INSTALLATION INSTRUCTIONS
Dishwasher XXL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DBI675 and is the answer not in the manual?

Questions and answers

Related Manuals for Asko DBI675

Summary of Contents for Asko DBI675

  • Page 1 INSTALLATION INSTRUCTIONS Dishwasher XXL...

  • Page 2: Installation Instructions

    Installation instructions [''] 48 3/4 1 1/8 - 3 3/4 DBI675 XXLS * If European widths of 23 5/8'' (600 mm) is required, remove the trim kit. 22 5/8 49 3/8 Nominal dimensions. Actual measurements may vary. Important safety instructions...

  • Page 3: Placing The Dishwasher

    NOTE! [''] The surface to which the protective film is fitted must be clean and The electrical and dry. water supplies should DBI675 XXLS 24 3/4 enter through the area indicated by the shading on the illustration. 5 3/8 *33 7/8'': Remove the trim kit.

  • Page 4: Adjust The Height And Slide The Dishwasher Into Place

    Adjust the height and slide the Drain connection dishwasher into place This dishwasher is suitable for installing in a raised recess (to attain an ergonomic working height). This means that the dishwasher can be 1 Start by measuring the height from the floor to the bottom edge of placed so that the drain hose runs to a lower level than the bottom of the countertop.

  • Page 5: Screwing The Dishwasher Into Place

    Connection to cold water supply Screwing the dishwasher into place Connect the dishwasher to the cold water supply if the building is (Applicable only to built-in dishwashers.) heated using oil, electricity, or gas. Connection to hot water supply Connect the dishwasher to the hot water supply (max. 140 °F (60 °C)) if the building is heated using an energy-efficient means such as district heating, solar power, or geothermal power.

  • Page 6: Dishwasher Toe Kick

    Dishwasher toe kick The dishwasher is supplied with a toe kick. Fit the sound insulation (only certain models) Fit the sound insulation (1-3 pieces depending on the toe kick depth). Fit the toe kick...
  • Page 7 Notes...
  • Page 8 www.askona.com...
