SYL-1512A PID TEMPEARATURE CONTROLLER INSTRUCTION MANUAL
www.auberins.com
·Wiring precautions
-Install an external protection circuit if failure of this instrument could result in damage to your system.
-In order to prevent instrument damage or failure, protect the power line and the input/output lines from
high currents by using fuses with appropriate ratings. A very fast blowing fuse (such as an I
needed when the output device is a solid-state relay (SSR). Please check with your fuse supplier for the
correct fuse for your SSR.
·Power supply
-Supply power of the specified rating.
-Do not turn on the power until all of the wiring is completed.
-Never use this instrument in the presence of inflammable gases or vapor.
-In order to prevent electric shock or burns, never touch the inside of the instrument.
-Do not attempt to modify this instrument.
·Maintenance
-Only authorized service engineers should replace parts.
-In order to use this instrument continuously and safely, conduct periodic maintenance. Some parts used
in this instrument have a limited service life and may deteriorate over time.
Caution
·Only clean the instrument when power is off.
·Please use a soft cloth or tissue to clean up stains on the display.
·Never use sharp & hard objects such as screwdrivers or ball pens to touch the buttons on the panel.
=============================================================
1. Features
◆ Compact size, 1/32 DIN that is only 24 x 48 x 75 mm (1x2 x3")
◆ Supports 10 different types of commonly used temperature sensors, including Pt100 and Cu50 RTDs，
T、R、J、B、S、K、E、and WRe3-WRe25 thermocouples.
◆ The PID control output can be configured by user for either relay contact or SSR.
◆ The relay contact output can also be configured as the alarm output, or on/off control
◆ Auto-tune function can automatically find the best PID parameters.
◆ Temperature can be displayed in Fahrenheit and Celsius.
◆ Can be used with either DC or AC power source.
2. Specification
◆ Power supply：85～260VAC or 85～360VDC
◆ Power consumption：<2W
◆ Sampling rate：4 sample/sec
◆ Accuracy：0.2% full scale
Version 2.2, July. 2007
Auber Instruments, 730 Culworth, Alpharetta, GA 30022
e-mail: info@auberins.com Tel: 770-569-8420
WARNING
Figure 1
1
2
