- Page 1 オ－ナ－マニュ アル 取り付け説明書...
- Page 2 The product you just purchased could be FREE! Register your product at www.lifetime.com and receive three important benefits: 1. You automatically will be entered to win $200 in our monthly drawing! 2. In the unlikely event of a product recall or safety modification, we can notify you immediately and directly.
- Page 3 **US and Canada customers only** IF ASSISTANCE IS NEEDED, DO NOT CONTACT THE STORE!!! CALL OUR CUSTOMER SERVICE DEPARTMENT 1 (800) 225-3865 HOURS: 7:00 a.m. to 5:00 p.m. Monday through Friday (Mountain Standard Time) Call, or visit our Website forSaturday hours. **For customers outside the U.S.
- Page 4 Pole Section Identification Identify the pole sections before beginning assembly. Failure to assemble the pole sections correctly may result in severe personal injury or property damage as described on Page Two. ONCE THE POLE SECTIONS HAVE BEEN SEATED, THEY CANNOT BE SEPARATED. Note: Tapers and flares are exaggerated in the illustrations.
-
Page 5: Before Beginning Assembly
Before Beginning Assembly A. Identify and inventory all parts using the checklist boxes on the Parts List. Keep the hardware bags and their contents separate. If any parts are missing, call our Customer Service Department. B. Test fit all Bolts by inserting them into their respective holes. If necessary, carefully scrape away any excess powder coating buildup from inside the holes. -
Page 6: Parts List
PARTS LIST Part # Description Qty. 088 Top Pole 089 Middle Pole 0860 Bottom Pole 087 Left Backboard Bracket 087 Right Backboard Bracket 89 Backboard 00 Wheel B000 /” x /” Axle . cm x 0 cm 008 Base FS600 Warning Sticker (Applied) 08886... - Page 7 HARDWARE IS ACTUAL SIZE (Unless otherwise indicated) Tools and Materials Required for Assembly (Not Included) . Adjustable Wrench . Phillips . 9 lbs. ( kg) of Sand/ Screwdriver Water Supply 6. Funnel . /” Wrenches () . Scrap Wood/ Cardboard...
- Page 8 /” Wrench 0000 Pull the plastic off the Top Pole while it is still inside the Middle Pole. You may need to loosen the poles before pulling the plastic out. Make sure the crimped side of the Top Pole faces the same direction as the Warning Sticker. Pull the Top Pole through the Middle Pole far enough to clear the...
- Page 9 0000 Be sure to use the Zinc Nut (CD). You may need to push the Nut (CD) into place with a 5/16” Bolt. Position the Top Pole (TP) at its lowest height setting.
- Page 10 0000 **Make sure Steps 1 through 4 are complete before starting this Step.** The Top Pole cannot be inserted after the Middle and Bottom Poles are joined. Align the slot in the Bottom Pole with the hole in the Middle Pole and slide the Middle Pole over the Bottom Pole.
- Page 11 0076 Lay the pole on the ground with Place the Base (AC) over the 1/2” the crimped side of the Top x 15 3/4” Axle (AB) and step on the Pole resting on the ground. Base so the Axle fits into the slots in the bottom of the Base.
- Page 12 0076 /” Wrenches The flattened end of the Pole Brace (AE) attaches to the Base. The angled end attaches to the pole. Only finger tighten the Nuts at this time. Completely tighten all Base and Pole Brace hardware. Tip the Base forward so the pole is resting on the ground.
- Page 13 HP8600 /” Wrenches 000 Completely tighten the Nuts. Only finger tighten the Nuts now.
- Page 14 /” Wrenches 000 Completely tighten all Rim hardware. Attach the Net (RE). WARNING For safety reasons, we recommend that sand be used instead of water in the Base. If a leak develops, water could run out unnoticed, allowing the unit to fall over and resulting in serious personal injury and/or death or property damage.
- Page 15 FILLING WITH SAND: (319 LBS (144 KG) OF SAND REqUIRED) Insert one of the 1 1/4” Base Plugs (BA) into the lower hole in the Base (Fig.1). Using a funnel, add sand through the hole in the top of the Base until the sand is just below the top hole (Fig.
- Page 16 FILLING WITH WATER: Insert one of the 1 1/4” Base Plugs (BA) into the lower hole in the Base (Fig. 1). Add water through the top hole in the Base until the water is just below the top hole (Fig. 1). Using two adults, carefully stand the system up.
- Page 17 MOVING THE PROCOURT SYSTEM: - Two adults are recommended. ® BEFORE TRANSPORTING THE PROCOURT , MAKE SURE ALL KNOBS AND ® NUTS ARE TIGHTENED COMPLETELY. a. Face the Backboard. Pull back on the Middle Pole until the system is on its Wheels. Move to the desired location. b. Using two adults, slowly stand the system to playing position. WARNING: Children should never be allowed to move the ProCourt ®...
- Page 19 N’accrochez rien au manche, brazos de elevación, ya que esto puede dañar el sistema y anular à l’anneau, au panneau ni aux leviers sous peine d’endommager la garantía. l’équipement et d’annuler la garantie. www.lifetime.com #FS16400 10/12/2004...
