Installer's Guide
Split System Heat Pump
3–Phase, 230V
3–Phase, 460V
2 2 3 3 0 0 V V M M O O D D E E L L S S
4A6C4036A3000A
4A6C4042A3000A
4A6C4048A3000A
4A6C4060A3000A
4 4 6 6 0 0 V V M M O O D D E E L L S S
4A6C4036A4000A
4A6C4042A4000A
4A6C4048A4000A
4A6C4060A4000A
N N o o t t e e : : "Graphics in this document are for representation
only. Actual model may differ in appearance. "
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and
air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered
equipment by an unqualified person could result in death or serious injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the equipment.
11-BC41D1-1A-EN
November 2016
Advertisement
Table of Contents
Related Manuals for American Standard 4A6C4036A3000A
Summary of Contents for American Standard 4A6C4036A3000A
- Page 1 Split System Heat Pump 3–Phase, 230V 3–Phase, 460V 2 2 3 3 0 0 V V M M O O D D E E L L S S 4A6C4036A3000A 4A6C4042A3000A 4A6C4048A3000A 4A6C4060A3000A 4 4 6 6 0 0 V V M M O O D D E E L L S S...
- Page 2 SAFETY SECTION I I m m p p o o r r t t a a n n t t — This document contains a wiring diagram C C A A U U T T I I O O N N and service information.
-
Page 3: Table Of Contents
Table of Contents Unit Location Considerations ....4 Electrical — Low Voltage ....14 . -
Page 4: Unit Location Considerations
Unit Location Considerations Table 1. Unit Dimensions and Weight H x D x W (in) Weight * (lb) Models 4A6C4036A3 29 x 34 x 37 4A6C4042A3 29 x 34 x 37 4A6C4048A3 33 x 34 x 37 4A6C4060A3 45 x 34 x 37 4A6C4036A4 29 x 34 x 37 4A6C4042A4... -
Page 5: Coastal Considerations
Table 2. Suggested Locations for Best Reliability • Ensure the top discharge area is unrestricted for at least 5 feet above the unit. • Provide at least 3 feet clearance in front of the control box (access panels) and any other side requiring service. •... -
Page 6: Unit Preparation
Unit Preparation 1. Check for damage and report promptly to the carrier any damage found to the unit. 1. To remove the unit from the pallet, remove tabs by cutting with a sharp tool. Setting Up the Unit Table 4. Pad Installation When installing the unit on a support pad, such as a concrete slab, consider the following: •... -
Page 7: Refrigerant Line Considerations
U U n n i i t t P P r r e e p p a a r r a a t t i i o o n n Refrigerant Line Considerations Table 5. Refrigerant Line and Service Valve Connection Sizes Line Sizes Service Valve Connection Sizes Vapor Line... - Page 8 U U n n i i t t P P r r e e p p a a r r a a t t i i o o n n Table 8. Refrigerant Line Insulation Important: The Vapor Line must always be insulated. DO NOT allow the Liquid Line and Vapor Line to come in direct (metal to metal) contact.
- Page 9 U U n n i i t t P P r r e e p p a a r r a a t t i i o o n n Table 11. Isolation From Joist/Rafter Secure Vapor Line from joists using isolators every 8 ft. Secure Liquid Line directly to insulated Vapor Line using tape, wire, or other appropriate method every 8 ft.
-
Page 10: Refrigerant Line Brazing
Refrigerant Line Brazing Table 14. Braze the Refrigerant Lines Remove caps or plugs. Use a deburring tool to debur the pipe ends. Clean both internal and external surfaces of the tubing using an emery cloth. Remove the pressure tap cap and valve core from each service valves. - Page 11 R R e e f f r r i i g g e e r r a a n n t t L L i i n n e e B B r r a a z z i i n n g g Table 14.
-
Page 12: Refrigerant Line Leak Check
Refrigerant Line Leak Check Table 15. Check for Leaks Pressurize the refrigerant lines and evaporator coil to 150 PSIG using dry nitrogen. Check for leaks by using a soapy solution at each brazed location. Note: Remove nitrogen pressure and repair any leaks before continuing. -
Page 13: Service Valves
Service Valves Table 16. Open the Gas Service Valve Important: Leak check and evacuation must be completed before opening the service valves. Note: Do not vent refrigerant gases into the atmosphere. Remove valve stem cap. Using a wrench, turn valve stem 1/4 turn counterclockwise to the fully open position. -
Page 14: Electrical - Low Voltage
Electrical — Low Voltage Table 18. Low Voltage Maximum Wire Length 24 VOLTS The table defines the maximum total length of low voltage wiring WIRE SIZE MAX. WIRE LENGTH from the outdoor unit, to the indoor unit, and to the thermostat. 18 AWG 150 Ft 16 AWG... - Page 15 E E l l e e c c t t r r i i c c a a l l — — L L o o w w V V o o l l t t a a g g e e Table 20.
-
Page 16: Electrical - High Voltage
Electrical — High Voltage Table 21. High Voltage Power Supply W W A A R R N N I I N N G G L L I I V V E E E E L L E E C C T T R R I I C C A A L L C C O O M M P P O O N N E E N N T T S S ! ! F F a a i i l l u u r r e e t t o o f f o o l l l l o o w w t t h h i i s s W W a a r r n n i i n n g g c c o o u u l l d d r r e e s s u u l l t t i i n n p p r r o o p p e e r r t t y y d d a a m m a a g g e e , , s s e e v v e e r r e e p p e e r r s s o o n n a a l l i i n n j j u u r r y y , , o o r r d d e e a a t t h h . -
Page 17: System Start Up
System Start Up Set the system thermostat to OFF. Turn on electrical power disconnect(s) to apply power to the indoor and outdoor units. Wait one (1) hour before starting the unit if compressor crankcase heater accessory is used and the Outdoor Ambient is below 70°F. 60 MIN. -
Page 18: System Charge Adjustment
S S y y s s t t e e m m S S t t a a r r t t U U p p Set the system thermostat to ON. System Charge Adjustment Table 24. Temperature Measurements Check the outdoor temperatures. Subcooling using “Charging Mode-Cooling”... -
Page 19: Subcooling Charging In Cooling Between 55° F And 120° Od Ambient
Subcooling Charging in Cooling between 55° F and 120° OD Ambient [brand name] has always recommended installing [brand name] approved matched indoor and outdoor systems. All [brand name] split systems are AHRI rated with only TXV indoor systems. The benefits of installing approved indoor and outdoor split systems are maximum efficiency, optimum performance and the best overall reliability. - Page 20 SUBCOOL CHARGING CHART CORRECTIONS TABLE (FOR LINE LENGTH AND RISE) SUBCOOL CHARGING CHART CORRECTIONS TABLE (FOR LINE LENGTH AND RISE) Add 1° 4° Add 4° Add 1° Add 2° Add 1° Add 2° 1° Add 1° Use Design Subcooling 1° Use Design Subcooling Add 1°...
-
Page 21: Charging The Unit
Charging the Unit Table 26. Proper Gage Pressure Using the “Refrigerant Charging Chart,” p. 23adjust refrigerant level to attain proper gage pressure. Add refrigerant if the Liquid Gage Pressure is lower than the chart value. Connect gauges to refrigerant bottle and unit as illustrated. Purge all hoses. - Page 22 C C h h a a r r g g i i n n g g t t h h e e U U n n i i t t Table 29. System Information Record system pressures and temperatures after charging is complete.
-
Page 23: Refrigerant Charging Chart
Refrigerant Charging Chart R-410A REFRIGERANT CHARGING CHART DESIGN SUBCOOLING (°F) LIQUID TEMP (°F) LIQUID GAGE PRESSURE (PSI) Refer to Service Facts or Installer’s Guide for charging method 11-BC41D1-1A-EN... -
Page 24: Checkout Procedures
Checkout Procedures The final phase of the installation is the system Checkout Procedures. The following list represents the most common items covered in a Checkout Procedure. Confirm all requirements in this document have been met. All wiring connections are tight and properly secured. Supply registers and return grilles are open, unobstructed, and air filter is installed.
