- Page 2 SC30 powered through NN3D (6 meter antenna cable) 18 Pin pigtail cable No Terminator resistor in NMEA2000 Micro supplied for use with 6 meter cable Double-ended cable Data 2 and 3 Male – Female 000-164-608 1 meter = 000-167-962 2 meter = 000-167-963...
- Page 3 SC30 powered through NN3D (15 or 30 meter antenna cable) NMEA2000 SC30 Backbone cable 15 meter = 000-166-891 This is to supply 30 meter = 000-166-892 NMEA2000 Micro (Terminator resistor included voltage for the Double-ended cable NMEA2000 Bus. in both of these cable lengths) Male –...
- Page 4 SC30 connection to DRS Dome and NavNet 3D (6 meter cable) Use the included 3 hole gasket for this installation application. Inside DRS2D and DRS4D NMEA2000 Micro drop cable 6 meter 000-166-887 (supplied) No Terminator resistor in 6 meter cable...
- Page 5 SC30 connection to DRS Dome and NavNet 3D (15 or 30 meter antenna cable) Use the included 3 hole gasket for this installation application. Inside DRS2D and DRS4D NMEA2000 SC30 Backbone cable 15 meter = 000-166-891 30 meter = 000-166-892...
- Page 6 SC30 connection to DRS Gearbox and NN3D (6 meter cable) Use the included 3 hole gasket for this installation application. Inside DRS Gearbox NMEA2000 Micro drop cable 6 meter 000-166-887 (supplied) No Terminator resistor in 6 meter cable Attach crimp-lug to shield...
- Page 7 SC30 connection to DRS Gearbox and NN3D (15 or 30 meter antenna cable) Use the included 3 hole gasket for this Inside DRS Gearbox installation application. NMEA2000 SC30 Backbone cable 15 meter = 000-166-891 30 meter = 000-166-892 (One terminator resistor is...
- Page 8 SC30 to FI5002 with FI505 instrument with NN3D (6 meter antenna cable) No Terminator resistor in 6 meter NMEA2000 Micro Drop cable cable NMEA2000 Micro drop Connect to any of the 6 6 meter cable 6 meter drop connection ports...
- Page 9 SC30 to FI5002 with FI505 instrument with NN3D (15 or 30 meter antenna cable) NMEA2000 Micro Drop cable NMEA2000 SC30 Backbone 6 meter cable 000-166-945 15 meter = 000-166-891 Connect to any of the 6 30 meter = 000-166-892 drop connection ports (One terminator resistor is inside the FI-5002.
