Promax DT-511 Quick Configuration Manual

Promax DT-511 Quick Configuration Manual

Hdmi to dvb-t modulator
Hide thumbs

Advertisement

Quick Links

Download this manual
DT-511
HDMI TO DVB-T MODULATOR
QUICK CONFIGURATION GUIDE
- 0 DG0104 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the DT-511 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Promax DT-511

Summary of Contents for Promax DT-511

  • Page 1 DT-511 HDMI TO DVB-T MODULATOR QUICK CONFIGURATION GUIDE - 0 DG0104 -...

  • Page 2: Quick Configuration Guide

    DT-511 1 INTRODUCTION 1.1 Description PROMAX DT-511 module is an affordable H.264/AVC DVB Encoder. It includes HDMI and TS-ASI inputs and offers TSoIP and DVB-T outputs. Because of its excellent enconding performance, bandwidth efficiency and moderate price it is an ideal solution to add High Definition to your programme roaster.
  • Page 3 DT-511 QUICK CONFIGURATION GUIDE SPECIFICATIONS VIDEO Encoder H.264/AVC High Profile Level 4.0 (HD). Input HDMI + backup. Resolution 1920 x 1080_60i, 1920 x 1080_50i, 1280 x 720_60p, 1280 x 720_50p. AUDIO Encoder MPEG-1 Layer II. Input HDMI + backup. Sample rate 48 kHz.
  • Page 4 DT-511 QUICK CONFIGURATION GUIDE Mechanical features Dimensions W. 100 x H. 262 x D. 230 mm. Weight 800 g. Mounting Using DT-900 rack/wall mounting frame. Included accessories 1 x 0 MI1962 Instruction Manual. 1 x 0 DG0104 Quick configuration guide.

  • Page 5: Safety Rules

    DT-511 QUICK CONFIGURATION GUIDE 2 SAFETY RULES General ∗ The safety could not be assured if the instructions for use are not closely followed. ∗ Use only with other DT series modules and for power supply and Control those indicated at the Specifications.
  • Page 6 DT-511 QUICK CONFIGURATION GUIDE Maintenance 2.2.1 Cleaning Recommendations CAUTION To clean the cover, take care the instrument is disconnected. CAUTION Do not use scented hydrocarbons or chlorized solvents. Such products may attack the plastics used in the construction of the cover.
  • Page 7 DT-511 QUICK CONFIGURATION GUIDE 3 DT-511 CONFIGURATION The DT-511 module is controlled and configured by means of a computer directly connected to the NMS web port or through an Ethernet network. Login The default IP of this device is 192.168.29.5.
  • Page 8 DT-511 QUICK CONFIGURATION GUIDE Figure 2.- Operation When we confirm the login, it displays the screen (figure 3). Figure 3.- 12/2012 Page 7...
  • Page 9 DT-511 QUICK CONFIGURATION GUIDE User can click any item here to enter the corresponding interface to check information or set the parameters. Device standard and name. It automatically identifies and displays the signal source interface and real-time encoding bit rate of corresponding input channel.
  • Page 10 DT-511 QUICK CONFIGURATION GUIDE Encoding Status Green light indicate it works normally, which otherwise turn to red. Help For user to turn to refer detailed explanation of terms on this interface. Default Click this button to apply the default setting of Input 1 Apply Click this button to apply the modified parameters.
  • Page 11 DT-511 QUICK CONFIGURATION GUIDE Multiplex Selecting this item to allow user select programs as required to output. Refresh Input Click on “Refresh Input” to refresh the input program list. Refresh Output Click on “Refresh Output” to refresh the output program list.
  • Page 12 DT-511 QUICK CONFIGURATION GUIDE When user clicks on “Add” from this page, it will display the screen (figure 7). Here user has to add Service ID for the programs. Figure 7.- Here by clicking on “Add”, users can set the program LCN in its respective field.
  • Page 13 DT-511 QUICK CONFIGURATION GUIDE IP Output When user clicks on “IP Output” from the menu, it will display the screen (figure 9). Here user can set the multicast IP Output address for the device if we need. After setting the parameter we need to click on “Apply”...
  • Page 14 DT-511 QUICK CONFIGURATION GUIDE Transmission Mode 2K, 8K optional. Guard Interval/Code Rate/RF Frequency/RF Out level The default configuration is as shown on figure 10. After setting all the parameters, user needs to click on “Apply” to save the Modulator parameters.
  • Page 15 DT-511 QUICK CONFIGURATION GUIDE Figure 11.- Restart the Device When user clicks on “Reboot” from the menu, the screen will display as figure 12. Here when user clicks on “Reboot” box, it will restart the device automatically. Figure 12.- Page 14...
  • Page 16 DT-511 QUICK CONFIGURATION GUIDE Update the Device When user clicks on “Firmware” from the menu it will display the screen as figure 13. Here user can update the device by using the update file. Click on “Select file” to find the path of the device update file for this device then click on “Update”...
  • Page 17 DT-511 QUICK CONFIGURATION GUIDE Change Password When user clicks on “Password”, it will display the password screen (figure 15). Here user can change the Username and Password for login to the device. User needs to put old Username and Password then to put new Username and Password.
  • Page 18 DT-511 QUICK CONFIGURATION GUIDE Figure 16.- Browse Button. 12/2012 Page 17...
