Summary of Contents for Toa TZ-206B AS
- Page 5 5. NOTES ON OUTDOOR INSTALLATION (TZ-206BWP AS, TZ-206WWP AS, TZ-406BWP AS, TZ-406WWP AS, TZ-606BWP AS, TZ-606WWP AS Only) Be sure to mount speaker in a vertical (portrait-style) orientation. Adjust the speaker’s tilt angle within the shaded range shown below: [Wall: Vertical 0 to 15 downward (TZ-206, TZ-406 series), 0 to 30 downward (TZ-606 series)] Note: Mount the speaker so that its rear mounted terminal cover is positioned on the lower side.
-
Page 6: Installation
6. INSTALLATION 6.1. Use the Supplied Bracket The speaker is equipped with mounting brackets as shown below. Use these brackets properly depending on the installation location and intended application. Bracket for TZ-206 and TZ-406 Series model [Speaker bracket] [Joint bracket] [Wall bracket] 30°... - Page 7 6.3. Mounting of Bracket to Speaker Adjusting horizontal and vertical angles Mounting of bracket to speaker is illustrated in the pictures below. Screws to mount the bracket to the speaker are provided as accessories when you purchase the speaker unit. * Horizontal max 60°,Vertical: max.
- Page 8 Ensure both sides are attached securely after mounting [Mounting the speaker close to wall surface] (TZ-206B AS, TZ-206W AS, TZ-406B AS, TZ-406W AS, TZ-606B AS, TZ-606W AS only) Use the joint bracket and speaker bracket. Mount joint bracket onto the wall. After mounting joint bracket, follow steps 3 ~ 6 above.
