CHAPTER 6: SETPOINTS
Table 6-1: Transformer types
Transformer Wdg. Connection
Type
2W External 1 WYE (gnd 1/2)
Correction
2 WYE (gnd 2/3) 0°
Y/y180° 1 WYE (gnd 1/2)
2 WYE (gnd 2/3) 180°
lag
Y/d150° 1 WYE (gnd 1/2)
2 DELTA (gnd 2/3)
150° lag
Y/d330° 1 WYE (gnd 1/2)
2 DELTA (gnd 2/3)
330° lag
D/d60° 1 DELTA (gnd 1/2)
2 DELTA (gnd 2/3)
60° lag
345 TRANSFORMER PROTECTION SYSTEM – INSTRUCTION MANUAL
Voltage Phase Transformer
Phasors Shift Type
(Φ )
comp
0° Y/y0°
0°
180° lag Y/d30°
0°
150° lag Y/d210°
0°
330° lag D/d0°
0°
60° lag D/d120°
0°
Wdg. Connection Voltage
Phasors
1 WYE (gnd 1/2)
2 WYE (gnd 2/3) 0°
1 WYE (gnd 1/2)
2 DELTA (gnd 2/3)
30° lag
1 WYE (gnd 1/2)
2 DELTA (gnd 2/3)
210° lag
1 DELTA (gnd 1/2)
2 DELTA (gnd 2/3) 0°
1 DELTA (gnd 1/2)
2 DELTA (gnd 2/3)
120° lag
S2 SYSTEM SETUP
Phase
Shift
(Φ )
comp
0°
0°
30° lag
0°
210° lag
0°
0°
0°
120° lag
0°
6–29
