American Standard 4TWA3036B3000A Service Facts

Service Facts
Split System
Cooling
4TWA3036B3000A, 4TWA3042B3000A,
4TWA3048B3000B, 4TWA3060B3000A
IMPORTANT — This document contains a wiring diagram, a parts list, and service information. This is customer property and
is to remain with this unit. Please return to service information pack upon completion of work.
WARNING:
PRODUCT SPECIFICATIONS
4TWA3036B3000A
OUTDOOR UNIT 12
208/230/3/60
POWER CONNS. — V/PH/HZ 3
MIN. BRCH. CIR. AMPACITY
BR CIR PROT RTG – MAX. (AMPS)
COMPRESSOR
NO. USED - NO. SPEEDS
208/230/3/60
VOLTS/PH/HZ
R.L. AMPS 7 - L.R. AMPS
FACTORY INSTALLED
START COMPONENTS 8
INSUL/SOUND BLANKET
COMPRESSOR HEAT
PROPELLER
OUTDOOR FAN
DIA. (IN.) - NO. USED
DIRECT - 1
TYPE DRIVE - NO. SPEEDS
CFM @ 0.0 IN. W.G. 4
NO. MOTORS - HP
MOTOR SPEED R.P.M.
200/230/1/60
VOLTS/PH/HZ
F.L. AMPS
SPINE FIN™
OUTDOOR COIL — TYPE
ROWS - F.P.I.
FACE AREA (SQ. FT.)
TUBE SIZE (IN.)
REFRIGERANT
7 LBS., 14 OZ.
LBS — R-410A (O.D. UNIT) 5
FACTORY SUPPLIED
LINE SIZE - IN. O.D. GAS 6
LINE SIZE - IN. O.D. LIQ. 6
CHARGING SPECIFICATION
SUBCOOLING
H X W X D
DIMENSIONS
38.4 x 35.1 x 38.7
CRATED (IN.)
WEIGHT
SHIPPING (LBS.)
NET (LBS.)
!
THIS INFORMATION IS INTENDED
POSSESSING ADEQUATE BACKGROUNDS
MECHANICAL EXPERIENCE. ANY ATTEMPT TO REPAIR A CENTRAL AIR
CONDITIONING PRODUCT MAY RESULT IN PERSONAL INJURY AND
OR PROPERTY DAMAGE. THE MANUFACTURER OR SELLER CANNOT
BE RESPONSIBLE FOR THE INTERPRETATION OF THIS INFORMATION,
NOR CAN IT ASSUME ANY LIABILITY IN CONNECTION WITH ITS USE.
NOTICE: The manufacturer has a policy of continuous product and product data improvement
and it reserves the right to change design and specifications without notice.
© 2016 Trane
HAZARDOUS VOLTAGE - DISCONNECT POWER and DISCHARGE
4TWA3042B3000A 4TWA3048B3000B
208/230/3/60
14 18
20 30
SCROLL SCROLL
1 - 1 1 - 1
208/230/3/60
10.4 - 73 13.6 - 83
NO NO
NO NO
YES YES
PROPELLER
27.6 - 1 27.6 - 1
DIRECT - 1
4385 4395
1 - 1/5 1 - 1/5
850 850
200/230/1/60
.93 .93
SPINE FIN™
1 - 24 1 - 24
21.99 21.99
3/8 3/8
7 LBS., 7 OZ.
YES YES
3/4 3/4
3/8 3/8
10°F 8°F
H X W X D
38.4 x 35.1 x 38.7 46.4 x 35.1 x 38.7
228 248
197 214
WARNING
FOR USE BY
OF ELECTRICAL
UNIT CONTAINS R-410A
REFRIGERANT!
R-410A OPERATING PRESSURE EXCEEDS THE
LIMIT OF R-22. PROPER SERVICE EQUIPMENT IS
REQUIRED. FAILURE TO USE PROPER SERVICE
CAPACITORS BEFORE SERVICING
4TWA3060B3000A
208/230/3/60 208/230/3/60
18 20
30 35
SCROLL SCROLL
1 - 1 1 - 1
208/230/3/60 208/230/3/60
13.7 - 83 15.6 - 110
NO NO
NO NO
YES YES
PROPELLER PROPELLER
27.6 - 1 27.6 - 1
DIRECT - 1 DIRECT - 1
4400 4760
1 - 1/6 1 - 1/5
835 850
200/230/1/60 200/230/1/60
1.30 .93
SPINE FIN™ SPINE FIN™
1 - 24 1 - 24
27.86 27.86
3/8 3/8
8 LBS., 10 OZ. 8 LBS., 14 OZ.
YES YES
7/8 7/8
3/8 3/8
10°F 8°F
H X W X D H X W X D
46.4 x 35.1 x 38.7
279 280
243 244
INDIVIDUALS RECONNECT ALL GROUNDING DEVICES.
AND ALL PARTS OF THIS PRODUCT CAPABLE OF CONDUCTING
ELECTRICAL CURRENT ARE GROUNDED. IF GROUNDING
WIRES, SCREWS, STRAPS, CLIPS, NUTS OR WASHERS USED
TO COMPLETE A PATH TO GROUND ARE REMOVED FOR
SERVICE, THEY MUST BE RETURNED TO THEIR ORIGINAL
POSITION AND PROPERLY FASTENED.
4TWA3B-SF3-3F-EN
!
CAUTION
SERVICE
USE ONLY R-410A REFRIGERANT AND
APPROVED POE COMPRESSOR OIL.
TUBING INFORMATION
REFRIGERANT TO ADD AT SPECIFIED
LINE TYPE
ADDITIONAL LENGTH
Suction Liquid 20 ft 30 ft
3/4" 3/8" 3 oz 9 oz
7/8" 3/8" 3 oz 9 oz
1 Certified in accordance with the Air-Source Unitary Air-conditioner
Equipment certification program, which is based on AHRI standard
210/240.
2 Rated in accordance with AHRI standard 270.
3 Calculated in accordance with Natl. Elec. Codes. Use only HACR circuit
breakers or fuses.
4 Standard Air — Dry Coil — Outdoor
5 This value approximate. For more precise value see unit nameplate.
6 Max. linear length 60 ft.; Max. lift - Suction 60 ft.; Max lift - Liquid 60 ft.
For greater length consult refrigerant piping software Pub. No. 32-3312-
0* (* denotes latest revision).
7 This value shown for compressor RLA on the unit nameplate and on this
specification sheet is used to compute minimum branch circuit ampacity
and max. fuse size. The value shown is the branch circuit selection cur-
rent.
8 No means no start components. Yes means quick start kit components.
PTC means positive temperature coefficient starter.
CAUTION
!
HOT SURFACE!
DO NOT TOUCH TOP OF
CAUTION
!
CONTAINS REFRIGERANT!
SYSTEM CONTAINS OIL AND REFRIGERANT
UNDER
HIGH PRESSURE. RECOVER REFRIGERANT TO
RELIEVE PRESSURE BEFORE OPENING SYSTEM.
CAUTION
!
40 ft 50 ft 60 ft
15 oz 21 oz 27 oz
16 oz 22 oz 28 oz
02/17
