Chapter 13. Applications...
This phone has Speed Dial, with access to a phone number with a shortcut number for speed dialing or to an e-mail or URL address for quick access. On the home screen, press Start > All Programs > More > Applications >...
Task Manager will help you resolve problems when the phone freezes. It can also help you solve memory problems and allow you to terminate unnecessary tasks. On the home screen, press Start >All Programs > More > Applications > More > [O]. Scroll to Task Manager >...
VOICE COMMANDER “Voice Commander” is a Speech Dialog System that provides natural human interface for users to communicate seamlessly with mobile devices. Through Voice Commander, users can make phone calls, look up contact info, launch program or check for calendars. It contains the following features.
Page 188
VOICE COMMANDER The recognizable contact length is 48 characters. For those exceed 48 characters will be ignored. 2. Voice Find Contact • You can use "Voice Commander" to look up contact information. • Usage: Find <Contact> at <Home/Work/Mobile> Example> "Find Mary Smith ", "Find Michael Archer at work", "Find Michael Archer at home"...
VOICE COMMANDER 8. SMS • You can use "Voice Commander" to look up unread SMS. • Usage: Read SMS. 9. What time is it • You can use "Voice Commander" to do time query. • Usage: What time is it ? 10.
VOICE COMMANDER “VOICE COMMANDER SETTINGS” MAIN FUNCTIONS “Voice Commander Settings” helps you to personalize the system. There are five major functions. They are “Contacts”, “Application”, “Music” and “Advanced Settings”. “Voice Commander Settings”, there is ways to start it: Start > All Programs > More > Applications > More > Voice Commader >...
Page 191
VOICE COMMANDER A check box will be shown in front of each name. • When a box is checked, means the application can be recognized normally. • When a box is unchecked, means the recognition is not in the recognition range. •...
Page 192
VOICE COMMANDER Voice Button Setting Set the voice commander quick key. 5. Voice Tag Voice tag User can record voice tag for selected music file to enhance “Voice Commander” usability and accuracy. A trailing lip icon represents voice tag built. “Voice Tag Settings”, there is ways to start it: After running “Voice Command setting”, press Menu >...
AUTO ANSWER Set how quickly calls are automatically answered during hands-free operation. These settings do not apply when the ring type is Silent. AUTO LOCK Refer Basic functions of the Chapter 2 Basic Operation. CALL FORWARDING On the home screen, press Start >All Programs > More > Settings >...
• Voice mail number: When you insert your SIM card into your phone, the phone automatically detects and sets your voicemail number. • Text messages service center: When you insert your SIM card into your phone, SMS accesses the number by default. If not, you can manually enter the numbers obtained from your service provider.
NOTE To edit the channel list, press the Menu and select Edit Channels. Then press the Menu and select the options for adding, deleting or editing channels. FIXED DIALING When this option is activated, your phone allows outgoing calls only to the limited set of phone numbers.
SERVICE DIALING NUMBERS (SDN) You can view the list of Service Dialing Numbers (SDN) assigned by your service provider. These numbers include emergency numbers, customer service numbers and directory inquiries. NOTE This menu is available only when your SIM card supports Service Dialing Numbers.
The Pantech Matrix Pro comes with a large standard set of ring tones and sounds. You can also add your own as long as they are in the correct format. CHANGE OR TURN SOUNDS ON OR OFF Any sound can be toggled on or off at any time, or you can turn the phone’s sound off altogether.
COPY A SOUND FROM YOUR PC TO YOUR PHONE After a sound file is located on your phone, you can use it for a ring tone. Sound files in .wav, .mid, mp3 or .wma formats can be used. Connect the phone to your PC using a USB connection. On your PC, copy the sound file you want.
VIEW THE LIST OF PROFILES You can store a set of parameters and options for your phone in what is known as a “profile”. By developing and selecting a profile you will be establishing the baseline features of operation for the phone. On the home screen, press Start >...
Change the home screen appearance On the home screen, press Start > All Programs > More > Settings > Home Screen. Select each option: Home screen layout, Color scheme, and Background image. Under Time out, select the length of time you want the home screen to be displayed if you are not using the device, and press Done.
CLOCK & ALARM SET THE DATE AND TIME On the home screen, press Start > All Programs > More > Settings > Clock & Alarm >Date and Time. • Time Zone: Select your time zone. • Date: Edit the month, day, or year. •...
WIRELESS MANAGER You can turn the power off to your wireless connections in a single location. This is a quick way to preserve battery power or to prepare your device for an airplane flight. On the home screen, press Start > All Programs > More > Settings >...
• User name: Enter your network user name, if required. • Password: Enter your password, if required. • Domain: Enter the domain name, if required. Press Done. CREATE A GPRS CONNECTION Every network connection is different. You should gather all of the relevant information or network settings you need before starting this process.
CREATE A PROXY CONNECTION Every network connection is different. You should gather all of the relevant information or network settings you need before starting this process. On the home screen, press Start > All Programs > More > Settings > Connections. Press Proxy.
• Connects from: Select the type of network from which you will connect to the VPN (typically The Internet). • Connects to: Select the type of network to which you will connect (typically My Corporate Network). • User name: Enter your user name for the VPN. •...
DELETE A PROXY CONNECTION On the home screen, press Start > All Programs > More > Settings > Connections. Press Proxy. Select the connection to delete. Press Menu > Delete. Press Yes. CHANGE AN INTRANET URL On the home screen, press Start > All Programs > More > Settings >...
USB TO PC You can change the type of USB connection to solve problems connecting ActiveSync. On the home screen, press Start > All Programs > More > Settings. Press Connections > USB to PC. MODEM LINK On the home screen, press Start > All Programs > More > Settings.
Your Pantech Matrix Pro has several easy-to-use security features. You can enable the device lock, or you can enable security certificates such as SSL. ENABLE THE DEVICE LOCK On the home screen, press Start > All Programs > More. Select Settings > [O].
ACTIVATING THE SIM PIN When SIM PIN is enabled, you must enter your PIN supplied with your phone each time you turn the phone on or insert the current SIM card into another device. Consequently, any person who does not have your PIN cannot use your phone without your approval.
VIEW A CERTIFICATE Your phone is able to use personal security certificates that you add to the phone and it also has root certificates that come pre-installed. On the home screen, press the Start > All Programs > More. Select Settings > [O]. Scroll to Security >...
ENCRYPTION When you will want to encrypt any files, select ‘Encrypt files placed on storage cards’ check box. You can save encrypted files which are placed on a storage card. Such files are readable only by this Windows Mobile- based device. CHANGING MASTER CLEAR PASSWORD On the home screen, press the Start >...
REMOVE PROGRAMS You can remove programs that have been added to the phone at any time. Be sure that you select the right program before removing it. On the home screen, press the Start > All Programs > More. Select Settings > [O]. Scroll to Remove Programs.
POWER MANAGEMENT You can use Power Management to check the battery and configure settings that prolong battery life. On the home screen, press Start > All Programs > More. Select Settings > [O]. Scroll to Power Management > [O]. Adjust the following: •...
On the home screen, press Start > All Programs > More. Select Settings > [O]. Select More... > [O] > Video Share. Modify the settings and press Done. Item Alerts Auto Record Recording Location IMS Service Chapter 14. Settings VIDEO SHARE Description Allows you to turn On or Off the Video Share Alerts which displays a message and a tone.
The accessibility settings will determine the size of the text and characters, time outs, call alerts, and volumes on the phone. On the home screen, press Start > All Programs > More. Select Settings > [O]. Select More... > [O] > Accessibility. Using the [L/R], select your preferences for the following: •...
REGIONAL SETTINGS You can specify the language, locale, date and time style, as well as number and currency formatting options. On the home screen, press Start > All Programs > More. Select Settings > [O]. Select More... > [O] > Regional Settings. Adjust the following: •...
OWNER INFORMATION You can save the user’s name, phone number, E-mail address, etc using Owner Information setting and save memo using note. On the home screen, press Start > All Programs > More. Select Settings > [O]. Select More... > [O] > Owner Information. Enter the information and press Done.
You can see your device’s information such as Windows Mobile® version and software version. On the home screen, press Start > All Programs > More. Select Settings > [O]. Select More... > [O] > About. Chapter 14. Settings ABOUT...
Your device uses this information to identify itself to other devices. You can change your device name. On the home screen, press Start > All Programs > More. Select Settings > [O]. Select More... > [O] > Device Name. Write your device name and press Done. Chapter 14.
ERROR REPORTING Error Reporting sends information needed by technical support groups to diagnose a program error for a device running Windows Mobile software. A text file is created whenever an error is detected, and can be delivered to support personnel if you choose to send it. If a program error occurs, Error Reporting starts automatically.
CUSTOMER FEEDBACK If you participate in the Customer Experience Improvement Program, enable the Feedback Reportig. On the home screen, press Start > All Programs > More. Select Settings > [O]. Select More... > [O] > Customer Feedback. Chapter 14. Settings...
WINDOWS UPDATE You can update your Windows Mobile device® using this fuction. On the home screen, press Start > All Programs > More. Select Settings > [O]. Select More... > [O] > Windows Update. Chapter 14. Settings...
You will register your E-mail account On the home screen, press Start > All Programs > More. Select Settings > [O]. Select More... > More... > [O] > Setup E-mail > [O]. Write your E-mail address and password. Press Next and follow the instructions to register your E-mail account.
MANAGED PROGRAMS Managed Programs will help you resolve problems when the phone freezes. It can also help you solve memory problems and allow you to terminate unnecessary programs. On the home screen, press Start > All Programs > More. Select Settings > [O]. Select More...
BRAIN CHALLENGE V2 DEMO Just like your body, your brain needs to exercise to stay in shape. Maintaining it simply involves completing little exercises without pain, stress, or boredom. That’s where Brain Challenge™ comes in! It’s like a real vitamin boost for your brain. Brain Challenge is more than just a game or program.
BUBBLE BREAKER OVERVIEW OF BUBBLE BREAKER Bubble Breaker is easy to learn, yet difficult to master. The objective is to align similar bubbles to form large blocks of bubbles before bursting them. The more bubbles you have in the block before they are burst, the greater number of points you will receive.
BUBBLE BREAKER – Continuous: Whenever a vertical set of bubbles has been burst and the remaining bubbles have shifted over to the right, a new, randomly selected column of bubbles will pop up on the left, allowing a game to be played for an extended amount of time. –...
GUITAR HERO 3 MOBILE Guitar Hero® – the award-winning global phenomenon – is available on mobile! Rock out anytime, anywhere with this rhythm-based, three button game that stays true to the original. Open with 15 jamming tracks, all taken from the Guitar Hero console series •...
The Jewel Quest phenomenon continues with all-new addictive puzzle fun. Rupert picks up a new treasure trail in search of the grandest Jewel Board ever! Guide him through the mystery as he explores Africa in search of jewels and his lost love. START A GAME OF JEWEL QUEST II On the home screen, press Start >...
MIDNIGHT POOL – DEMO In Gameloft’s Midnight Pool™, you can pit yourself against a host of colorful characters ranging in skill from amateur to veritable pool shark, challenging them and betting on matches. Link up your trick shots during challenges and games using either US 8-ball, UK 8-ball or 9 ball rules, depending on your preference.
MS. PAC-MAN – DEMO Ms. Pac-Man is an arcade video game produced by Midway as an unauthorized sequel to Pac-Man. It was released in North America in 1981 and became one of the most popular video games of all time, leading to its adoption by Pac-Man licenser Namco as an official title.
Page 234
MS. PAC-MAN – DEMO • The orange ghost's name changed from Clyde to Sue. (Sue would later become a purple female ghost in Pac-Land, appearing alongside Clyde.) • The three intermissions have changed to follow the developing relationship between Pac-Man and Ms. Pac-Man (from when they first meet to having a stork drop off their baby).
Mobile SCRABBLE® spells major fun! This exciting update of the classic board game now includes flexible difficulty levels, built-in word list, dynamic animations, scrolling and full-board views. An easy-to-use interface lets you play alone, challenge the computer in your phone, or enjoy pass ‘n play with a friend.
START A GAME OF SOLITAIRE On the home screen, press Start > All Programs > More > Games > Solitaire. Start new game. When you have finished playing a game, begin a new one by pressing Menu > New Game. HOW TO MOVE CARDS A number or character is displayed above each card stack.
Tetris®. Captivating, fun, addicting. See why more than 60 million players worldwide have made Tetris® one of the most popular games ever! The latest mobile Tetris® adds multiplayer to the fun. Play against a friend over a wireless network, or battle the computer in your phone. Block your opponent’s efforts to clear lines.
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES Read this information before using your Handheld Portable Cellular Telephone. EXPOSURE TO RADIO FREQUENCY SIGNALS Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES DRIVING SAFETY Talking on the phone while driving is extremely dangerous and is illegal in some states. Remember, safety comes first. Check the laws and regulations on the use of phones in the areas where you drive. Always obey them.
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES ELECTRONIC DEVICES Most modern electronic equipment is shielded from RF energy. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone. Pacemakers The Health Industry Manufacturers Association recommends that a minimum separation of six (6”) inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker.
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES Aircraft FCC and Transport Canada Regulations prohibit using your phone while in the air. Turn your phone OFF before boarding an aircraft. Blasting areas To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area”...
Your Handheld Portable Telephone is a high quality piece of equipment. Before using the device, please read all the instructions and cautionary markings on (1) AC Adaptor (2) Battery and (3) Product Using Battery. DO NOT use this equipment in an extreme environment where high temperature or high humidity exists.
Page 244
PRECAUTIONS WARNING! Read this Information before using Cautions In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters.
SAFETY INFORMATION FOR FCC RF EXPOSURE This device was tested for typical body-worn operations with the back of the phone kept 2.0 cm. from the body. To maintain compliance with FCC RF exposure requirements, use only belt-clips, holsters or similar accessories that maintain a 2.0 cm.
SAR INFORMATION THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S.
SAR INFORMATION with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on PP4TX-215. Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Association (CTIA) website at http://www.wow-com.com. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue.
FCC & INDUSTRY COMPLIANCE FCC & Industry Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 249
FCC & INDUSTRY COMPLIANCE interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Statement according to FCC part 15.21: Modifications not expressly approved by this company could void the user’s authority to operate the equipment. RF exposure FCC For body worn operation, to maintain compliance with FCC RF exposure guidelines, use only accessories that contain no metallic components...
FCC HEARING-AID COMPATIBILITY REGULATIONS FOR WIRELESS DEVICES FCC ID: JYCC820 Trade Name/Model(s): AT&T/ C820 FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §20.19 HAC Standard: ANSI PC63.19-2005 D3.6 On July 10, 2003, the U.S. Federal Communications Commission (FCC) Report and Order in WT Docket 01-309 modified the exception of wireless phones under the Hearing Aid Compatibility Act of 1988 (HAC Act) to require digital wireless phones be compatible with hearing-...
FCC HEARING-AID COMPATIBILITY REGULATIONS FOR WIRELESS DEVICES In the above example, if a hearing aid meets the M2 level rating and the wireless phone meets the M3 level rating, the sum of the two values equal M5. This should provide the hearing aid user with “normal usage” while using their hearing aid with the particular wireless phone.
FDA CONSUMER UPDATE U.S. Food and Drug Administration – Center for Devices and Radiological Health Consumer Update on Wireless Phones 1. Do wireless phones pose a health hazard? The available scientific evidence does not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe.
Page 253
FDA CONSUMER UPDATE FDA belongs to an interagency working group of the federal agencies that have responsibility for different aspects of RF safety to ensure coordinated efforts at the federal level. The following agencies belong to this working group: • National Institute for Occupational Safety and Health •...
Page 254
FDA CONSUMER UPDATE 4. What are the results of the research done already? The research done thus far has produced conflicting results, and many studies have suffered from flaws in their research methods. Animal experiments investigating the effects of radiofrequency energy (RF) exposures characteristic of wireless phones have yielded conflicting results that often cannot be repeated in other laboratories.
Page 255
FDA CONSUMER UPDATE 6. What is FDA doing to find out more about the possible health effects of wireless phone RF? FDA is working with the U.S. National Toxicology Program and with groups of investigators around the world to ensure that high priority animal studies are conducted to address important questions about the effects of exposure to radiofrequency energy (RF).
Page 256
FDA CONSUMER UPDATE 8. What has FDA done to measure the radiofrequency energy coming from wireless phones? The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical standard for measuring the radiofrequency energy (RF) exposure from wireless phones and other wireless handsets with the participation and leadership of FDA scientists and engineers.
Page 257
FDA CONSUMER UPDATE 10. What about children using wireless phones? The scientific evidence does not show a danger to users of wireless phones, including children and teenagers. If you want to take steps to lower exposure to radiofrequency energy (RF), the measures described above would apply to children and teenagers using wireless phones.
Page 258
FDA CONSUMER UPDATE 12. Where can I find additional information? For additional information, please refer to the following resources: • FDA web page on wireless phones (http://www.fda.gov/cdrh/ phones/index.html) • Federal Communications Commission (FCC) RF Safety Program • (http://www.fcc.gov/oet/rfsafety) • International Commission on Non-Ionizing Radiation Protection (http://www.icnirp.de) •...
PROTECT YOUR WARRANTY Read your Warranty carefully, with special consideration to paragraph seven of the Limited Warranty for your unit. “Warranty does not apply to or to any product or part thereof which has suffered through alteration, mishandling, misuse, neglect or accident”. Many companies are making look-alike accessories and in some cases, promoting their product is equal to or better than the AT&T product.
MANUFACTURER’S WARRANTY 12 MONTH LIMITED WARRANTY The AT&T Personal Communications (the Company) warrants to the original retail purchaser of this AT&T handheld portable cellular telephone, that should this product or any part thereof during normal consumer usage and conditions, be proven defective in material or workmanship that results in product failure within the first twelve (12) month period from the date of purchase, such defect(s) will be repaired or replaced (with new or rebuilt parts) at the Company’s option, without...
Page 261
MANUFACTURER’S WARRANTY device utilizes a SIM or Multimedia card, please remove the card before submitting the device and store for later use when your device is returned, the AT&T Personal Communications is not responsible for and does not guarantee restoration of any third-party software, personal information or memory data contained in, stored on, or integrated with any wireless device, whether under warranty or not, returned to the AT&T Personal Communications for repair or service.
