DSS-7000
This information is usually printed on the battery label.
Rating Description
CCA Cold Cranking Amps: Battery
current at 0 ºF (–17.8 ºC).
CA
Cranking Amps: Battery current
at 32°F (0 ºC).
JIS Japanese Industrial Standard:
Usually printed on battery label.
DIN(A) Deutsche Industrie-Norm
SAE(A) European labeling of CCA
IEC(A) International Electrotechnical
Commission
EN(A) Europa-Norm
EN2(A) Europa-Norm
Battery Rating
Tap on the box and use the keypad displayed on the
Tablet Controller to enter the battery rating.
NOTE: When JIS is selected, use the drop-down
menu to scroll to the correct JIS number.

Battery Test Results

After the test the tester displays one of five battery decisions
along with the complete results.
Tap PRINT to print the test results or EMAIL to email the
results to the customer. To return to the Home Screen, tap
DONE.
Decision
GOOD BATTERY Return the battery to service.
GOOD– Fully charge battery and return to
RECHARGE service.
CHARGE & Fully charge the battery and retest.
RETEST Failure to fully charge the battery
before retesting may cause false
readings. For a repeated CHARGE &
RETEST decision, replace battery.
www.midtronics.com
Range
100 to 3000
100 to 3000
26A17 to
245H52
100 to 1000
100 to 3000
100 to 1000
100 to 1700
100 to 1700
?
Recommended Action
REPLACE May also mean a poor connection
BATTERY * between battery cables and battery.
After disconnecting battery cables,
retest battery using Battery Test before
replacing.
BAD CELL– Replace the battery and retest.
REPLACE

Pre Sale

Use the Pre Sale function to test each new battery before
customer purchase to confirm it is good and prevent potential
customer service or warranty issues.
1. Tap Pre Sale icon.
Connect the test clamps to the battery and tap Continue.
2.
3. Hold the Diagnostic Device over the battery and tap Cap-
ture Temperature. Once the battery temperature has
been successfully measured, tap Continue.
Enter the battery testing parameters. Tap Continue when
4.
finished.
Battery Post
TOP POST
SIDE POST
DUAL POST
Battery Application
AUTOMOTIVE
MARINE BATTERY
POWERSPORT
GROUP 31
COMMERCIAL 4D/8D
LAWN & GARDEN
Battery Type
FLOODED
AGM
AGM/SPIRAL
GEL
25
