Quatech Freedom USB Adapter User's Manual
Installing the Freedom USB
Note: The installation process
takes place in two stages: the
serial adapter board and then
the serial ports.
Caution! Be sure to allow
the installation process to
finish without interruption.
If
you
stop
the
process
before the adapter board(s)
and all of the serial ports
are
installed,
you
corrupt the installation.
Installing under Windows XP
Step
Procedure
Step 1
Turn on the power to your computer
system.
Step 2
Plug the wide flat end of the USB cable
into the downstream connector.
Step 3
Plug the square end of the USB cable into
the back of the Freedom USB box.
Rev 2.02 (2/24/2004)
This section explains how to install the Freedom USB under different
operating systems. Please locate and follow the procedure for your
computer's operating system.
Windows maintains a registry of all known hardware installed in
your computer in which it keeps track of all of your system resources,
such as I/O locations, IRQ levels, and DMA channels. The Add New
Hardware Wizard utility helps you to add new hardware and updates
this registry.
The Freedom USB includes an INF configuration file to allow easy
configuration in the Windows environment. Windows uses the INF
file to determine the system resources required by the Freedom USB,
searches for available resources to fill the boards requirements, and
will
then updates the hardware registry with an entry that allocates these
resources.
The Freedom USB also includes Windows device drivers that enable
the Freedom USB serial ports to appear to Windows as standard
COM ports.
Follow these steps to install the Freedom USB under Windows XP.
Description
This is the system in which the Freedom
USB is to be installed.
This is the connector located on the back of
the computer or USB hub.
Windows tells you that it has found new
hardware and launches the Found New
Hardware Wizard.
Installing the software
Page 3
