netsys NV-600L/R User Manual

Netsys nv-600l/r vdsl2 with 4 port ethernet switch (master-/slave-modems)
Hide thumbs
Table of Contents

Advertisement

Quick Links

NV-600L/R
VDSL2 CO/CPE Router
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NV-600L/R and is the answer not in the manual?

Questions and answers

Related Manuals for netsys NV-600L/R

Summary of Contents for netsys NV-600L/R

  • Page 1 NV-600L/R VDSL2 CO/CPE Router USER’S MANUAL...

  • Page 2: Copyright

    In the interest of improving internal design, operational function, and/or reliability, NETSYS reserves the right to make changes to the products described in this document without notice. NETSYS does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
  • Page 3 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 VDSL2 Point to Point Solution VDSL2 (Very-High-Bit-Rate Digital Subscriber Line 2, ITU-T G.993.2 Standard) is an access technology that exploits the existing infrastructure of copper wires that were originally deployed for POTS services. It can be deployed from central offices, from fibre-fed cabinets located near the customer premises, or within buildings.

  • Page 4: Safety Warnings

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Safety Warnings For your safety, be sure to read and follow all warning notices and instructions before device use. • DO NOT open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other risks. ONLY qualified service personnel can service the device.

  • Page 5: Table Of Contents

    2.2 Pre-installation Requirements..............................9 2.3 General Rules....................................10 2.4 NV-600L/R Connections ................................10 3. Hardware Description...................................12 3.1 Front Panel ....................................12 3.2 Six LED indicators ..................................13 3.3 Front Indicators..................................13 3.4 Rear Panel....................................14 3.5 Power On....................................14 4. Configure the NV-600L/R Via Web Browser..........................15 4.1 Login......................................15...
  • Page 6 4.4 Select LAN....................................20 4.4.1 Select LAN Settings and set the IP Address ........................21 4.4.2 Restart the Settings Dialog ...............................23 5. Configure the NV-600L/R via Console............................24 5.1 Setup on Hyperterminal ................................24 5.2 Reset the system to default configuration..........................24 6. Building a VDSL2 System ................................25 6.1 Connect the NV-600L and the NV-600R to the Line ........................26...
  • Page 7 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8. Configuration Interface of the Router ............................47 8.1 Logging in to the NV-600L/R..............................48 8.2 Setup Wizard and Advanced Setup ............................49 8.2.1 Setup Wizard ..................................50 8.2.2 Advanced Setup................................51 8.2.3 System....................................53 8.2.3.1 Administrator Settings..............................54 8.2.3.2 Firmware Upgrade .................................56 8.2.3.3 Device Mode..................................57...
  • Page 8 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.8 Route Settings ..................................88 8.2.8.1 Static Routing.................................89 8.2.8.2 Routing Table List ................................90 8.2.9 UPnP Setting ..................................91 8.2.9.1 Settings..................................92 Appendix A: Product Features & Specification ..........................93 Features: ......................................93 Specifications: ....................................94 Appendix B: Troubleshooting .................................96 Appendix C : Compliance and Safety Information.........................98 Warranty ......................................101...

  • Page 9: Unpacking Information

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 1.Unpacking Information 1.1 Check List Carefully unpack the package and check its contents against the checklist. Package Contents VDSL2 Router (NV-600L for CO side/ NV-600R for CPE side) Two rubber feet User’s Manual AC to DC 12V Power Adapter RJ-45 cable RJ-11 cable...

  • Page 10: Complete Installation

    • Power requirements: DC12V/1A or above. • The NV-600L/R should be located in a cool dry place, with at least 10cm/4in of space at the front and back for ventilation. • Place the NV-600L/R out of direct sunlight, and away from heat sources or areas with a high amount of electromagnetic interference.

  • Page 11: General Rules

    2.4 NV-600L/R Connections The NV-600L/R can be controlled by a PC. For this purpose, a PC is needed with an Ethernet network interface and a DB-9 RS-232 serial interface. Two programs are required: A Web browser is mandatory and a terminal program should be available optionally.
  • Page 12 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Figure 2.4 VDSL2 Basic Setup...

  • Page 13: Hardware Description

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 3. Hardware Description This section describes the important parts of the NV-600L/R. It features the front indicators and rear connectors. 3.1 Front Panel The following figure shows the front panel. Figure 3.1.1 NV-600L...

  • Page 14: Six Led Indicators

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 3.2 Six LED indicators At a quick glance of the front panel, it will be easy to tell if the router has power signal from its Ethernet RJ-45 port or there is phone line signal RJ-11port 3.3 Front Indicators The following table describes the LEDs.

  • Page 15: Rear Panel

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 3.4 Rear Panel The following figure shows the rear connectors Figure 3.4 Rear Connectors NV-600L/R Rear Connectors Connectors Type Description Line RJ-11 For connecting to the VDSL2 Router Using a RJ-11 cable Phone...

  • Page 16: Configure The Nv-600L/R Via Web Browser

    4. Configure the NV-600L/R Via Web Browser The NV-600L/R provides a built-in HTML based management interface that allow user configure the NV-600L/R via Internet Browser. Recommend using Internet Explorer 6.0 or later version and set screen resolution at 1024 x 768.

  • Page 17: Select The Menu Level

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 4.2 Select the Menu Level There is an easy Setup Wizard for end users at the NV-600R and an Advanced Setup for more detail configurations. This manual attaches importance to the Advanced Setup.
  • Page 18 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Figure 4.2 Select the Advanced Setup in the Entry Screen...

  • Page 19: Select Advanced Setup

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 4.3 Select Advanced Setup Select the Advanced Setup. The menu below will be used frequently. As an exercise and an example now the IP address will be set.
  • Page 20 LAN settings. Such a change may be necessary when connecting the NV-600L/R to a new control PC and/or in order to turn the IP address changed via a shell command into a default address for the next restart of the board.

  • Page 21: Select Lan

    4.4 Select LAN The menu below will not be used very often, but when connecting the NV-600L/R to a new control PC, one may want to go through the following steps in order to make the IP address previously set by ifconfig in the console or on some later occasion one may want to change it again without using the console then the menu below will be helpful.

  • Page 22: Select Lan Settings And Set The Ip Address

    4.4.1 Select LAN Settings and set the IP Address The form below is used to change the IP address of the LAN port “adm0” in the NV-600L/R. The proposed IP address is either the default address of adm0 or it is the address changed by an ifconfig command via the shell running in the terminal.
  • Page 23 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Figure 4.4.1 LAN Settings Now the IP address either may be changed or left as it is. If it has been changed in the form or after it has been changed through console ifconfig command, it needs to be “APPLY” in order to make the displayed IP address new default address.

  • Page 24: Restart The Settings Dialog

    After the “APPLY” button has been hit, the displayed IP address “adm0” port will be stored in a non volatile memory on the NV-600L/R. Also, the Ethernet link between the control PC and the NV-600L/R will be re-initialized – even if the IP address has not been changed.

  • Page 25: Configure The Nv-600L/R Via Console

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 5. Configure the NV-600L/R via Console 5.1 Setup on Hyperterminal Open the Hyperterminal and set the baud rate to 115200, 8N1N to properly set the hyperterminal. Figure 5 Hyperterminal Configuration 5.2 Reset the system to default configuration.

  • Page 26: Building A Vdsl2 System

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 6. Building a VDSL2 System First a quick overview on a complete setup of NV-600L/R: Figure 6 VDSL2 Application...

  • Page 27: Connect The Nv-600L And The Nv-600R To The Line

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 6.1 Connect the NV-600L and the NV-600R to the Line The objective for VDSL2 is to pass high speed data over a twisted pair cable. In the setup, connects NV-600L to NV-600R through phone wire or line simulator or any other hardware representation of a cable network, with or without noise injection and crosstalk simulations.

  • Page 28: Operating The Vdsl2 System

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 7. Operating the VDSL2 System After the VDSL2 system has been set up, one may want to configure the settings that are related to VDSL2. Configuration of operation modes, test modes (loop back) and the display of status information are supported by GUI (Graphical User Interface).

  • Page 29: Channel Configuration

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 7.1.1 Channel Configuration This function is for setting VDSL2 channel. Figure 7.1.1 Channel Configuration Menu...
  • Page 30 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Interleave delay function is used in digital data transmission technology to protect the transmission against noise issue and data error. If during transit more than a certain amount of data has been lost then the data cannot be correctly decoded. Short bursts of noise on the line can cause these data packets to become corrupt and the router has to re-request data which in turn can slow down the overall rate at which data is transmitted.
  • Page 31 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Channel Configuration Settings Setting Description To which bearer channel number shall the settings apply? Channel Number Channel 0 To which direction shall the settings apply? Direction Upstream Downstream Min Data Rate Minimum Payload Data Rate Max Data Rate Maximum Payload Data Rate Max Interleave Delay...

  • Page 32: Line Configuration

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 7.1.2 Line Configuration Figure 7.1.2 Line Configuration Menu for SNR Margin Selection Line Configuration Setting Description Direction Select the target direction. Target SNRM Set the required SNR Margin *10 (60=6dB)

  • Page 33: Profile Configuration

    The only thing that NV-600R must be configured so that the routers will link is the tone mode. However, the default tone mode for NV-600L/R is V43, so at default there’s no need to change the tone mode unless it is required by the telecom companies to use different tone mode.
  • Page 34 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Figure 7.1.3.1 NV-600L Profile Configuration...
  • Page 35 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Figure 7.1.3.2 NV-600R Profile Configuration...
  • Page 36 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Figure 7.1.3.3 Band Profile and Plan Setup Error Figure 7.1.3.4 Band Profile Region...
  • Page 37 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 The following shows the band profile and band plan compatibility: Band Profile List Band Plan List VDSL2 Profile8a Annex A M1_EU32 VDSL2 Profile8b Annex A M9_EU64 VDSL2 Profile8c Annex B 997-M2x-A (B05) VDSL2 Profile8d Annex B 997-M2x-M (B06) VDSL2 Profile12a Annex B 997-M1c-A-7 (B07)
  • Page 38 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Band Profile \ Band Plan 13 14 16 18 20 21 22 23 24 25 26 Note: O = Compatible; X = Not Compatible...
  • Page 39 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 The following phone cable distance and data rates are possible according to the band profile and band plan setup: Default plan profile and band plan = 30a and C8K At distance 0-350m, data rates are at 100Mbps for both downstream and upstream 350-450m, data rates are at 70-85/40Mbps for downstream/upstream 450-600m at 40-60/10Mbps for downstream/upstream 600-900m at 20-40/1-5Mbps for downstream/upstream...

  • Page 40: Loop Back

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 7.1.4 Loop Back The loop back testing function for checking phone wire link problem: 1. System Loop. 2. Line Side Loop Figure 7.1.4 Loop Back Activation/Deactivation Menu Loop Back Setting Description To which bearer channel number shall the settings apply? Channel No.

  • Page 41: Line Activation

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 7.1.5 Line Activation This function is for enable/disable VDSL2 port. Figure 7.1.5 Activation and Deactivation of the Line Line Activation/Deactivation Setting Description Activate or deactivate the line. (Select the activity and the press the APPLY Line button.)

  • Page 42: Status Displays

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 7.2 Status Displays 7.2.1 Line Status This function provides SNR value for checking phone wiring quality. Figure 7.2.1 Line Status Display: Actual SNR The following status messages may occur: not_initialized, exception, idle request, idle, silent request, silent, handshake, full init, discovery, training, analysis, exchange, showtime no sync, showtime tc sync, fast retrain, lowpower l2, loopdiagnostic, loopdiagnostic complete, resync, test, lowpower l3, unknown.

  • Page 43: Channel Status

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 7.2.2 Channel Status This function shows VDSL2 port status. Figure 7.2.2 Channel Status Display: Data Rate, Delay, Error Counters and Impulse Noise Protection...

  • Page 44: Version Info

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 7.2.3 Version Info This function shows hardware and firmware version. Figure 7.2.3 Display of Version Data...

  • Page 45: Snr Graphs

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 7.2.4 SNR Graphs When NV-600L link with NV-600R, this graph will show the SNR value for each band.
  • Page 46 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Figure 7.2.4 Display of SNR per Carrier...

  • Page 47: Bitsgraphs

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 7.2.5 BitsGraphs When NV-600L link with NV-600R, this graph will show the bits value for each tone. Figure 7.2.5 Display Bits Per Tone Graph...

  • Page 48: Configuration Interface Of The Router

    8. Configuration Interface of the Router This section explains how to configure the router section of the NV-600L/R using its web-based configuration. The part of the circuitry as well as the router configuration menu has been ported from that of the reference kit to the NV-600L/R reference board.

  • Page 49: Logging In To The Nv-600L/R

    8.1 Logging in to the NV-600L/R To log on to the NV-600L/R Web Application, you must have a valid password. The Administrator creates the log on user with its password. When one log on to the NV-600L/R Web Application, the LOGIN PASSWORD window is displayed as...

  • Page 50: Setup Wizard And Advanced Setup

    There is an easy Setup Wizard for end users at the NVF-200R side and an Advanced Setup for more detail configurations for both NV-600L/R. This manual gives importance to the Advanced Setup. Figure 8.2 Select the Advanced Setup in the Entry Screen...

  • Page 51: Setup Wizard

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.1 Setup Wizard The Setup Wizard is designed for ease-of-use in order to quickly configure the most common settings. The Admin can view the Setup Wizard link in the homepage. The wizard first step is to allow the admin to configure the system host settings displayed as shown in Figure 8.2.1.

  • Page 52: Advanced Setup

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.2 Advanced Setup Click on the Advanced Setup link in the homepage in case you want to configure a wider range of settings. Router setup are only located at NV-600R. So the WAN, NAT, Firewall and UPnP are only seen at NV-600 advanced setup menu. The following configuration options are displayed in the left navigation bar, as shown in Figure 8.2.2.
  • Page 53 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Figure 8.2.2 Advanced Setup...

  • Page 54: System

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.3 System The System link can be viewed in the left navigation bar. The following are the options available under System, as shown Figure 8.2.3. • Administrator Settings • Firmware Upgrade • Device Mode (NV-600R only) •...

  • Page 55: Administrator Settings

    Figure 8.2.3.1. Figure 8.2.3.1 Administrator Settings Configuration While adding a user, each user must assign a separate port. Hence the number of users that can be added to the system depends on the number of ports available on the NV-600L/R.
  • Page 56 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 The screen contains the following details: Fields in User Setting Field Description This is the password associated with the administrator. This is enabled only for the user Current Password Administrator login. Password This is the password of the login administrator. Re-type Password This is the password verification.

  • Page 57: Firmware Upgrade

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.3.2 Firmware Upgrade To update the system firmware, click on the Firmware Upgrade link in the left navigation bar. A screen is displayed as shown in 8.2.3.2 Figure 8.2.3.2 Firmware Update The screen contains the following detail: •...

  • Page 58: Device Mode

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.3.3 Device Mode The ADM5120 network processor used in the reference system is able to act as either a switch or a router. Clicking on Device Mode on the left navigation bar allows the user to change the mode of operation, as shown in the following figure. Figure 8.2.3.3 Device Mode The default setting is in Switch mode, it is not necessary to change the setting in most of the case.

  • Page 59: System Status

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.3.4 System Status To view system status, click on the System Status link in the left navigation bar. A screen is displayed as shown in Figure 8.2.3.4 Figure 8.2.3.4 Status Window...

  • Page 60: Reboot

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.3.5 Reboot To reboot the unit, click on the Reboot link in the left navigation bar. A screen is displayed as shown in Figure 8.2.3.5. Figure 8.2.3.5 Reboot NV-600L/R Router • Click Reboot to restart the unit.

  • Page 61: Reset System

    8.2.3.6 Reset system To reset the system, click on the Reset link in the left navigation bar. A screen is displayed as shown in Figure 8.2.3.6. Figure 8.2.3.6 Reset NV-600L/R Router • Click Reset to restart the system to default configuration.

  • Page 62: Wan

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.4 WAN The WAN settings can be viewed in the left navigation bar of NV-600R only. The following are the options available under WAN, as shown Figure 8.2.4: • Dynamic IP • IP Settings •...

  • Page 63: Dynamic Ip

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.4.1 Dynamic IP To configure the WAN interface to dynamically obtain an IP Address, click on the Dynamic IP link in the left navigation bar. A screen is displayed as shown in Figure 8.2.4.1.

  • Page 64: Ip Settings

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.4.2 IP Settings To configure the WAN interface to use a Static IP Address, click on the Static IP link in the left navigation bar. A screen is displayed as shown in Figure 8.2.4.2.
  • Page 65 Subnet Mask Enter the Subnet Mask of NV-600L/R. ISP Gateway Address Enter the Gateway address of the NV-600L/R. Provides more IP Addresses of the WAN interface. Select the check box Does ISP provide more IP Address to enable this option. A screen is displayed as shown in Figure 41. Click Add to add IP Address and Subnet Mask.

  • Page 66: Pppoe

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.4.3 PPPoE To configure the WAN interface to use PPPoE, click on the PPPoE link in the left navigation bar. A screen is displayed as shown in Figure 8.2.4.3. Figure 8.2.4.3 PPPoE Configuration...
  • Page 67 If no packets are transmitted between LAN port and WAN port or between Maximum Idle Time NV-600L/R and WAN, the connection is disconnected after the 'Maximum idle time. If the Auto-reconnect check box is selected, the PPP connection is re-established if there is some data that is received from the upper layers to be transmitted on this link.

  • Page 68: Dns

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.4.4 DNS To configure the DNS address, click on the DNS link in the left navigation bar. A screen is displayed as shown in Figure 8.2.4.4: Figure 8.2.4.4 DNS Configuration...
  • Page 69 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 The screen contains the following details: Fields in DNS Field Description Domain Name Server(DNS) Address Enter the DNS address of the primary DNS server. Secondary DNS Address(optional) Enter the address of the secondary DNS server, if available. •...

  • Page 70: Lan

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.5 LAN The LAN Setting can be viewed in the left navigation bar. The following are the options available under LAN, as shown in Figure 8.2.5: • LAN Settings • DHCP Client List •...

  • Page 71: Lan Settings

    8.2.5.1 LAN Settings Attention: For the NV-600L/R it is recommended to select a simple IP setting suitable to controlled lab environments. Set a static IP address and don’t use DHCP. The required steps are explained in Chapter 4.4.1 on Page 21! To configure the LAN interface, click on the LAN Settings link in the left navigation bar.
  • Page 72 Enter the LAN interface IP Address of NV-600L/R. Subnet Mask Enter the LAN Subnet Mask of NV-600L/R. Enable or disables the DHCP Server of the NV-600L/R. Select the The Gateway acts as DHCP Server check-box to enable this option. • Click APPLY to save the information that has been entered.

  • Page 73: Dhcp Client List

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.5.2 DHCP Client List To view the DHCP client list, click on the DHCP Client List link in the left navigation bar. A screen is displayed to list all DHCP client connection with IP Address and MAC Address as shown in Figure 8.2.5.2.

  • Page 74: Lan Switch Port Setting

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.5.3 LAN Switch Port Setting To view the All LAN Port Setting, click on the All Lan Port Setting link in the left navigation bar. A screen is displayed to all LAN Port Setting as shown in Figure 8.2.5.3.

  • Page 75: Lan Port Status

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.5.4 LAN Port Status The following information provides a view of the current Ethernet ports status of the unit Figure 8.2.5.4 LAN Port Status...

  • Page 76: Nat

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.6 NAT The NAT Settings can be viewed in the left navigation bar of NV-600R only. The following are the options available under NAT, as shown in Figure 8.2.6: • Virtual Server • Port Mapping •...

  • Page 77: Virtual Server

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.6.1 Virtual Server To configure virtual server, click on the Virtual Server link in the left navigation bar. A screen is displayed as shown in Figure 8.2.6.1: Figure 8.2.6.1 Virtual Server Configuration...
  • Page 78 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 The screen contains the following details: Fields in Virtual Server Field Description Private IP Enter a private IP Address of specified entry. Private Port Enter a private Port number of the specified entry. Type Select virtual server protocol type of the specified entry.

  • Page 79: Port Mapping

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.6.2 Port Mapping To configure Port Mapping, click on the Port Mapping link in the left navigation bar. A screen is displayed as shown in Figure 8.2.6.2: Figure 8.2.6.2 Port Mapping Configuration...
  • Page 80 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 The screen contains the following details: Fields in Port Mapping Field Description Server IP Enter the IP Address of a specified local machine. Mapping Port Assign a range of port or specific port number to route the packets. Enabled Enable a specified entry of the Port Mapping.

  • Page 81: Dmz

    Figure 8.2.6.3 DMZ Configuration The screen contains the following details: Fields in DMZ Field Description Enable or disable the DMZ setting of NV-600L/R. Select the check box to enable this Enable option. IP Address Enter IP Address of the DMZ host.

  • Page 82: Firewall

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.7 Firewall The Firewall Settings can be viewed in the left navigation bar of NV-600R only. The following are the options available under Firewall, as shown in Figure 8.2.7: • Firewall Options • Client Filter MAC Control •...

  • Page 83: Firewall Options

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.7.1 Firewall Options To enable the firewall options, click on the Firewall Options link in the left navigation bar. A screen is displayed as shown Figure 8.2.7.1: Figure 8.2.7.1 Firewall Options Configuration...
  • Page 84 Select the check box to drop all PING from the WAN side. Discard PING the Gateway Select the check box to drop all PING to NV-600L/R packet for the LAN side. Drop Port Scan Select the check box to drop all the port scan packets.

  • Page 85: Client Filtering

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.7.2 Client Filtering To enable Client Filter, click on the Client Filter link in the left navigation bar. A screen is displayed as shown in Figure 8.2.7.2. Figure 8.2.7.2 Client Filter Configuration The screen contains the following details:...
  • Page 86 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Fields in Client Filter Field Description Enable or disable the Client Filter feature of VDSL2 CO&CPE ROUTER. Select the Enable Client Filter check box to enable this option. Enter the filter IP Address range of the local machines under VDSL2 CO&CPE ROUTER.

  • Page 87: Mac Control

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.7.3 MAC Control To configure MAC Control, click on the MAC Control link in the left navigation bar. A screen is displayed as shown in Figure 8.2.7.3 Figure 8.2.7.3 MAC Control Configuration...
  • Page 88 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 The screen contains the following details: Fields in MAC Control Field Description MAC Address Control Enable or disable the MAC address control. Enable or disable block status. If the check box is selected, it blocks the Block Connection to Internet specified MAC address.

  • Page 89: Route Settings

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.8 Route Settings The Route Settings can be viewed in the left navigation bar. The following are the options available under Route, as shown in Figure 8.2.8: • Static Routing • Routing Table List Figure 8.2.8 Route in Left Navigator Bar...

  • Page 90: Static Routing

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.8.1 Static Routing To setup Static Routing, click on the Static Routing link in the left navigation bar. A screen is displayed as shown in Figure 8.2.8.1. Figure 8.2.8.1 Static Routing Configuration The screen contains the following details: Fields in Static Routing Field Description...

  • Page 91: Routing Table List

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.8.2 Routing Table List To view the Routing entry table list of NV-600L/R, click on the Routing Table by link in the left navigation bar. A screen is displayed as shown in Figure 8.2.8.2.

  • Page 92: Upnp Setting

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.9 UPnP Setting The UPnP Settings can be viewed in the left navigation bar of NV-600R only. The following are the options available under UPnP, as shown in Figure 8.2.9. Figure 8.2.9 UPnP in Left Navigator Bar...

  • Page 93: Settings

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 8.2.9.1 Settings To enable or disable the UPnP Settings, click on the Settings link in the left navigation bar. A screen is displayed as shown in Figure 8.2.9.1. Figure 8.2.9.1 UPnP Configuration The screen contains the following details: Fields in UPnP Settings Field Description...

  • Page 94: Appendix A: Product Features & Specification

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Appendix A: Product Features & Specification Features: • Compliant with IEEE 802.3 & 802.3u Ethernet Standards • Compliant with G993.2 VDSL2 standards • Provides 4 x 10/100M auto-sensing RJ-45 Ethernet ports • Supports Bandwidth setup with 100 Mbps VDSL RJ-11 ports •...

  • Page 95: Specifications

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Specifications: Standard: IEEE802.3 standard IEEE802.3u standard Compliant G993.2 VDSL2 standard Interface: 4 * RJ-45 10/100Mbps Ethernet port 1 * RJ-11 connector for VDSL2 1 * RJ-11 connector for POTS/ISDN device Band Profile: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 17b, 30a Band Plan: 997, 998 Max.
  • Page 96 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Storage Temperature: -20° C ~ 70° C (-4° F ~ 158° F) Humidity: 10 to 90% (non-condensing) Weight: 0.96kg & 1.03kg (for metal case) Dimensions: 184 x 146 x 40 mm (7.2" x 5.74" x 1.57”) AC to DC adapter: Input range: 85VAC~240VAC/50~60Hz Output: 12VDC/1A...

  • Page 97: Appendix B: Troubleshooting

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Appendix B: Troubleshooting 1. Symptom: Connected the CO Router with CPE Router within 300 meters RJ-11 phonecable got only less than 10 Mbit/s. Cause: Some testing program which is base on TCP/IP protocol such as FTP, Iperf, NetIQ, the bandwidth of testing outcome will be limited by TCP window size.
  • Page 98 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Solution: Open a command prompt and log in to telnet by writing “telnet xxx.xxx.xxx.xxx”, xxx is the IP address of your router, then write “cd /etc/rc.d/init.d” to go to this folder, then write “./httpd start” to open the web management, so that it can be accessed again.

  • Page 99: Appendix C : Compliance And Safety Information

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Appendix C : Compliance and Safety Information FCC Radio Frequency Interference Statement This equipment has been tested to comply with the limits for a computing device, pursuant to Part 15 of FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 100 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service.
  • Page 101 NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at owner’s expense. CE Mark Warning This is a CE class A product.

  • Page 102: Warranty

    NV600L/R VDSL2 CO&CPE Router USER’S MANUAL Ver.A15 Warranty The original owner of this package will be free from defects in material and workmanship for one year parts after purchase. For the warranty to apply, you must register your purchase by returning the registration card indicating the date of purchase. There will be a minimal charge to replace consumable components, such as fuses, power transformers, and mechanical cooling devices.
