MTS400 Series Generators User Manual
Default Rate: Displays the default clock rate and packet size and then
changes the values. When you select this button, the following Default Clock
dialog box appears.

Figure 9: Default Clock Dialog box

Default Data Rate: Changes the default clock rate when the selected
stream file was downloaded.
Since the default clock rate is calculated based on the PCRs in the
downloaded stream file, the value can be different than the original clock
rate. When the elementary stream rate is fixed (refer to the Fixed ES Rate
description), the instrument refers to the default clock rate. Therefore, if
the default clock rate is different than the original clock rate, you need to
set the value to the appropriate value. If you change the value, the clock
rate value in the Data Rate dialog box is also changed.
Packet Size: Changes the default packet size when the selected stream
file is downloaded. If you change the value, the Packet Size setting in the
Play menu will also change.
Press the OK button to enable all setting changes.
Menus and Controls
177
