Summary of Contents for TESTO 175-T1
- Page 1 175 Instruction manual Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 2 Testo AG. We reserve the right to modify the technical data contained in the descriptions, data and graphics in this documentation.
- Page 3 Introduction Dear Customer Thank you for purchasing a Testo product. We hope you will enjoy the benefits of this product for a long time to come and that it will help you with your work. Please take the time to read the instruction manual carefully and make sure you become familiar with how the instrument operates before using it.
- Page 4 7.2 Connecting data logger to PC ........14 7.3 Setting up connection ..........15 7.4 Opening the connection ..........16 7.5 Programming the data logger ........17 7.6 Closing the connection ..........23 8. Reading out data ..........24 9. Changing the battery ........25 10. Error messages..........26 Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 5 C C o o n n t t e e n n t t s s 11.Technical data ..........27 11.1 testo 175-T1 ..............27 11.2 testo 175-T2 ..............28 11.3 testo 175-T3 ..............29 11.4 testo 175-S1, testo 175-S2 ........30 11.5 testo 175-H1 ..............31 11.6 testo 175-H2 ..............32 11.7 Battery life ..............33 12. Accessories / Spare parts........34 Testo-Direct info@Testo-Direct.com...
- Page 6 Force should never be applied! Only for testo 175-T3 The probe sockets in testo 175-T3 are not isolated from one another. Please take note of this when using surface probes with a non-insulate thermocouple. Disposal: Please dispose of spent batteries responsibly.
- Page 7 EN 13486 (recommendation: once a year) is carried out on this instrument. Please contact us for more detailed information. Only for testo 175 - T1 and testo 175 - T2 The following components of the product are designed for continuous contact with...
- Page 8 New programming: Switched on Protocol n n ame testo175-{Type}_{Serial number} * testo 175-T3: T/C -Type “K” programmed testo 175-S1: “0 to 10V” programmed testo 175-S2: “0 to 10V” programmed The data logger with the above factory defaults can be used immediately.
- Page 9 175-S1 testo 175-H1 loggers do not have a display. The following units are shown in the 175 - S S 2 data logger display: testo 175-T1 testo 175-T2 testo 175-T3 testo 175-H2 mV, %, °F, °C and mA. and testo 175-S2...
- Page 10 4 4 . . D D i i s s p p l l a a y y a a n n d d c c o o n n t t r r o o l l e e l l e e m m e e n n t t s s 4.2 L L ED f f unctions The LED functions can be switched on/off via software. testo ComSoft In a a ll m m odes: Alarm led (red LED) The Alarm led flashes three times every 15 seconds if the remaining battery capacity is less than10% (even if Alarm led is deactivated).
-
Page 11: Contents
The readings from Start ( All readings ) or From time mark can be read out on the fast printer or the software. testo 575 testo ComSoft The readings from Start ( All readings ) can be read out on the data collector. -
Page 12: Display
1 Push the data logger into the wall holder. 2 Push the interface onto the wall holder. 3 Secure the unit by connecting the wall holder and the interface using the screw supplied. Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com... - Page 13 ComSoft connections are printed on the housing! testo 175-S1/S2 The testo 175-S1/S2 data logger is designed for use in electric circuits in measurement technology, automatic control, information technology in process, laboratory and technical systems (0 to 20mA current loop; 0-1V, 0-10V voltage sockets).
- Page 14 7.1 I I nstalling s s oftware In order to program your data logger in accordance with your individual needs, you will need a PC on which the testo ComSoft software is installed. You will find instructions on the installation and operation of the software in the instruction manual.
- Page 15 7.3 S S etting u u p t t he c c onnection 1 Start software. testo ComSoft testo C C omsoft 4 4 : 2 Select IStart > New device . - The New device setup wizard opens. testo C C omsoft 3 3 : 2 Select Instrument >...
- Page 16 PC when the connection is opened. Carry out the following to transmit the readings: Click twice on the title of the protocol (See testo ComSoft software instruction manual). Use o o ne c c onnection f f or s s everal d d ata l l oggers You can connect different data loggers once a connection has been set up.
-
Page 17: Programming
Read out any data from the data logger which may exist before programming (See software instruction manual). testo ComSoft Select Start (Comsoft 4) or Instrument (Comsoft 3) > Device control . This function is only activated if the name of the connection is highlighted. - Page 18 You can read information from the protocol currently stored in the data logger in the Protocol window. You can choose to display All values and Since time mark . This window is an information window. Programming is not possible. Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 19 You cannot change the unit in this window, but in the Settings , window. The lower alarm limit for the channels is entered here. The upper alarm limit for the channels is entered here. Name: Enter a name for the channel here. Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 20 Status information on mode and battery capacity are always shown. Enable limit signal output From ComSoft Version 3.4 on, the external alarm signal output testo 581 can be activated if connected to a data logger. Testo-Direct info@Testo-Direct.com 1.888.475.5235 www.
- Page 21 It is only possible to select Date/Time if Date/Time is also selected as Start criterion . If you choose No. of logs an additional field will appear in which the number of measurements required can be entered. Testo-Direct info@Testo-Direct.com 1.888.475.5235 www.
- Page 22 Once the measurement protocol has been opened in the testo software, you can send it by e-mail via testo-Logo > ComSoft Senden (Comsoft 4) or File > Send ... by emai . (Comsoft 3). The entered email address and the log are automatically saved in your e-mail.
- Page 23 7.6 C C losing t t he c c onnection 1 Click on the connection you wish to close with your right mouse button in the Data window. 2 Select Close . - The connection to the data logger is closed. Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 24 ComSoft 3 Professional (0554.0830) like , but with the following additional features: testo ComSoft 4 Basic - Programming and reading out other Testo instruments such , etc. testo 400 testo 650 - Display and printout as number box, histogram, form, analog...
-
Page 25: Changing The Battery
6 Connect the new battery to the data logger`s plug-in connection and place in battery compartment. Only original Testo spare batteries should be used (see 12. A A ccessories/Spare p p arts, P. 34 for Part nos). 7 Remove the jumper from the plug connector. - Page 26 1 1 0 0 . . E E r r r r o o r r m m e e s s s s a a g g e e s s If problems occur which are not described here, please contact Testo or your local distributor. For contact data, see back of this document or web page www.testo.com/service-contact...
- Page 27 Battery l l ife ............Typical: 2½ years* ..(Measuring rate: 15 Min., Operating temperature: -10 to +50°C, ..........Display: On, Status led (green LED): Off) * See Chapter 11.7 B B attery l l ife, P. 33 Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 28 Battery l l ife ............Typical: 2½ years* ..(Measuring rate: 15 min., Operating temperature: -10 to +50°C, ..........Display: On, Status led (green LED): Off) * See Chapter 11.7 B B attery l l ife, P. 33 Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 29 Battery l l ife ............Typical: 2½ years* ..(Measuring rate: 15 Min., Operating temperature: 0 to +50°C, ..........Display: On, Status led (green LED): Off) * See Chapter 11.7 B B attery l l ife, P. 33 Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 30 Battery l l ife ............Typical: 2½ years* ..(Measuring rate: 15 min., Operating temperature: -10 to +50°C, ..........Display: On, Status led (green LED): Off) * See Chapter 11.7 B B attery l l ife, P. 33 Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 31 Battery ..............Lithium (1/2 AA) Battery l l ifetime............Typical: 2½ years* ..(Measuring rate: 15 min., Operating temperature: -10 to +50°C, ..........Display: On, Status led (green LED): Off) * See Chapter 11.7 B B attery l l ife, P. 33 Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 32 Battery l l ife ............Typical: 2½ years* ..(Measuring rate: 15 min., Operating temperature: -10 to +50°C, ..........Display: On, Status led (green LED): Off) * See Chapter 11.7 B B attery l l ife, P. 33 Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
-
Page 33: Battery Life
Saved readings are not lost if the battery is spent or changed. Requirement: The battery is changed by following the directions in the Instruction manual. Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com... - Page 34 (1 channel current/voltage, built-in screwed contact socket, 0563 1759 testo 175-S1 wall holder, calibration protocol) testo 175-S2 (1 channel current/voltage, display, built-in screwed contact socket, 0563 1761 wall holder, calibration protocol testo 580 data collector incl. desk-top holder for testo 175/177 data loggers 0554 1778...
- Page 35 Accurate NTC probes for data loggers testo 175-T2 D D e e s s c c r r i i p p t t i i o o n n I I l l l l u u s s t t r r a a t t i i o o n n M M e e a a s s .
- Page 36 Accurate thermocouple probes for data loggers: testo 175-T3 D D e e s s c c r r i i p p t t i i o o n n I I l l l l u u s s t t r r a a t t i i o o n n M M e e a a s s .
- Page 37 N N o o t t e e s s Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 38 N N o o t t e e s s Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 39 N N o o t t e e s s Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com...
- Page 40 Testo-Direct info@Testo-Direct.com 1.888.475.5235 www. .com 0970 1752 en 06 V04.0-0 en-GB...
