Summary of Contents for Cytech KP04
- Page 1 KP04 LCD Keypad Installation Manual...
-
Page 3: Table Of Contents
KP04 LCD Keypad Installation Manual Introduction.................1 Upgrading from KP01 and KP02..........1 Specifications................2 System Requirements..............2 Contents ..................2 Set-Up...................2 Connections................2 Cables..................3 Jumper Settings.................3 Keypad ID Switch..............3 LED Indicators................3 Installation ...................4 Vocabulary Programming............5 Tabs...................6 Event Log Sentences..............6 Miscellaneous Sentences ............7 Special Words ................8 Settings..................8... -
Page 5: Introduction
KP02. A feature of the KP04 is its real time display of active zones and alarms. Hence a trouble alarm like “Phone Trouble” will be displayed on the LCD. -
Page 6: Specifications
For Comfort I, firmware should be Outside (PRO) or Action (ULTRA) 4.226 or above. The firmware can be upgraded by purchasing the IC01-OUT or IC01-ACT and replacing the U1 IC on Comfort. The KP04 cannot be used with Comfort ENTRY. All Comfort II firmware versions are compatible with... -
Page 7: Cables
• Switch” settings). Keypad ID Switch Comfort is able to support up to 8 keypads (KP01/KP02/KP03/KP04) in any combination. SW1 is a set of 4 headers which is used to determine the ID, in accordance to the table below: Table 1: ID Settings... -
Page 8: Installation
Open the Keypad housing by unscrewing the screw at the base. Mount the back housing on the wall using the screws supplied. The KP04 can replace the KP01 or KP02 with little difficulty as the position and size of the mounting holes are identical to that of the older products. -
Page 9: Vocabulary Programming
KP04. The KP04 currently supports English and European language text (A-Z, a-z and 0-9). The LCDKP Language Customisation Software is used to customise the words in the KP04. This program can be downloaded from http://www.cytech.biz/software.html. The above screen should be seen when running the installation for the LCDKP Language Customisation Software. -
Page 10: Tabs
KP04 LCD Keypad Installation Manual Upon running the LCDKP Language Customisation Software, a set of default system files are loaded under a certain template, which can be seen on the top right hand corner of the screen. The system files loaded can be seen under ‘Edit... -
Page 11: Miscellaneous Sentences
KP04 LCD Keypad Installation Manual Miscellaneous Sentences The above screen is displayed when the Miscellaneous Sentence tab is displayed. Here, unlike the Event Log Sentences tab, the fields can be edited without the restriction of a fixed list. However, the LCD Keypad only... -
Page 12: Special Words
KP04 LCD Keypad Installation Manual Special Words This screen allows the modification of certain special words, such as the month name. This is, however, similar to the Event Log Sentences, which limits the choice of words to that of a fixed wordlist. -
Page 13: Menu Bar
Transfer This menu allows the downloading of the program to the LCD Keypad. Description Download Downloads the current configuration to the KP04. Help This menu provides on-site assistance to installers. Description Contents Displays the contents in the help file. -
Page 14: Toolbar
KP04 LCD Keypad Installation Manual Toolbar The toolbar serves to provide shortcut keys, which consists of the more commonly used functions. Description Opens a new template file. Open Opens an existing file. Save Saves the current configuration. Download Downloads the current configuration. - Page 15 KP04 LCD Keypad Installation Manual Instead of changing the default template, the system files may be changed for the change in a new vocabulary. This is useful in cases where the default template of choice is still maintained. For such cases, click on “Edit” followed by “Options”...
-
Page 16: Downloading
KP04 LCD Keypad Installation Manual Downloading Ensure that the UCM (Version 5.72 and above) is connected to both the PC (via RS232) as well as to the Comfort system (via 12V/COM/KA/KB) and SW8-E is shorted. Click on “Download”. This should bring up the download screen as... -
Page 17: Comfort Ii Downloading
Following that, download the configuration into the keypads using the LCD Keypad Language Customisation Software If the version shown is 1.03 or later, connect up the KP04 to Comfort as per normal. Should there be a mismatch between the versions of the language displayed and the vocabulary onboard Comfort, the KP04 will display “Wrong Text. -
Page 18: Version History
KP04 LCD Keypad Installation Manual KP04 Firmware History KP04 1.03 (October 2005) Comfort II vocabulary supported. Comfort II downloading function (*1) supported. KP04 1.01 (April 2005) Initial Release Document Revision History Rev 1.05 • 30 June 2006 Updated... - Page 19 KP04 LCD Keypad Installation Manual...
- Page 20 KP04 LCD Keypad Installation Manual Document Title: KP04 LCD Keypad Installation Manual Document Revision 1.0.5 UCM Firmware: 5.72 and above (for downloading) Date Last Modified: 8 March 2006 Comfort Version: Outside or Action 4.226 and above Comfigurator: 1.6.0 and above...
