Wireless digital room thermostat
Hide thumbs Also See for ESRTERFW:

Advertisement

ESRTERFW
Wireless Digital

Room Thermostat

Installation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESRTERFW and is the answer not in the manual?

Questions and answers

Summary of Contents for ESI ESRTERFW

  • Page 1: Room Thermostat

    ESRTERFW Wireless Digital Room Thermostat Installation Instructions...
  • Page 2 Thank you for choosing ESi Controls. All our products are tested in the UK so we are confident this product will reach you in perfect condition and give you many years of service. However, for additional peace of mind, we recommend you register your product online at www.esicontrols.co.uk/warranty for your...
  • Page 3: Table Of Contents

    Contents Installation Instructions Technical Data Installation Instructions Installation Safety Instructions Maintenance Safety Notice Fitting the Room Thermostat Fitting the Receiver Commissioning/ Configuring Wiring Diagram DIP Switch Settings - Heating Heating Mode Receiver Manual Override...
  • Page 5: Installation Instructions

    Installation Instructions...
  • Page 6: Technical Data

    Technical data Wireless Digital Room Thermostat with TPI Fixing Easy Fit Back Plate Sensing Element Electronic Power Supply 230VAC, 50Hz Switch Action 3(1)A 230VAC Temperature Setting Range 5°C to 30°C Current rating Maxiumum 3(1)Amp Terminal Differential <0.6°C at 4°/hour Switch Type SPDT Dimensions L: 85mm x H: 85mm x D: 35mm...
  • Page 7: Installation Safety Instructions

    Installation Safety Instructions The unit must be installed by a suitably qualified person in accordance with the latest IEE Wiring Regulations. Isolate mains supply before commencing installation. Please read all instructions before proceeding. Ensure that the fixed wiring connections to the mains supply is via a fuse rated at not more than 6 amps and class ‘A’...
  • Page 8: Safety Notice

    Safety Notice WARNING! Always isolate the AC mains supply before installing. this product must be fitted by a qualified person, and installation must comply with the guidance provided in the current editions of BS767 (IEE wiring regulations) and part “P” of the building regulations. Fitting the Room Thermostat The ideal position to locate the Programmable Room Thermostat is about 1.5m above floor level, in a location...
  • Page 9: Fitting The Receiver

    3. Insert the AA batteries provided and replace the front cover of the thermostat. Fitting the Receiver Installation 1. Loosen the screws on the back-plate and remove from the Unit. 2. Fix the back-plate, terminals at the top, either direct onto a flat wall using wall plugs and screws or on a flush mounting single conduit box.
  • Page 10: Wiring Diagram

    temperature and check that the red manual button (on the receiver) lights up. 7. If unsuccessful, leave the unit powered on for 5 minutes and repeat the steps above. MANUAL Wiring Diagram Room Thermostat Receiver 1.0-2.5mm Fused Main Supply 6mm MAX COM N/O N/C N.B.
  • Page 11: Dip Switch Settings - Heating

    Terminal Identifier Description Neutral Neutral Live Live Feed (230V AC) Linked Live Feed (230V AC Heating Applications Only) Normally open Normally closed (NC) DIP Switch Settings - Heating HEAT COMP DELAY (TPI) OFF COMP DELAY (TPI) ON 6 CYCLES 3 CYCLES °F °C Heating Mode...
  • Page 12: Receiver Manual Override

    Receiver Manual Override It is possible to operate the receiver manually. This may be necessary where, for example, the batteries in the Thermostat (Transmitter) are depleted and therefore the heating cannot turn on or off. To engage the manual override, press the MANUAL button (See page 10) on the receiver, which will then light up with a green background.
  • Page 14 We are continuously developing our products to bring you the very latest in energy saving technology and simplicity. However, should you have any questions setting up your controls please email us at sales@esicontrols.co.uk or for technical queries call us on our dedicated technical helpline 07539 117468.
  • Page 15 WARNING: Interference with sealed parts renders the guarantee void. In the interests of continuous product improvement we reserve the right to alter designs, specifications and materials without prior notice and cannot accept liability for errors.
  • Page 16 Version 6.10.2 © ESi Controls Limited 2017...
