345 ORDER CODES
NOTE:
NOTE
FASTPATH:
Phase Currents
Ground Currents
Communications
Harsh Environment
a Ground current options “G1/G5” must match the corresponding “P1/P5” Phase currents
1–8
Empty chassis
The 345 protection relay chassis used with a drawout relay is available separately, for use
as a partial replacement or in test environments. Many features are supported by the
cards and ports within the chassis, as is reflected in the chassis order code.
The chassis order code and drawout relay order code must match exactly.
A drawout relay cannot be used in a chassis with different order code options.
Figure 1-4: 350 chassis order codes
345 CH – * * * N N
–
P1 |
P5 |
a
G1
G5
S1
S5
Remote Module I/O
The remote RTD Module provides additional protection by monitoring the temperature of
key components in the equipment.
RMIO – * G G
Power Supply L
H
I/O Module 1 G
I/O Module 2
I/O Module 3
I/O Module 4
Accessories
• 18L0-0075 3 Series Depth reducing collar - 1.375"
• 18L0-0076 3 Series Depth reducing collar - 3.00"
• 18L0-0080 3 Series IP20 Kit
• 3S-NDO-STCONKIT 3 Series NDO straight terminal block kit
• 0804-0458 USB A-B configuration cable - 6'
* * *
| | | 1 A 3-phase CTs (Winding 1 - 1 A, Winding 2 - 1 A)
| | | 5 A 3-phase CTs (Winding 1 - 5 A, Winding 2 - 5 A)
| | | 1 A standard ground CTs (Winding 1 - 1 A, Winding 2 - 1 A)
| | | 5 A standard ground CTs (Winding 1 - 5 A, Winding 2 - 5 A)
| | | 1 A sensitive ground CTs (Winding 1 - 1 A, Winding 2 - 1 A)
| | | 5 A sensitive ground CTs (Winding 1 - 5 A, Winding 2 - 5 A)
| Standard: Front USB, Rear RS485: Modbus RTU, DNP3.0,
S N
| IEC60870-5-103
| Standard + Ethernet (Copper & Fiber - MTRJ),
1 E
| Modbus TCP/IP, DNP3.0, IEC 60870-5-104
| Standard + Ethernet (Copper & Fiber - MTRJ),
2 E
| Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850 GOOSE
| Standard + Ethernet (Copper & Fiber - MTRJ),
3 E
| Modbus TCP/IP, DNP3.0, IEC 60870-5-104, IEC 61850
N None
H Harsh Environment Conformal Coating
* *
| | | | 24 - 48 V DC
| | | | 110 - 250 V DC / 110 - 230 V AC
| | | Remote Module I/O (3 - 100 Ohm Platinum RTDs)
G | | Remote Module I/O (3 - 100 Ohm Platinum RTDs)
G | Remote Module I/O (3 - 100 Ohm Platinum RTDs)
X | None
G Remote Module I/O (3 - 100 Ohm Platinum RTDs)
X None
