- Page 1 Installation Instructions / Warranty Citterio M 34133XX1 Citterio M 34213XX1...
-
Page 2: Technical Information
Axor Citterio M widespread lavatory faucet 34133XX1 Axor Citterio M widespread bidet faucet 34213XX1 34213XX1 Technical Information Recommended water pressure Max. water pressure Recommended hot water temp. Max. hot water temp Hole size in mounting surface valves spout Max. mounting surface depth Flow rate *Please know and follow all applicable local plumbing codes when setting the temperature on the water heater. -
Page 3: Installation
Installation Install the friction washer and fiber washer on the valve. Push the valve up through the hole in the mounting surface. Install the sealing ring, escutcheon, and nut. Rest the valve assembly on the mounting surface (1). Tighten the screws (2). Push the handles into place (3). - Page 4 Check the alignment of the handles. If one is not aligned, pull it off (1), turn it slightly (2), and reinstall it (3). Install the glide ring and the o-ring.
- Page 5 Lubricate spout the o-ring. Push the spout into place. Tighten the spout screw with a 2 mm Allen wrench. Tighten the mounting nut screws. Install the drain pull rod.
- Page 6 Thread the connecting hoses into the spout shank by hand. Connect the hoses to the valves with the compression fittings. Tighten the fittings using two wrenches. Do not allow the hoses to twist. Install the hot and cold supply lines (not included). Install the pop-up drain.
-
Page 7: Install The Pop-Up Drain
Install the pop-up drain Remove the plunger assembly. plunger Unscrew the drain outlet flange from the tee. height adjuster Unscrew the tailpiece from the tee. Wrap the threads with plumbers’ thread tape and replace. Install the white, flexible sealing gasket to the flange flange. - Page 8 Cleaning (34133 only) If the flow of water diminishes over time, unscrew the aerator using the service key. Rinse the aerator with clear water. Reinstall the aerator. Tighten it with the service key.
-
Page 9: Replacement Parts
Replacement Parts 30x1.5 1 aerator 2 handle 3 color-ring set 4 spout 5 nut pull rod 7 cold cartridge 8 hot cartridge fixation set 10 connection hose 11 handle fixing set 12 flange 13 aerator 14 ball joint 15 spout 1 aerator service key 17 compression fittings (pr.) -
Page 10: Limited Lifetime Consumer Warranty
Cleaning Recommendation for Hansgrohe Products Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. - Page 11 (i) for 1 year, with respect to Hansgrohe and Commercial products, and (ii) for 5 years, with respect to AXOR products.
- Page 12 Hansgrohe, Inc. • 140 Bluegrass Lakes Parkway • Alpharetta, GA 30004 Tel. 770-30-880 • Fax 770-30-887 www.hansgrohe-usa.com...
