Web Interface
3.6.3

BACnet

If the WiNG-MGR will communicate via the BACnet, configure the necessary options here.
Figure 3.21
Option
Pics
Packet Log
Device ID
Device Name
Description
Location
UDP Port
BACnet/IP Read
Multiple
Register as Foreign
Device at IPv4
Table 3.12
48
BACnet Configuration
Description
Click this link to view the Bacnet identifiers and objects supported by
the WiNG-MGR.
Click this link to view the Bacnet packet log.
To enable BACnet, assign a unique number between 1 and 4194302
to identify this BACnet device on the network.
If you enter a 0 in this field BACnet will be disabled.
Default: 0 (Disabled)
Assign a name - up to 38 characters - to the unit for BACnet
discovery and integration.
Add any additional details about the device, up to 38 characters.
Designate the physical location of the unit.
Enter a 0 to specify port 47808 (0xBAC0) as the UDP port. If another
port is specified by your application, enter that value here.
Default: 0 (47808)
Use the toggle switch to enable or disable this option.
Default: Enabled
IP address of the master device with which you're trying to
communicate. Requires a BBMD for foreign device discovery.
BACnet Configuration Options
