CHAPTER 1: INTRODUCTION

345 order codes

345 – * *
Interface 345 |
|
E |
User
Interface
L |
a P0 |
Phase Currents
P1 |
P5 |
b
Ground Currents
Power Supply
c
Current Protection
Communications
Case Design
Harsh Environment
a Phase current option “P0” and Ground current option “G0” is only available on the non-drawout version
(Case Design option “N”)
b Ground current options “G0/G1/G5” and “S0/S1/S5” must match the corresponding “P0/P1/P5” Phase currents
The selected phase and ground CTs apply to both windings.
c Current protection option “E” has been discontinued.
NOTE:
NOTE
345 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
The information to specify a 345 relay is provided in the following Order Code figure.
Figure 1-3: Order Codes
* * E * N N * *
| | | |
| | | |
| | | |
| | |
| | |
| | |
G0 | | |
G1 | | |
G5 | | |
S0 | | |
S1 | | |
S5 | | |
L | |
H | |
|
S
|
|
M
|
S N
1 E
2 E
3 E
Features related to each order number are subject to change without notice.
* *
| | | 345 Transformer Protection Relay
| | | English without programmable LEDs
| | |
English with programmable LEDs
| | | 1 A and 5 A configurable phase current inputs
| | | 1 A 3-phase CTs (Winding 1 - 1 A, Winding 2 - 1 A)
| | | 5 A 3-phase CTs (Winding 1 - 5 A, Winding 2 - 5 A)
| | | 1 A and 5 A configurable ground current input
| | | 1 A standard ground CTs (Winding 1 - 1 A, Winding 2 - 1 A)
| | | 5 A standard ground CTs (Winding 1 - 5 A, Winding 2 - 5 A)
| | | 1 A and 5 A configurable sensitive ground current input
| | | 1 A sensitive ground CTs (Winding 1 - 1 A, Winding 2 - 1 A)
| | | 5 A sensitive ground CTs (Winding 1 - 5 A, Winding 2 - 5 A)
| | | 24 to 48 V DC
| | | 110 to 250 V DC/110 to 230 V AC
| | | Standard: 87T, 87T-50, 51P(1), 51N(1), 51G(1), 50P(1), 50G(1),
| | | 50N(1), 49P, 46 (51_2/50_2), 86
| | | Advanced: 87T, 87T-50, 51P(2), 51N(2), 51G(2), 50P(2), 50G(2),
| | | 50N(2), 49P, 46 (51_2/50_2)(2), 86, 50BF(2), 87G/RGF(2)
| | Standard: Front USB, Rear RS485: Modbus RTU, DNP3.0,
| | IEC60870-5-103
| | Standard + Ethernet (Copper & Fiber - MTRJ),
| | Modbus TCP/IP, DNP3.0, IEC 60870-5-104
| | Standard + Ethernet (Copper & Fiber - MTRJ),
| | Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850 GOOSE
| | Standard + Ethernet (Copper & Fiber - MTRJ),
| | Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850
D | Protection Relay with drawout design
N | Protection Relay with non-drawout design
X | Protection Relay (drawout design) with no chassis
N None
H Harsh Environment Conformal Coating
345 ORDER CODES
897800A6.PDF
1–7
