Page 1: Installation Guide
Beale Street Audio IC6-B, IC6-MB, IC6-BB, IC8-B, IC8-MB, IC8-BB, ICA6-B, ICA6-MB, ICA6-BB, IC6DVC-B, BS650 In Ceiling Speakers ICS6-MB, ICS8MB In Ceiling Subwoofers Installation Guide... - Page 2 Introduction Congratulations and thank you for purchasing Beale Street Audio In Ceiling speakers and subwoofers with Sonic Vortex®. Our patented Sonic Vortex Technology is based on Ported Transmission Line design and incorporates a compact, integrated enclosure. Most In Ceiling speakers do not utilize a back box, even fewer have an enclosure, and only a Sonic Vortex speaker has an Integrated Transmission Line Ported Enclosure.
-
Page 3: Speaker Placement
Speaker Placement When installing in ceiling speakers or subs, (or in ceiling anything for that matter) it is always a good idea to find out what is in the ceiling before cutting holes. Be aware of the location of plumbing, electrical and structural elements that may affect speaker placement. -
Page 4: Installation
400’ (122m) 14AWG NEW CONSTRUCTION Beale Street Audio speaker installation can be simplified by using a Beale Street Audio new construction EZBracket®, (sold separately; visit www.getbeale.com for additional information). This is installed prior to drywall installation and allows for precise speaker placement and simplifies the final installation of the speaker. - Page 5 Installation • Once you have determined your locations, use a pencil to mark the hole to cut out for the speaker using the supplied template. Don’t forget to allow for the size of the speaker bezel if you are installing the speaker near a sidewall or other item that could become an obstacle.
- Page 6 Installation 16AWG (min) 16AWG (min) Stranded Speaker Wire Stranded Speaker Wire + to + + to + - to - - to - L+ R- R+ Amplifier Speaker Terminal • With the ‘dogs’ flush to the side of the speaker, insert the speaker into the ceiling and tighten each of the four screws for the speakers’...
-
Page 7: Troubleshooting
TROUBLESHOOTING Beale Street Audio speakers are designed to function trouble-free. Most problems that occur are due to simple issues. If you have trouble, please check the list of simple fixes below. -
Page 8: Specifications
Specifications 6.5” IN CEILING 8” IN CEILING IC6-B 6.5” In Ceiling 2 Way IC8-B 8” In Ceiling 2 Way • Woofer: 6.5” Poly • Woofer: 8” Poly • 1” Silk Dome Tweeter • 1” Silk Dome Tweeter • Butyl Rubber Surround •... - Page 9 Specifications 6.5” ANGLED IN CEILING 6.5” DUAL VOICE COIL ICA6-B 6.5” Angled In Ceiling 2 Way IC6DVC-B 6.5” In Ceiling Dual Voice Coil • Woofer: 6.5” Poly • Woofer: 6.5” Poly • 1” Silk Dome Tweeter • 1” Silk Dome Tweeter •...
- Page 10 Specifications 6.5” IN CEILING SUBWOOFER ICS6-MB 6.5” In Ceiling Subwoofer • Woofer: 6.5” Kevlar • Butyl Rubber Surround • Sonic Vortex® Ported Transmission Line • Magnetic Bezelless Grille; White - Paintable • Impedance: 4Ω • Installed Frequency Response: 38 Hz - 300 Hz •...
-
Page 11: Limited Lifetime Warranty
Limited Lifetime Warranty For Beale Street Audio Branded In-Wall and In-Ceiling Speakers and Subwoofers Purchased after May 1, 2017 Limited Warranty Vanco warrants to you, the original consumer purchaser of speakers, that under proper use and conditions, and subject to the other conditions provided below, your speakers will be free from defective materials and workmanship for the life of the speakers. - Page 12 The Vanco logo, Sonic Vortex logo, and Beale Street Audio Inc. logo are registered trademarks of Vanco International, LLC. Vanco, Sonic Vortex, Beale Street Audio, Get Reale. Get Beale., the Vortex logo, and the Beale Street Audio logo are trademarks of Vanco International, LLC.
