Ruckus Wireless ZoneFlex 7321-U Quick Setup Manual

ZoneFlex 7321-U 802.11n
Multimedia Wi-Fi Access Point

Quick Setup Guide

CAUTION!
THE MINIMUM SOFTWARE REVISION FOR
7321-U APs IS ZONEFLEX (ZF) 9.6 OR LATER.
DO NOT CONNECT ANY 7321-U AP TO A RUCKUS
WIRELESS CONTROLLER WITH ZF 9.5 OR EARLIER.
This Quick Setup Guide provides step-by-step instructions
on how to set up your Ruckus Wireless ZoneFlex 7321-U
Access Point (AP). After completing the steps described in
this Guide, you will be able to place the AP at your site and
provide wireless network access to users.
Copyright © 2013 Ruckus Wireless, Inc.
Published November 2013, Part Number 800-70590-001 Rev A
T G O L
HIS UIDE IN THER ANGUAGES
请从以下网站获得该指南的简体中文版
https://support.ruckuswireless.com .
Vous trouverez la version française de ce guide à l'adresse
https://support.ruckuswireless.com
suivante
こ の ガ イ ド の日本語版は
https://support.ruckuswireless.com
で ご 覧 く だ さ い。
이 가이드의 한국어 버전은 웹 사이트
) 에서 확인하시기 바랍니
https://support.ruckuswireless.com
(
다 .
Veja a versão em português (Brasil) deste guia em
https://support.ruckuswireless.com.
Puede ver la versión en español (América Latina) de esta guía en
https://support.ruckuswireless.com
B Y B
EFORE OU EGIN
Before deploying your Ruckus Wireless device, please check
the Ruckus Wireless Web site for the latest software and
release documentation.
• Release Notes and User Guides are available at
http://support.ruckuswireless.com/documents.
• Software Upgrades are available at
http://support.ruckuswireless.com/software.
• Open Source information is available at
http://support.ruckuswireless.com/open_source.
• Software License and Limited Warranty available at
http://support.ruckuswireless.com/warranty.
P C
ACKAGE ONTENTS
• One ZoneFlex 7321-U Access Point
• Two sets 1" 8AWG panhead sheet metal screws and wall
anchors
• One 5mm M2.5 Torx security screw
• Declaration of conformity
• Service level agreement/limited warranty statement
• Regulatory flyer
• This Quick Setup Guide
S 1: C
TEP
Complete the following:
• Collecting Required Equipment
• Connecting the Computer to your AP
.
• Preparing Your Computer for AP Setup
• Logging Into the AP
• Customizing the Wireless Settings
• Placing the AP in Your Site
• Provisioning the USB Backhaul Device
• Verifying the Installation
Collecting Required Equipment
• A computer running Windows 7 (procedures for other
OS's are similar).
• One Cat 5e Ethernet cable.
• An AC power adapter (sold separately)
--or--
an 802.3af or 802.3at -compliant Power over Ethernet
(PoE) switch or PoE injector.
Note! If the AP is deployed with a ZoneDirector via a local
network, follow the ZoneDirector Quick Setup Guide, and
connect the AP to your local network.
• OPTIONAL: If you are deploying the AP with a USB
backhaul device, then you need a Provisioning
ZoneDirector on a local LAN that is loaded with the
supported driver for the USB backhaul device. Refer to
the ZoneDirector User Guide for USB backhaul device
driver download instructions. Refer to
USB Backhaul Device
option.
Connecting the Computer to your AP
1 After removing your Ruckus Wireless AP from its
package, place it next to your computer.
2 Using an Ethernet cable, connect your computer's
network port to the 10/100/1000 port on the AP.
3 Using the AC adapter (sold separately), connect the AP
to a convenient (and protected) power source.
Alternatively, connect the 10/100/1000 port to a PoE
injector or PoE switch for both power and network con-
nectivity.
AP
ONFIGURING THE
Provisioning the
for more information on this
Page 1 of 4
