netsys NV-720R User Manual

Adsl2+/vdsl2 modem router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
N
V
-
7
2
0
R
N
V
-
7
2
0
R
N
V
-
7
2
0
R
ADSL2+/VDSL2 Modem Router
U
S
E
R
'
S
M
A
N
U
A
L
U
S
E
R
'
S
M
A
N
U
A
L
U
S
E
R
'
S
M
A
N
U
A
L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NV-720R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for netsys NV-720R

Summary of Contents for netsys NV-720R

  • Page 1 ADSL2+/VDSL2 Modem Router ’ ’ ’...

  • Page 2: Copyright

    In the interest of improving internal design, operational function, and/or reliability, NETSYS reserves the right to make changes to the products described in this document without notice. NETSYS does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
  • Page 3 VOD, videoconferencing, high speed Internet access and advanced voice services including VoIP, over a standard copper telephone cable.Netsys NV-720R is seen by many operators as an ideal accompaniment to a FTTP rollout, where for instance fiber optic is supplied direct to an apartment block and from there copper cable is used to supply residents with high-speed VDSL2.

  • Page 4: Safety Warnings

    Use ONLY the dedicated power supply for your device. Connect the power to the right supply voltage (110V AC used for North America and 230V AC used for Europe. NV-720R supports 12 VDC power input). Place connecting cables carefully so that no one will step on them or stumble over them. DO NOT allow anything to rest on the power cord and do NOT locate the product where anyone can work on the power cord.

  • Page 5: Table Of Contents

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Table of Contents COPYRIGHT................................................1 SAFETY WARNINGS..............................................3 1.1 C ................................................6 HECK CHAPTER 2. INSTALLING THE ROUTER.......................................7 2.1 H ............................................7 ARDWARE NSTALLATION 2.2 P ........................................7 INSTALLATION EQUIREMENTS 2.3 G ..............................................8 ENERAL ULES 2.4 C ............................................9...
  • Page 6 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 APPENDIX A: CABLE REQUIREMENTS......................................39 APPENDIX B: PRODUCT SPECIFICATION......................................42 APPENDIX C: ROUTER MODE SELECT......................................45 APPENDIX D: TROUBLESHOOTING........................................52 APPENDIX E: COMPLIANCE INFORMATION....................................60 WARRANTY ................................................63 CHINESE SJ/T 11364-2014 .............................................64...

  • Page 7: Check List

    3. Do not use sub-standard power supply. Before connecting the power supply to the device, be sure to check compliance with the specifications. The NV-720R uses a DC12V/1A power supply. 4. The power supply included in the package is commercial-grade. Do not use in industrial-grade applications.

  • Page 8: Chapter 2. Installing The Router

    • Do not install phone lines strapped together with AC power lines, or telephone office line with voice signal. • Avoid installing this device with radio amplifying stations nearby or transformer stations nearby. • Please note that the voice spectrum allowed by the NV-720R internal splitter is 0 KHz ~ 120 KHz.

  • Page 9: General Rules

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 2.3 General Rules Before making any connections to the router, please note the following rules: • Ethernet Port (RJ-45) All network connections to the router Ethernet port must be made using Category 5 UTP/STP or above for 100 Mbps, Category 3, 4 UTP for 10Mbps.

  • Page 10: Connecting The Router

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 2.4 Connecting the Router The router has four Ethernet ports which support connection to Ethernet operation. The devices attached to these ports must support auto-negotiation /10Base-T / 100Base-TX unless they will always operate at half duplex. Use any of the Ethernet ports to connect devices such as Monitor systems, Servers, Switches, bridges or routers.

  • Page 11: Rj-45 Ports

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 2.5 Connecting the RJ-11 / RJ-45 Ports The line port has 1 connector: RJ-11. It is used to connect with NV-700L(CO) using a single pair phone cable to NV-720R(CPE) bridge side (point to point solution).

  • Page 12: Vdsl2 Application

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 2.6 VDSL2 Application The router’s line port supports up to 3km for data service across existing phone wiring. It is easy-to-use and do not requires installation of additional wiring. Every modular phone jack in the home can become a port on the LAN. Networking devices can be installed on a single telephone wire that can be installed within a suitable distance.
  • Page 13 2.6.1 Connect the NV-802S and the NV-720R to the Line The objective for VDSL2 is to pass high speed data over a twisted pair cable. In the setup, connect NV-802S to NV-720R through phone wire(24~26 AWG) or line simulator or any other hardware representation of a cable network, with or without noise injection and crosstalk simulations.

  • Page 14: Chapter 3. Hardware Description

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Chapter 3. Hardware Description This section describes the important parts of the vdsl2 router. It features the front panel and rear panel. NV-720R Outward...

  • Page 15: Front Panel

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 3.1 Front Panel The figure shows the front panel. (Figure 3.1) Figure 3.1 Front Panel(NV-720R) 3.2 Front Indicators The router has Seven LED indicators. The following Table shows the description. (Table...

  • Page 16: Rear Panel

    Note: It is normal for the connection between two Routers to take up to 3 minutes, due to NV-700L/NV-720R to establish a link mechanism in auto-negotiation, with detects and calculates CO and CPE both PBO and PSD level, noise levels and other arguments for getting a better connection.
  • Page 17 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 And the table shows the description. (Table 3-2) Table 3-2 Description of the router rear connectors Connectors Type Description The reset buttons allows users to reboot the VDSL2 or load the default settings.
  • Page 18 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Before user installed power and device, please read and follow these essentials: Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must cross, make sure the wires are perpendicular at the intersection point.

  • Page 19: Chapter 4. Configure The Nv-720R Via Web Browser

    Chapter 4. Configure the NV-720R Via Web Browser The NV-720R provides a built-in HTML based management interface that allows configuration of the NV-720R via Internet Browser. Best viewed using Chrome or Firefox browsers. In order to use the web browser to configure the device, you may need to allow: •...

  • Page 20: Basic Setup

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 4.1 BASIC Setup Login webpage The IP address is 192.168.16.254 , username and password are admin. Figure 4.1 Login Password...
  • Page 21 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Display status The status page displays some information. When the device is running. For example: Device Information:...
  • Page 22 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 WAN->Network:...
  • Page 23 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 LAN->Network:...
  • Page 24 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Statistics->xDSL:...

  • Page 25: Upgrade Software

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 upgrade software Select “Management”->”upgrade software” Choose the newest Firmware file and do upgrading...

  • Page 26: Restore Default Settings

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Restore Default Settings Select “Management”->”Settings” ->”Restore Default” If Click “Restore Default Settings”, the device will reboot in 10 seconds. Warning: The settings will restore the factory defaults expect WAN connection and TR069 Settings.

  • Page 27: Wan/Tr069 Setup

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 4.2 WAN/TR069 Setup Create ATM+BRIDGE WAN Connection WAN Service page, HGW has three mode: ATM/PTM/ETH, each compare ADSL/VDSL/GE_WAN, according different network to setup. For example, below pic is ATM mode...
  • Page 28 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Create PTM +PPPoE WAN Router Connection WAN Service page, DSL mode chooses PTM, select Route+PPPoE, setup PPPoE user account and password, choose Service Type is TR069_Internet, this WAN Connection can suffer internet and can use TR069.
  • Page 29 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2...
  • Page 30 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2...
  • Page 31 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Create TR-069 Connection A: In Management/CWMP page setup ACS URL/Username/PasswordTR-069 and basic information. B: Confirm WAN Connection setting, Service TypeincludeTR-069 type...

  • Page 32: Igmp Setup

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 4.3 IGMP setup According to the WAN setting, if you want to test IGMP function on Router mode, you only need to enable IGMP function basic on the WAN SETUP.

  • Page 33: Usb Setup

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 USB setup Insert a U disk into the USB interface, then login 192.168.16.254,select “Application”->” Storage Service”->”Storage Device Info”. Confirm the system has mounted the U disk.

  • Page 34: Ftp Server

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 FTP Server Below is picture for how to enable FTP Server function.

  • Page 35: Ftp Client

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 FTP Client Below is picture for how to enable FTP Client function. Input FTP Client Settings, then chick “Download”...

  • Page 36: Tftp Server

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Click “Refresh”, Make sure the status is complete. TFTP Server Below is picture for how to enable TFTP Server function.

  • Page 37: Snmp Setup

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 4.4 SNMP setup Below is picture for how to enable SNMP function, device support SNMP V1/V2.
  • Page 38 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Download “MG-SOFT MIB Browser”. below is picture for how to use the software. Connect Remote SNMP agant.
  • Page 39 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Select OID:1.3.6.1.2.1.1.3 System Up Time...

  • Page 40: Appendix A: Cable Requirements

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Appendix A: Cable Requirements A.1 Ethernet Cable A CAT 3~7 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the router. A 10Base-T cable often consists of four pairs of wires, two of which are used for transmission. The connector at the end of the 10Base-T cable is referred to as an RJ-45 connector and it consists of eight pins.
  • Page 41 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...
  • Page 42 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 A.2 Telephone wire Standard telephone wire of any gauge or type-flat, twisted or quad is used to connect the Modem to the telephone network. A telephone cable typically consists of three pairs of wires, one of which is used for transmission. The connector at the end of the telephone cable is called an RJ-11 connector and it consists of six pins.

  • Page 43: Appendix B: Product Specification

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Appendix B: Product Specification Key Features & Benefits Adopts ARM Cortex A9 dual-core processor Supports G.993.5 Vectoring and ADSL2+ Supports G.998.4 G.INP Supports Dying Gasp Support ATM and PTM transmission mode auto detection ( ADSL backward compatible)
  • Page 44 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Supports IEEE 802.1q VLAN tagging Support IEEE 802.1p VLAN Priority and mapping to DSCP Support 8 queue MFC/DSCP both type QoS Supports HTTP/HTTPS web management Support SSL / SSH security Support remote management and monitor...
  • Page 45 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 4 x RJ-45 10/100 Mbps Ethernet port 1 x RJ-11 connector for VDSL2 line port Physical Interface: 1 x Reset Button for resetting to factory default 1 x USB2.0 for connecting USB dongle Full duplex: IEEE 802.3x...

  • Page 46: Appendix C: Router Mode Select

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Appendix C: Router Mode select This appendix describes how to select the router mode, The NV-720R default mode is switch(bridged mode), please refer to the following steps to select the router mode or switch mode. Select the Router mode: 1.
  • Page 47 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 2. Click the WAN Service link (WAN Setup) on the left navigation bar to specify the WAN Setup. Please Select as the DHCP Mode. Figure C-2 WAN Setup...
  • Page 48 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 3. Please refer to the section 4.2 to configure the wan type, the user can setup the Dynamic IP Address, Static IP Address, PPPoE mode. Figure C-3 Config WAN Type Click Apply for applying the changes.
  • Page 49 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Select the Bridged mode: 1. To configure the bridged mode settings, click the IPv4 Configuration link (LAN Setup) on the left navigation bar. And click Apply at any time during configuration to save the information that you have entered. A screen is displayed as shown in Figure C.4...
  • Page 50 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 2. Click the WAN Service link (WAN Setup) on the left navigation bar to specify the WAN setup. A screen is displayed as shown in Figure C.5...
  • Page 51 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2...
  • Page 52 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Figure C-5 WAN Setup...

  • Page 53: Appendix D: Troubleshooting

    2.4 Verify that the proper cable type is used and its length does not exceed specified limits. 2.5 Check the router on the attached device and cable connections for possible defects. 2.6 Make sure that the phone wire must be connecting NV-720R first, when powered on. 2.7 Replace the defective router or cable if necessary.
  • Page 54 VDSL setting failure or phone cable length is over the specification limit. 3.1 Please make sure that the phone wire must be connected between CO side and NV-720R (CPE) when both are power on. CO side will do link speed function depending on phone wire length, therefore if CO side can’t detect NV-720R (CPE) over phone wire while both power on,...
  • Page 55 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 The protocol was standardized in the International Telecommunication Union telecommunications sector (ITU-T) as Recommendation G.993.2. It was announced as finalized on 27 May 2005,[1] and first published on 17 February 2006. Several corrections and amendments were published in 2007 through 2011.
  • Page 56 IPERF program, and TCP window size must be settled max. 64k, the parameter as iperf –c server IP address –i 1 –t 50 –w 65535 for client side. I just bought a Netsys NV-720R to replace my Quest DSL modem for my home. I was told any VDSL2 7. Question: modem would replace and give me higher communication speeds.
  • Page 57 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Re: Please note NV-720R is a remote side(CPE side), it must be connected to the CO side to work. Answer: Tone mode, Band profile and band plan setting must be compatible to each other if not access error will show when applied.
  • Page 58 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 10. Question: What can I do if I forgot my password. If you forgot your password, you must reset your router. Unfortunately this process will change all your settings back to the factory defaults. To reset the router, locate the reset on the rear panel of the unit.
  • Page 59 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 System Diagnostics Power and Cooling Problems If the POWER indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply as explained in the previous section. However, if the unit power is off after running for a while, check for loose power connections, power losses or surges at the power outlet.
  • Page 60 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Physical Configuration If problems occur after altering the network configuration, restore the original connections, and try to track the problem down by implementing the new changes, one step at a time. Ensure that cable distances and other physical aspects of the installation do not exceed recommendations.

  • Page 61: Appendix E: Compliance Information

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Appendix E: Compliance Information FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a computing device, pursuant to Part 15 of FCC rules.
  • Page 62 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service.
  • Page 63 NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 WEEE Warning To avoid the potential effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment, end users of electrical and electronic equipment should understand the meaning of the crossed-out wheeled bin symbol.

  • Page 64: Warranty

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Warranty The original product that the owner delivered in this package will be free from defects in material and workmanship for one year parts after purchase. There will be a minimal charge to replace consumable components, such as fuses, power transformers, and mechanical cooling devices.

  • Page 65: Chinese Sj/T 11364-2014

    NV-720R ADSL2+/ VDSL2 Modem Router USER’S MANUAL Ver. A.2 Chinese SJ/T 11364-2014 有 毒 有 害 物 质 或 元 素 部件名称 铅(Pb) 汞(Hg) 镉(Cd) 六价铬[Cr(VI)] 多溴联苯(PBB) 多溴二苯醚(PBDE) 结构壳体 ○ ○ ○ ○ ○ ○ 电路组 ○ ○ ○ ○...
