Technical Specifications; Optional Accessories And Spare Parts - Ferrofish Verto 32 Owner's Manual

06. Technical specifications

DANTE I/O
ADAT I/O
(Only Verto 32 & 64)
MIDI I/O
MADI I/O
(Verto MX only)
Wordclock
Fuse
Power consumption
Temperature range
Humidity
Dimensions
Weight

07. Optional accessories and spare parts

The following accessories and spare parts are available for the Verto series:
Description
19" Rack mountain kit, metal
(for mounting 1 x Verto in a 19" rack-space)
Multi-range Power Supply 12V (EU)
ADAT Cable Locking Plate
MADI Singlemode Module
MADI SC / LC Adapter
The accessories and the spare parts can be purchased
from the dealer or the distributor as well as at www.ferrofish.de.
∙ 2x Ethernet (PRI/SEC) sockets, 1GBit
∙ 64x64 channel Brooklyn II board built-in
∙ 4x ADAT Input + 4x ADAT Output, optical TOSLINK (Verto 32)
∙ 32x32 channels at 48kHz, 16x16 channels at 96kHz
∙ 8x ADAT Input + 8x ADAT Output, optical TOSLINK (Verto 64)
∙ 64x64 channels at 48kHz 32x32 channels at 96kHz
∙ MIDI Standard 1.0 / 1996
∙ 2x DIN female 5pin In/Out for embedding / de-embedding
MIDI-over-MADI messages
∙ AES 10, 2x optical LC port, 2x coaxial BNC port
∙ 64x64 channels at 48kHz, 32x32 channels at 96kHz, 16x16
channels at 192kHz
∙ 2x BNC In/Out, 75 Ohm termination set to on by default.
Can be changed from software via DANTE.
∙ Polyfuse internal, self-resetting
∙ 14.4VA (1.2A at 12V)
∙ +5°C to +45°C
∙ <75%, non-condensing
∙ 22 x 9 x 4,5 mm (without rack ears)
∙ 0,9 kg
Item code For VERTO Series
7008 32, 64 and MX
7023 32, 64 and MX
7027 32 and 64
7020 MX
7026 MX
9
